2013 INFINITI G SEDAN warning light

Black plate (7,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
0 Illustrated table of contents
Seats, seat belts and Supplemental Restraint
System (SRS)...
....................................................... 0-2
Exterior front ...
....................................................... 0-3
Sedan ...
............................................................. 0-3
Coupe ...
............................................................. 0-4
Exterior rear ...
......................................................... 0-5
Sedan ...
............................................................. 0-5
Coupe ...
............................................................. 0-6
Exterior (INFINITI Performance Line model
- Coupe) ...
.............................................................. 0-7 Passenger compartment
...
...................................... 0-8
Sedan ...
............................................................ 0-8
Coupe ...
............................................................ 0-9
Cockpit ...
.............................................................. 0-10
Instrument panel ...
............................................... 0-11
Meters and gauges ...
........................................... 0-13
Engine compartment ...
......................................... 0-14
VQ37VHR engine ...
......................................... 0-14
Warning and indicator lights ...
............................. 0-15
Condition:

Black plate (17,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
GUID-5BF1CCAC-1271-471E-83A1-FF109419BE46
SSI0671
1. Side ventilator (P.4-30)
2. Meters and gauges (P.2-6)
3. Center ventilator (P.4-30)
4. Audio system (P.4-41)
5. Clock (P.2-42)6. Center multi-function control panel
(P.4-3)
—Navigation system* (if so
equipped)
— Vehicle information and setting
buttons (P.4-9) —
Bluetooth
®Hands-Free Phone Sys-
tem (if so equipped) (P.4-85, P.4-96)
— Audio system (P.4-41)
7. Center display (P.4-3)/Navigation sys- tem* (if so equipped)
8. Hazard warning flasher switch (P.6-2)
9. Front passenger supplemental air bag (P.1-41)
10. Fuse box cover (P.8-24)
11. Parking brake (for Automatic Trans- mission models)
—Parking (P.5-21)
12. Push-button ignition switch (P.5-9)
13. Automatic climate control system (P.4-31)
14. Cigarette lighter and ashtray (if so equipped) (P.2-43) or storage box (if
so equipped) (P.2-49)
—Power outlet (if so equipped)
(P.2-42)
15. Parking brake (for Manual Transmis- sion models)
—Parking (P.5-21)
16. Heated seat switch (if so equipped) (P.2-40)
17. SNOW mode switch (if so equipped) (P.2-41)
Illustrated table of contents0-11
INSTRUMENT PANEL
Condition:

Black plate (19,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
GUID-E8D7EED7-37CE-4B5F-8ECB-479CB10AB8D6
SIC4288
1. Tachometer (P.2-8)
2. Warning/Indicator lights (P.2-12)
3. Speedometer (P.2-7)
4. Engine coolant temperature gauge(P.2-8) 5.
Dot matrix liquid crystal display/
Odometer/twin trip odometer
(P.2-20)
6. Fuel gauge (P.2-9)
Illustrated table of contents0-13
METERS AND GAUGES
Condition:

Black plate (21,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
GUID-20167C10-9FEC-49A8-BD90-B52F0ED487EA
Warninglight Name
Page
All-Wheel Drive (AWD) warning
light (AWD models)* 2-12
Anti-lock Braking System (ABS)
warning light2-13
Automatic Transmission check
warning light
2-13
Brake warning light
2-13
Charge warning light2-14
Engine oil pressure warning
light 2-14
4 Wheel Active Steer (4WAS)
warning light*
2-14
Intelligent Cruise Control (ICC)
system warning light (orange)*2-15
Intelligent Key warning light 2-15
Low tire pressure warning light 2-15
Master warning light
2-16
Preview Function warning light
(orange)* 2-16
Seat belt warning light 2-17
Supplemental air bag warning
light2-17Warning
light Name
Page
Vehicle Dynamic Control (VDC)
warning light 2-17
Indicator light Name
Page
Automatic Transmission posi-
tion indicator light* 2-18
Exterior light indicator
2-18
Front fog light indicator light 2-18
Front passenger air bag status
light 2-18
High beam indicator light 2-18
Malfunction Indicator Light
(MIL)2-18
Security indicator light 2-19
Turn signal/hazard indicator
lights2-19
Vehicle Dynamic Control (VDC)
off indicator light2-19
*: if so equipped
Illustrated table of contents0-15
WARNING AND INDICATOR LIGHTS
Condition:

