2013 Lexus GX460 navigation system

TABLE OF CONTENTSIndex
2
GX460_OM_OM60J63U_(U)
1-1. Key informationKeys ...................................................... 28
1-2. Opening, closing and locking the doors
Smart access system with push-button start ........................... 31
Wireless remote control .............. 49
Side doors .......................................... 52
Back door ........................................... 57
Glass hatch ........................................ 62
1-3. Adjustable components (seats, mirrors, steering wheel, etc.)
Front seats .......................................... 67
Rear seats ............................................. 71
Driving position memory (driver’s seat) ................................. 82
Head restraints................................. 86
Seat belts ........................................... 89 Steering wheel.................................. 97
Inside rear view mirror.................. 99
Outside rear view mirrors .......... 101
1-4. Opening and closing the windows and moon roof
Power windows.............................. 105
Moon roof ........................................ 108
1-5. Refueling Opening the fuel tank cap........... 113
1-6. Theft deterrent system Engine immobilizer system ......... 119
Alarm.................................................... 121
1-7. Safety information Correct driving posture ............. 124
SRS airbags ..................................... 126
Front passenger occupant classification system .................. 143
Child restraint systems ............... 150
Installing child restraints ............. 155
1Before driving
For vehicles with a navigation system, refer to the “Navigation System Owner’s
Manual” for information regarding the equipment listed below.
• Navigation system
• Audio/video system
• Rear seat entertainment system
• Air conditioning
• Windshield wiper de-icer
• Rear window and outside rear view mirror defogging •Hands-free system (for cellular
phone)
• Intuitive parking assist
• Wide view front & side monitor
• Lexus Enform with Safety Connect
GX460_OM_OM60J63U_(U).book Page 2 Thursday, March 29, 2012 9:10 AM

15
GX460_OM_OM60J63U_(U)
A
Headlight cleaner switch∗
P. 249
Fuel filler door opener P. 113
VSC OFF switch P. 339
Heated steering wheel switch∗
P. 555
ODO/TRIP button P. 200
Instrument cluster light control switch P. 200
Outside rear view mirrorswitches
P. 101
∗: If equipped
*: Refer to “Navigation System Owner’s Manual”.
GX460_OM_OM60J63U_(U).book Page 15 Thursday, March 29, 2012 9:10 AM

17
GX460_OM_OM60J63U_(U)
C
Accessory meter∗ P. 216
∗: If equipped
*: Refer to “Navigation System Owner’s Manual”.
Vehicles without a navigation system
Vehicles with a navigation systemSecurity indicator
P. 119, 121
Rear window defogger switch P. 417
Air conditioning system P. 398
Navigation system*Security indicator P. 119, 121
Air conditioning system*
Rear window defogger switch*
Windshield wiper de-icer P. 418
GX460_OM_OM60J63U_(U).book Page 17 Thursday, March 29, 2012 9:10 AM

119
1
Before driving
GX460_OM_OM60J63U_(U)
1-6. Theft deterrent system
Engine immobilizer system
The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s on-
board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
Vehicles without a navigation systemThe indicator light flashes after
the “ENGINE START STOP”
switch has been turned OFF to
indicate that the system is oper-
ating.
The indicator light stops flashing
after the “ENGINE START
STOP” switch has been turned
to ACCESSORY or IGNITION
ON mode to indicate that the
system has been canceled.
Vehicles with a navigation system The indicator light flashes after
the “ENGINE START STOP”
switch has been turned OFF to
indicate that the system is oper-
ating.
The indicator light stops flashing
after the “ENGINE START
STOP” switch has been turned
to ACCESSORY or IGNITION
ON mode to indicate that the
system has been canceled.
GX460_OM_OM60J63U_(U).book Page 119 Thursday, March 29, 2012 9:10 AM

121
1
1-6. Theft deterrent system
Before driving
GX460_OM_OM60J63U_(U)
Alarm
The system sounds the alarm and flashes the lights when forced entry is
detected.
■Triggering of the alarm
The alarm is triggered in the following situations when the alarm is
set:
● A locked door or glass hatch is unlocked or opened in any way
other than using the entry function, wireless remote control or
mechanical key. (The doors will lock again automatically.)
● The hood is opened.
■ Setting the alarm system
Vehicles without a navigation system Close the doors, glass hatch
and hood, and lock all the doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the
system is set.
GX460_OM_OM60J63U_(U).book Page 121 Thursday, March 29, 2012 9:10 AM

122
1-6. Theft deterrent system
GX460_OM_OM60J63U_(U)
■System maintenance
The vehicle has a maintenance-free type alarm system.
■Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the
following:
●Nobody is in the vehicle.
●The windows and moon roof are closed before the alarm is set.
●No valuables or other personal items are left in the vehicle.
Vehicles with a navigation systemClose the doors, glass hatch
and hood, and lock all the doors.
The system will be set automati-
cally after 30 seconds.
The indicator light changes from
being on to flashing when the
system is set.
■Deactivating or stopping the alarm
Do one of the following to de activate or stop the alarms:
● Unlock the doors.
● Start the engine. (The alarm will be deactivated or stopped after a
few seconds.)
GX460_OM_OM60J63U_(U).book Page 122 Thursday, March 29, 2012 9:10 AM

202
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)
Indicators and warning lights
The indicators and warning lights on the instrument cluster and center
panel inform the driver of the status of the vehicle’s various systems.
Instrument cluster
Center panel (vehicles without a navigation system)
GX460_OM_OM60J63U_(U).book Page 202 Thursday, March 29, 2012 9:10 AM

203
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
Center panel (vehicles with a navigation system)
GX460_OM_OM60J63U_(U).book Page 203 Thursday, March 29, 2012 9:10 AM
