Page 89 of 98
89
GS450h_QG_U (OM30D12U)
■Rear door child-protector lock
The door cannot be op ened from inside the
vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent chil-
dren from opening the rear doors.
Push down on each rear door switch to
lock both rear doors.
Powe r Wi n d ows
■Po w e r w i n d o w s w i t c h e s
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: Pushing the switch in the opposite direc-
tion will stop window travel partway.
■ Window lock switch
Press the switch down to lock the passen-
ger window.
The indicator will come on.
Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
1
2
1
2
3
4
Indicator
Page 90 of 98
90
GS450h_QG_U (OM30D12U)
Moon Roof
■Opening and closing
Opens the moon roof*
The moon roof stops slightly before the
fully open position to reduce wind
noise.
Press the switch again to fully open the
moon roof.
Closes the moon roof
*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
■ Tilting up and down
Tilts the moon roof up*
Tilts the moon roof down*
*
: Lightly press either of the moon roof
switches to stop the moon roof partway.
1
2
1
2
Page 91 of 98
91
GS450h_QG_U (OM30D12U)
Fuel Tank Cap
■Before refueling the vehicle
● Close all the doors and windows, and turn the power switch off.
● Confirm the type of fuel.
■Opening the fuel tank cap
With the doors unlocked, press the
center of the rear ed ge of the fuel filler
door.
Push until you hear a click and take
your hand away to slightly open the fuel
filler door. Then open the door fully by
hand.
Turn the fuel tank cap slowly to open.
Hang the fuel tank cap on the back of
the fuel filler door.1
2
3
Page 92 of 98
92
GS450h_QG_U (OM30D12U)
Trunk
■Opening the trunk
● From inside the vehicle
Press the opener switch.If the vehicle is equipped with a power
trunk opener and closer, the trunk lid
automatically opens fully
Turn the main switch in the glove box off to
disable the trunk opener. On
Off
The trunk lid cannot be opened even with
the wireless remote control or the entry
function.
● From outside the vehicle
• Entry function
P.1 5
• Wireless remote control P.1 4
■Trunk easy closer (vehicles with power trunk opener and closer)
In the event that the trunk lid is left slightly open, the trunk easy closer will automatically
close it to the fully closed position.
■Trunk closer switch (vehicles with power trunk opener and closer)
Pressing the switch closes the trunk lid
automatically. (A buzzer sounds.)
Pressing the switch while the trunk lid is
closing opens the trunk lid again.
1
2
Page 93 of 98
What to do if...
93
GS450h_QG_U (OM30D12U)
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
Brake system warning light
(Canada)
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
Malfunction
indicator lamp
Slip indicator
(Canada)
(Flashes)
“AFS OFF” indicator
(if equipped)
SRS warning light
(Flashes)
Brake hold operated indicator
(U.S.A.)
ABS warning light(Flashes)(U.S.A.)
Parking brake
indicator
(Canada)
(Flashes)
(Canada)
Electric power steering
system warning lightBrake system warning light
(Flashes)“PCS” warning light
(if equipped)(Blinking and then
continu-
ously on)Tire pressure warning light
For further information, re fer to the Owner’s Manual.
Page 94 of 98
94
What to do if...
GS450h_QG_U (OM30D12U)
*: It also comes on due to natural causes such as natural air leaks and tire inflation pressure changes caused by temperature. Adjust the tire inflation pressure to the specified level.
The light will turn off after a few minutes. In case the light does not turn off even if the tire
inflation pressure is adjusted, have th e system checked by your Lexus dealer.
Follow the correction procedures.
Open door warning lightMaster warning light
Low fuel level warning light
(Illuminates
without
blinking)Tire pressure warning light*
Seat belt reminder light
For further information, re fer to the Owner’s Manual.
Page 95 of 98
What to do if...
95
GS450h_QG_U (OM30D12U)
See the Owner’s Manual
Turn signal indicatorIntuitive parking assist
indicator (if equipped)
Headlight indicator (U.S.A.)“A F S O F F ” i n d i c a t o r
(if equipped)
Tail light indicator (Canada)
(Flashes)
Slip indicator
Headlight high beam indicatorVSC OFF indicator
Front fog light indicator
(if equipped)
(Flashes faster)
“PCS” warning light
(if equipped)
“READY” indicatorParking brake indicator
(U.S.A.)
EV indicatorParking brake indicator
(Canada)
Cruise control indicatorBrake hold standby indicator
Radar cruise control
indicator (if equipped)Brake hold operated indicator
Cruise control “SET” indicator“A I R B A G O N /
OFF” indicator
LKA (Lane-Keeping assist)
indicator (if equipped)
For further information, re fer to the Owner’s Manual.
Page 96 of 98
96
What to do if...
GS450h_QG_U (OM30D12U)
If the electronic key does not operate properly
■Unlocking and locking the doors
Use the mechanical key in order to perform
the following operations:
Locks all the doors
Closes the windows and moon roof
*
(turn and hold)
Unlocks the door
Turning the key rearward unlocks the
driver’s door. Turning the key once
again within 5 seconds unlocks the
other doors.
Opens the windows and moon roof
*
(turn and hold)
*: This setting must be customized at yourLexus dealer.
■ Unlocking the trunk
Turn the mechanical key clockwise to open.
1
2
3
4
