1463-2. Opening, closing and locking the doors
CT200h_OM_OM76102E_(EE)
Note for the entry function
Even when the electronic key is within the effective range (detection areas), the
system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near
the ground, or in a high place when the doors are locked or unlocked.
• The electronic key is near the ground or in a high place, or too close to the
rear bumper center when the back door is opened.
• The electronic key is on the instrument panel, luggage room, floor, or in the
door pockets or glove box when the hybrid system is started or power switch
modes are changed.
Do not leave the electronic key on top of the instrument panel or near the door
pockets when exiting the vehicle. Depending on the radio wave reception con-
ditions, it may be detected by the antenna outside the cabin and the door will
become lockable from the outside, possibly trapping the electronic key inside
the vehicle.
As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone.
Even if the electronic key is not inside the vehicle, it may be possible to start
the hybrid system if the electronic key is near the window.
The doors may unlock if a large amount of water splashes on the door handle,
such as in the rain or in a car wash when the electronic key is within the effec-
tive range. (The door will automatically be locked after approximately 30 sec-
onds if the doors are not opened and closed.)
If the wireless remote control is used to lock the doors when the electronic key
is near the vehicle, there is a possibility that the door may not be unlocked by
the entry function. (Use the wireless remote control to unlock the doors.)
Touching the door lock sensor while wearing gloves may delay or prevent lock
operation. Remove the gloves and touch the lock sensor again.
If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. Place the key in a position 2 m
(6 ft.) or more separate from the vehicle while the vehicle is being washed.
(Take care to ensure that the key is not stolen.)
If the electronic key is inside the vehicle and a door handle becomes wet during
a car wash, a message may be shown on the multi-information display and a
buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors.
The lock sensor may not work properly if it comes into contact with ice, snow,
mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock
sensor on the lower part of the door handle.

1473-2. Opening, closing and locking the doors
3
Operation of each component
CT200h_OM_OM76102E_(EE)
A sudden approach to the effective range or door handle may prevent the doors
from being unlocked. In this case, return the door handle to the original position
and check that the doors unlock before pulling the door handle again.
If there is another electronic key in the detection area, it may take slightly lon-
ger to unlock the doors after the door handle is gripped.
Fingernails may scrape against the door during operation of the door handle. Be
careful not to injure fingernails or damage the surface of the door.
When the vehicle is not driven for extended periods
Vehicles with entry function: To prevent theft of the vehicle, do not leave the
electronic key within 2 m (6 ft.) of the vehicle.
The smart entry & start system can be deactivated in advance. (P. 650)
To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get the
electronic key too close to the vehicle when operating the system from the out-
side of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention may not operate.)
If the smart entry & start system does not operate properly
Locking and unlocking the doors: Use the mechanical key. (P. 621)
Starting the hybrid system: P. 6 2 2
Customization
Settings (e.g. smart entry & start system) can be changed.
(Customizable features: P. 650)
If the smart entry & start system has been deactivated in a customized setting
Locking and unlocking the doors:
Use the wireless remote control or mechanical key. (P. 132, 621)
Starting the hybrid system and changing power switch modes: P. 622
Stopping the hybrid system: P. 197

1653-3. Adjusting the seats
3
Operation of each component
CT200h_OM_OM76102E_(EE)
Each electronic key (including a card key) can be registered to recall your
preferred driving position.
Registering procedure
Record your driving position to button “1”, “2” or “3” before perform-
ing the following:
Carry only the key you want to register, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.
Turn the power switch to ON mode.
Check that the shift position is in P.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the door
lock switch (either lock or
unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds continu-
ously for approximately 3
seconds.
Recall procedure
Carry the electronic key that has been registered to the driving posi-
tion, and then unlock and open the driver’s door using the smart entry
& start system or wireless remote control.
The driving position will move to the recorded position.
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Memory recall function
1
2
3
4