Black plate (23,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
1 Safety—Seats, seat belts and supplemental
restraint system
Seats ...
................................................................... 1-2
Front seats ...
...................................................... 1-3
Rear seats ...
....................................................... 1-7
Head restraints (front seats) ...
............................ 1-9
Head restraints (rear seats) ...
........................... 1-13
Armrest (if so equipped) ...
................................ 1-13
Seat belts ...
.......................................................... 1-14
Precautions on seat belt usage ...
..................... 1-14
Pregnant women ...
........................................... 1-17
Injured persons ...
............................................. 1-17
Pre-crash seat belts (front seats) (if
so equipped) ...
................................................. 1-17
Three-point type seat belt ...
............................. 1-17
Seat belt extenders ...
....................................... 1-21
Seat belt maintenance ...
................................... 1-21
Child safety ...
....................................................... 1-22
Infants ...
........................................................... 1-22
Small children ...
............................................... 1-23
Larger children ...
.............................................. 1-23
Child restraints ...
.................................................. 1-24
Precautions on child restraints ...
...................... 1-24
Lower Anchors and Tethers for CHildren
System (LATCH) ...
............................................. 1-26 Rear-facing child restraint installation
using LATCH
...
................................................. 1-28
Rear-facing child restraint installation using
the seat belts ...
.............................................. 1-30
Forward-facing child restraint installation
using LATCH ...
................................................. 1-32
Forward-facing child restraint installation
using the seat belts ...
..................................... 1-34
Installing top tether strap ...
............................ 1-37
Booster seats ...
.............................................. 1-38
Supplemental restraint system ...
.......................... 1-41
Precautions on supplemental
restraint system ...
........................................... 1-41
INFINITI Advanced Air Bag System
(front seats) ...
................................................. 1-47
Front seat-mounted side-impact
supplemental air bag and roof-mounted
curtain side-impact supplemental air
bag systems ...
................................................ 1-52
Seat belts with pretensioners (front seats) ...
.... 1-54
Supplemental air bag warning labels ...
........... 1-55
Supplemental air bag warning light ...
............. 1-55
Repair and replacement procedure ...
............... 1-56
Condition:

Black plate (38,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
1-16Safety—Seats, seat belts and supplemental restraint system
. Do not wear the seat belt inside out or
twisted. Doing so may reduce its effec-
tiveness.
. Do not allow more than one person to
use the same seat belt.
. Never carry more people in the vehicle
than there are seat belts.
. If the seat belt warning light glows
continuously while the ignition is turned
ON with all doors closed and all seat
belts fastened, it may indicate a mal-
function in the system. Have the system
checked by an INFINITI retailer.
. No changes should be made to the seat
belt system. For example, do not modify
the seat belt, add material or install
devices that may change the seat belt
routing or tension. Doing so may affect
the operation of the seat belt system.
Modifying or tampering with the seat
belt system may result in serious perso-
nal injury.
. Once a seat belt pretensioner has
activated, it cannot be reused and must
be replaced together with the retractor.
See an INFINITI retailer.
. Removal and installation of the preten-
sioner system components should be done by an INFINITI retailer.
. All seat belt assemblies, including re-
tractors and attaching hardware, should
be inspected after any collision by an
INFINITI retailer. INFINITI recommends
that all seat belt assemblies in use
during a collision be replaced unless
the collision was minor and the belts
show no damage and continue to oper-
ate properly. Seat belt assemblies not in
use during a collision should also be
inspected and replaced if either damage
or improper operation is noted.
. All child restraints and attaching hard-
ware should be inspected after any
collision. Always follow the restraint
manufacturer’s inspection instructions
and replacement recommendations. The
child restraints should be replaced if
they are damaged.
SSS0016
SSS0014
Condition:

