2013 Lexus GX460 engine

624
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Engine coolantThe coolant level is satisfactory if it is between the “F” and “L” lines on the
reservoir when the engine is cold. Reservoir cap
Full
Low
If the level is on or below the “L”
line, add coolant up to the “F” line.
■Coolant selection
Only use “Toyota Super Long Life Coolant” or similar high quality ethylene glycol
based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life
hybrid organic acid technology.U.S.A.: “Toyota Super Long Life Coolant” is a mixture of 50 % coolant and 50 %
deionized water. (Minimum temperature: -31 °F [-35 °C])
Canada: “Toyota Super Long Life Coolant” is a mixture of 55 % coolant and 45 % deionized water. (Minimum temperature: -44 °F [-42 ° C])
For more details about coolant, contact your Lexus dealer.
GX460_OM_OM60J63U_(U).book Page 624 Thursday, March 29, 2012 9:10 AM

625
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
■If the coolant level drops within a short time after replenishing
Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and
water pump.
If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in
the cooling system.
CAUTION
■When the engine is hot
Do not remove the radiator cap.
The cooling system may be under pressure and may spray hot coolant if the cap is
removed, causing serious injuries, such as burns.
NOTICE
■When adding the coolant
Coolant is neither plain water nor straight antifreeze. The correct mixture of water
and antifreeze must be used to provide proper lubrication, corrosion protection
and cooling. Be sure to read the antifreeze or coolant label.
■If you spill coolant
Be sure to wash it off with water to prevent it damage to parts or paint.
GX460_OM_OM60J63U_(U).book Page 625 Thursday, March 29, 2012 9:10 AM

626
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Radiator and condenserCheck the radiator and condenser and clear any foreign objects.
If either of the above parts is extremely dirty or you are not sure of their
condition, have your vehicle checked by your Lexus dealer.
CAUTION
■When the engine is hot
Do not touch the radiator or condenser as they may be hot and cause serious inju-
ries, such as burns.
GX460_OM_OM60J63U_(U).book Page 626 Thursday, March 29, 2012 9:10 AM

629
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Power steering fluid■ Fluid level
The fluid level should be within the appropriate range.
Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: The vehicles has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frig id temperatures. (Fluid temper-
ature, 140 °F - 175 ° F [60 °C - 80 ° C]).
Cold: The engine has not been run for about 5 hours. (Room tempera- ture, 50 °F - 85 °F [10 ° C - 30 °C]).
GX460_OM_OM60J63U_(U).book Page 629 Thursday, March 29, 2012 9:10 AM

632
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
■Before recharging
When recharging, the battery produces hydrogen gas which is flammable and
explosive. Therefore, observe the following before recharging:
●If recharging with the battery installed on the vehicle, be sure to disconnect the
ground cable.
●Make sure the power switch on the charger is off when connecting and discon-
necting the charger cables to the battery.
■After recharging/reconnecting the battery
●Unlocking the doors using the smart key system may not be possible immedi-
ately after reconnecting the battery. If this happens, use the wireless remote
control or the mechanical key to lock/unlock the doors.
●Start the engine with the “ENGINE START STOP” switch in ACCESSORY
mode. The engine may not start with the “ENGINE START STOP” switch
turned OFF. However, the engine will operate normally from the second
attempt.
●The “ENGINE START STOP” switch mode is recorded by the vehicle. If the bat-
tery is reconnected, the vehicle will return the “ENGINE START STOP” switch
mode to the status it was in before the battery was disconnected. Make sure to
turn off the engine before disconnect the battery. Take extra care when con-
necting the battery if the “ENGINE START STOP” switch mode prior to dis-
charge is unknown.
If the system will not start even after multiple attempts, contact your Lexus dealer.
GX460_OM_OM60J63U_(U).book Page 632 Thursday, March 29, 2012 9:10 AM

634
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
CAUTION
■Emergency measures regarding electrolyte
●If electrolyte gets in your eyes
Flush your eyes with clean water for at least 15 minutes and seek immediate med-
ical attention. If possible, continue to apply water with a sponge or cloth while
traveling to the nearest medical facility.
●If electrolyte gets on your skin
Wash the affected area thoroughly. If you feel pain or a burning sensation, seek
medical attention immediately.
●If electrolyte gets on your clothes
It can soak through clothing on to your skin. Immediately take off the clothing and
follow the procedure above if necessary.
●If you accidentally swallow electrolyte
Drink a large quantity of water or milk. Get emergency medical attention imme-
diately.
NOTICE
■When recharging the battery
Never recharge the battery while the engine is running. Also, be sure all accesso-
ries are turned off.
GX460_OM_OM60J63U_(U).book Page 634 Thursday, March 29, 2012 9:10 AM

635
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Washer fluidIf any washer does not work or the
warning message appears on the
multi-information display, the
washer tank may be empty. Add
washer fluid.
CAUTION
■When refilling the washer fluid
Do not refill the washer fluid when the engine is hot or running, as the washer fluid
contains alcohol and may catch fire if spilled on the engine etc.
NOTICE
■Do not use any fluid other than washer fluid
Do not use soapy water or engine antifreeze instead of washer fluid.
Doing so may cause streaking on the vehicle’s painted surfaces.
■Diluting washer fluid
Dilute washer fluid with water as necessary.
Refer to the freezing temperatures listed on the label of the washer fluid bottle.
GX460_OM_OM60J63U_(U).book Page 635 Thursday, March 29, 2012 9:10 AM

650
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air condi-
tioning efficiency.
■ Removal method
Turn the “ENGINE START STOP” switch off.
Open the glove box and
remove the glove box cover.
Remove the filter cover.
Replace the filter with a new
one.
The “↑UP” marks shown on the
filter should be pointing up.
STEP1
STEP2
STEP3
STEP4
GX460_OM_OM60J63U_(U).book Page 650 Thursday, March 29, 2012 9:10 AM