1793-5. Opening, closing the windows and moon roof
3
Operation of each component
CT200h_OM_OM76102E_(EE)
The power windows can be operated when
The power switch is in ON mode.
Operating the power windows after turning the hybrid system off
The power windows can be operated for approximately 45 seconds even after the
power switch is turned to ACCESSORY mode or turned off. They cannot, how-
ever, be operated once either front door is opened.
Jam protection function
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.
When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on the
relevant door.
After stopping the vehicle, the window can be closed by holding the power
window switch in the one-touch closing position while the power switch is
turned to ON mode.
If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following procedure.
Hold the power window switch in the one-touch closing position. Continue
holding the switch for a further 6 seconds after the window has closed.
Hold the power window switch in the one-touch opening position. Continue
holding the switch for a further 2 seconds after the window has opened com-
pletely.
Hold the power window switch in the one-touch closing position once again.
Continue holding the switch for a further 2 seconds after the window has
closed.
If you release the switch while the window is moving, start again from the begin-
ning.
If the window continues to close but then re-open slightly even after performing
the above procedure correctly, have the vehicle inspected by any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
Door lock linked window operation
The power windows can be opened and closed using the mechanical key.*
(P. 621)
The power windows can be opened and closed using the wireless remote con-
trol.* (P. 132)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
Customization
Setting (e.g. linked door lock operation) can be changed.
(Customizable features:
P. 650)
1
2
3

5077-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
Before recharging
When recharging, the 12-volt battery produces hydrogen gas which is flammable
and explosive. Therefore, observe the following precautions before recharging:
If recharging with the 12-volt battery installed on the vehicle, be sure to discon-
nect the ground cable.
Make sure the power switch on the charger is off when connecting and discon-
necting the charger cables to the 12-volt battery.
After recharging/reconnecting the 12-volt battery
Unlocking the doors using the smart entry & start system may not be possible
immediately after reconnecting the 12-volt battery. If this happens, use the
wireless remote control or the mechanical key to lock/unlock the doors.
Start the hybrid system with the power switch in ACCESSORY mode. The
hybrid system may not start with the power switch turned off. However, the
hybrid system will operate normally from the second attempt.
The power switch mode is recorded by the vehicle. If the 12-volt battery is
reconnected, the vehicle will return the power switch mode to the status it was
in before the 12-volt battery was disconnected. Make sure to turn off the power
before disconnect the 12-volt battery. Take extra care when connecting the 12-
volt battery if the power switch mode prior to discharge is unknown.
Restart the hybrid system, depress the brake pedal, and confirm that it is possi-
ble to shift into each shift position.
If the system will not start even after multiple attempts at all methods above,
contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.

5337-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
Use a CR1632 lithium battery
Batteries can be purchased at any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional, local electrical appliance
shops or camera stores.
Replace only with the same or equivalent type recommended by the manufac-
turer.
Dispose of used batteries according to the local laws.
When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional can
replace the battery for you.
If the electronic key battery is depleted
The following symptoms may occur:
The smart entry & start system and wireless remote control will not function
properly.
The operational range will be reduced.
WA R N I N G
Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking.
Keep away from children. Failure to do so could result in death or serious
injury.
Certification for the smart entry & start system
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
NOTICE
For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
Always work with dry hands.
Moisture may cause the battery to rust.
Do not touch or move any other component inside the remote control.
Do not bend either of the battery terminals.

6228-2. Steps to take in an emergency
CT200h_OM_OM76102E_(EE)
If the electronic key does not operate properly
Use the mechanical key (P. 127)
in order to perform the following
operations:
Locks all the doors
Closes the windows
* (turn and
hold)
Unlocks all the doors
Opens the windows
* (turn and
hold)
*: These settings must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
If communication between the electronic key and vehicle is interrupted (P.
145) or the electronic key cannot be used because the battery is depleted, the
smart entry & start system and wireless remote control cannot be used. In
such cases, the doors can be opened and the hybrid system can be started by
following the procedure below.
Locking and unlocking the doors and key linked functions
1
2
3
4

6539-2. Customization
CT200h_OM_OM76102E_(EE)
9
Vehicle specifications
Smart entry & start system* and wireless remote control (P. 143,
126)
*: If equipped
Smart entry & start system* (P. 143)
*: If equipped
FunctionDefault
settingCustomized
setting
Operation signal (emer-
gency flashers)OnOffO–OO
Time elapsed before the
automatic door lock func-
tion is activated if a door is
not opened after being
unlocked
30 seconds
60 seconds
–––O
120 seconds
Open door reminder buzzer
(When locking the vehicle)OnOff–––O
1234
FunctionDefault
settingCustomized
setting
Smart door unlocking All the doors Driver’s door O – O O
Smart entry & start system On Off O – O O
1234