Black plate (39,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
PREGNANT WOMENGUID-AF3C2DF0-16F5-464E-B1C9-A2B02DF135AEINFINITI recommends that pregnant women
use seat belts. The seat belt should be
worn snug, and always position the lap
belt as low as possible around the hips,
not the waist, and place the shoulder belt
over your shoulder and across your chest.
Never run the lap/shoulder belt over your
abdominal area. Contact your doctor for
specific recommendations.
INJURED PERSONSGUID-3574EA04-0EC7-407F-8299-5666BD2D1B17INFINITI recommends that injured persons
use seat belts, depending on the injury.
Check with your doctor for specific recom-
mendations.
PRE-CRASH SEAT BELTS (front
seats) (if so equipped)
GUID-E8B8D974-2162-458D-A2F5-F4343FCA4064The pre-crash seat belt tightens the seat
belt to help restrain front seat occupants
under emergency braking. This can help
reduce the risk of injury when a collision
occurs.
Pre-crash seat belt will not be activated
when:
.the brake pedal is not depressed
. the seat belt is not fastened .
the vehicle speed is under 10 MPH (15
km/h)
Always wear your seat belt correctly and sit
upright and well back.
If the seat belt warning light blinks even if
the driver’s and front passenger’s seat
belts are fastened, it may indicate the pre-
crash seat belt system has a malfunction.
Have your INFINITI retailer check and repair
the system.
THREE-POINT TYPE SEAT BELTGUID-30E039F3-1C1F-4413-811C-DE74575ADD15
WARNING
. Every person who drives or rides in this
vehicle should use a seat belt at all
times.
. Do not ride in a moving vehicle when the
seatback is reclined. This can be danger-
ous. The shoulder belt will not be
against your body. In an accident, you
could be thrown into it and receive neck
or other serious injuries. You could also
slide under the lap belt and receive
serious internal injuries.
. For the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back in the seat with both feet on the floor and
adjust the seat belt properly.
. Do not allow children to play with the
seat belts. Most seating positions are
equipped with Automatic Locking Re-
tractor (ALR) mode seat belts. If the seat
belt becomes wrapped around a child’s
neck with the ALR mode activated, the
child can be seriously injured or killed if
the seat belt retracts and becomes tight.
This can occur even if the vehicle is
parked. Unbuckle the seat belt to release
the child. If the seat belt can not be
unbuckled or is already unbuckled,
release the child by cutting the seat belt
with a suitable tool (such as a knife or
scissors) to release the seat belt.
Safety —Seats, seat belts and supplemental restraint system1-17
Condition:

Black plate (52,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
1-30Safety—Seats, seat belts and supplemental restraint system
applicable). Not all child restraints fit in
all types of vehicles.
5. Check to make sure the child restraint is properly secured prior to each use. If
the child restraint is loose, repeat steps
1 through 4.
REAR-FACING CHILD RESTRAINT IN-
STALLATION USING THE SEAT BELTS
GUID-68D5DDB8-3F24-4C65-922C-6DD7B90A7477
WARNING
The three-point seat belt with Automatic
Locking Retractor (ALR) must be used when
installing a child restraint. Failure to use the
ALR mode will result in the child restraint
not being properly secured. The restraint
could tip over or be loose and cause injury
to a child in a sudden stop or collision. Also,
it can change the operation of the front
passenger air bag. See “Front passenger air
bag and status light” (P.1-49).SSS0100
Rear-facing—step 1
Refer to all Warnings and Cautions in the
“Child safety” (P.1-22) and“Child re-
straints” (P.1-24) before installing a child
restraint.
Follow these steps to install a rear-facing
child restraint using the vehicle seat belts
in the rear seats:
1. Child restraints for infants must be
used in the rear-facing direction and
therefore must not be used in the front
seat. Position the child restraint on the
seat. Always follow the restraint man-
ufacturer’s instructions.
SSS0654
Rear-facing —step 2
2. Route the seat belt tongue through the
child restraint and insert it into the
buckle until you hear and feel the latch
engage. Be sure to follow the child
restraint manufacturer’s instructions
for belt routing.
Condition:
