2013 INFINITI G SEDAN Owner's Manual

Black plate (448,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
8-44Maintenance and do-it-yourself
placed with tires of the same size, brand,
construction and tread pattern. The tire
pressure and wheel alignment should also
be checked and corrected as necessary.
Contact an INFINITI retailer.
Wheel balanceGUID-E8819382-6D86-409C-A6FD-5113A53508ABUnbalanced wheels may affect vehicle
handling and tire life. Even with regular
use, wheels can get out of balance. There-
fore, they should be balanced as required.
Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to mechanical damage.
For additional information regarding tires,
refer to“Important Tire Safety Information”
(US) or “Tire Safety Information” (Canada)
in the INFINITI Warranty Information Book-
let.
Care of wheelsGUID-C1AC6B0A-3969-4BA4-85FF-DEEAE1EBA8ABSee “Cleaning exterior” (P.7-2) for details
about care of the wheels.
Spare tire (TEMPORARY USE ONLY
(T-type) spare tire)
GUID-3D33E4D2-DC59-460C-941C-8160D646B5B6Observe the following precautions if the T-
type spare tire must be used, otherwise your vehicle could be damaged or involved
in an accident.
WARNING
.
The T-type spare tire should be used for
emergency use. It should be replaced
with the standard tire at the first
opportunity to avoid possible tire or
differential damage.
. Drive carefully while the TEMPORARY
USE ONLY spare tire is installed. Avoid
sharp turns and abrupt braking while
driving.
. Periodically check spare tire inflation
pressure. Always keep the pressure of
the TEMPORARY USE ONLY spare tire at
60 psi (420 kPa, 4.2 bar). Always keep
the pressure of the full size spare tire (if
so equipped) at the recommended pres-
sure for standard tires, as indicated on
the Tire and Loading Information label.
For Tire and Loading Information label
location, see “Tire and Loading Informa-
tion label” in the index of this manual.
. With the TEMPORARY USE ONLY spare
tire installed do not drive your vehicle at
speeds faster than 50 MPH (80 km/h). .
When driving on roads covered with
snow or ice, the TEMPORARY USE ONLY
spare tire should be used on the front
wheels and original tire used on the rear
wheels (drive wheels). Use tire chains
only on the two rear original tires.
. Tire tread of the TEMPORARY USE ONLY
spare tire will wear at a faster rate than
the standard tire. Replace the spare tire
as soon as the tread wear indicators
appear.
. Do not use the spare tire on other
vehicles.
. Do not use more than one spare tire at
the same time.
CAUTION
.Do not use tire chains on a TEMPORARY
USE ONLY spare tire. Tire chains will not
fit properly and may cause damage to
the vehicle.
. Because the TEMPORARY USE ONLY
spare tire is smaller than the original
tire, ground clearance is reduced. To
avoid damage to the vehicle, do not
drive over obstacles. Also do not drive
Condition:

Black plate (449,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
the vehicle through an automatic car
wash since it may get caught.
Maintenance and do-it-yourself8-45
Condition:

Black plate (450,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
8-46Maintenance and do-it-yourself
MEMO
Condition:

Black plate (451,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
9 Technical and consumer information
Capacities and recommended fuel/lubricants...
....... 9-2
Fuel information ...
.............................................. 9-4
Engine oil and oil filter recommendation ...
......... 9-6
Air conditioning system refrigerant and
lubricant recommendations ...
............................. 9-7
Specifications ...
...................................................... 9-8
Engine ...
............................................................. 9-8
Wheels and tires ...
............................................. 9-9
Dimensions ...
................................................... 9-10
When traveling or registering your vehicle in
another country ...
................................................. 9-11
Vehicle identification ...
......................................... 9-11
Vehicle Identification Number (VIN) plate ...
....... 9-11
Vehicle identification number
(chassis number) ...
........................................... 9-12
Engine serial number ...
.................................... 9-12
F.M.V.S.S./C.M.V.S.S. certification label ...
.......... 9-13
Emission control information label ...
................ 9-13
Tire and Loading Information label ...
................ 9-13
Air conditioner specification label ...
.................. 9-14
Installing front license plate ...
.............................. 9-14
Sedan ...
........................................................... 9-15 Coupe (except for INFINITI Performance
Line model)
...
................................................. 9-16
Coupe (INFINITI Performance Line model) ...
..... 9-18
Vehicle loading information ...
............................... 9-19
Terms ...
.......................................................... 9-19
Vehicle load capacity ...
................................... 9-20
Loading tips ...
................................................. 9-21
Measurement of weights ...
.............................. 9-22
Towing a trailer ...
................................................. 9-22
Flat towing ...
................................................... 9-22
Uniform tire quality grading ...
.............................. 9-23
Treadwear ...
.................................................... 9-23
Traction AA, A, B and C ...
................................ 9-23
Temperature A, B and C ...
............................... 9-23
Emission control system warranty ...
..................... 9-24
Reporting safety defects ...
.................................... 9-25
Readiness for Inspection/Maintenance (I/M) test
(US only) ...
........................................................... 9-26
Event Data Recorders (EDR) ...
............................... 9-26
Owner’s Manual/Service Manual
order information ...
.............................................. 9-27
Condition:

Black plate (452,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
9-2Technical and consumer information
GUID-83DC73A1-0226-4579-85B6-0002CD56C740The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the“8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended specifications
US measure Imp measure Liter
Fuel 20 gal 16-5/8 gal 76 See “Fuel information”(P.9-4).
Engine oil*1 .Engine oil with API Certification Mark*2*3
. Viscosity SAE 5W-30
Drain and refill
With oil filter change 5-1/8 qt 4-3/8 qt 4.9
Without oil filter change 4-7/8 qt 4 qt 4.6
Cooling system
Automatic transmission
model With reservoir 9 qt 7-1/2 qt 8.5
Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent
Reservoir 7/8 qt 3/4 qt 0.8
Manual transmission model With reservoir 9-1/2 qt 7-7/8 qt 9.0
Reservoir
7/8 qt3/4 qt 0.8
Automatic transmission fluid ———Genuine NISSAN Matic S ATF*4
Manual transmission gear oil ———Genuine NISSAN Manual Transmission Fluid (MTF) HQ Multi 75W-85 or API GL-4,
Viscosity SAE 75W-85
Differential gear oil ———For 7A/T 2WD models:
API GL-5 Synthetic Gear Oil Viscosity SAE 75W-90*5
All other models:
Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-90 or API GL-5, Viscosity SAE
80W-90*6
Transfer fluid ———Genuine NISSAN Matic J ATF*7
Power steering fluid (PSF) Refill to the proper oil level according to the instructions in the “8.
Maintenance and do-it-yourself” section. Genuine NISSAN PSF or equivalent*8
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*9 or equivalent DOT 3
Multi-purpose grease Without limited slip differential ———
NLGI No. 2 (Lithium soap base)
With limited slip differential ———
Air conditioning system refrigerant ———HFC-134a (R-134a)*10
Air conditioning system lubricants ———NISSAN A/C System Oil Type S or exact equivalent
Window washer fluid ———Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1:
For additional information, see “Engine oil”(P.8-11) for changing engine oil.*2:INFINITI recommends Genuine NISSAN Ester Engine Oil available at an INFINITI retailer.
CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS
Condition:

Black plate (453,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
*3:For additional information, see“Engine oil and oil filter recommendation” (P.9-6).*4:Using automatic transmission fluid other than Genuine NISSAN Matic S ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic
transmission, which is not covered by the INFINITI new vehicle limited warranty.
*5:See an INFINITI retailer for service for synthetic oil.*6:For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 328F (08C).*7:Using transfer fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and transfer durability, and may damage the transfer, which is not covered by the INFINITI new
vehicle limited warranty.
*8:DEXRONTMVI type ATF may also be used.*9:Available in mainland USA through an INFINITI retailer.*10:For additional information, see“Vehicle identification”(P.9-11) for air conditioner specification label.
Technical and consumer information9-3
Condition:

Black plate (454,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
9-4Technical and consumer information
FUEL INFORMATIONGUID-FD3A9510-2D82-4C2F-81D2-3EECA4BDE202
VQ37VHR engineGUID-62D6EF4E-F486-46EA-A1E0-D4BB9121EA3AUse unleaded premium gasoline with an
octane rating of at least 91 AKI (Anti-Knock
Index) number (Research octane number
96).
If premium gasoline is not available,
unleaded regular gasoline with an octane
rating of 87 AKI number (Research octane
number 91) may be temporarily used, but
only under the following precautions:
.Have the fuel tank filled only partially
with unleaded regular gasoline, and fill
up with unleaded premium gasoline as
soon as possible.
. Avoid full throttle driving and abrupt
acceleration.
Use unleaded premium gasoline for max-
imum vehicle performance.
CAUTION
. Using a fuel other than that specified
could adversely affect the emission
control system, and may also affect
warranty coverage. .
Under no circumstances should a leaded
gasoline be used, because this will
damage the three-way catalyst.
. Do not use E-15 or E-85 fuel in your
vehicle. Your vehicle is not designed to
run on E-15 or E-85 fuel. Using E-15 or E-
85 fuel in a vehicle not specifically
designed for E-15 or E-85 fuel can
adversely affect the emission control
devices and systems of the vehicle.
Damage caused by such fuel is not
covered by the INFINITI new vehicle
limited warranty.
. U.S. government regulations require
ethanol dispensing pumps to be identi-
fied by a small, square, orange and black
label with the common abbreviation or
the appropriate percentage for that
region.
Gasoline specificationsGUID-E8A76FAE-F1E8-41BA-ACCF-E439B6733579INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter (WWFC)
specifications where it is available. Many
of the automobile manufacturers devel-
oped this specification to improve emis-
sion system and vehicle performance. Ask
your service station manager if the gaso- line meets the World-Wide Fuel Charter
(WWFC) specifications.
Reformulated gasolineGUID-21D3DE2D-574C-45D2-AE5B-28DCCCBF286CSome fuel suppliers are now producing
reformulated gasolines. These gasolines
are specially designed to reduce vehicle
emissions. INFINITI supports efforts to-
wards cleaner air and suggests that you
use reformulated gasoline when available.
Gasoline containing oxygenatesGUID-ABC4FC82-F0F7-44E4-BDD3-2D84252E0A47Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, MTBE and
methanol with or without advertising their
presence. INFINITI does not recommend the
use of fuels of which the oxygenate content
and the fuel compatibility for your INFINITI
cannot be readily determined. If in doubt,
ask your service station manager.
If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
performance problems and/or fuel system
damage.
.
The fuel should be unleaded and have
an octane rating no lower than that
recommended for unleaded gasoline.
Condition:

Black plate (455,1)
[ Edit: 2012/ 7/ 6 Model: V36-D ]
.If an oxygenate-blend, excepting a
methanol blend, is used, it should
contain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)
. E-15 fuel contains more than 10%
oxygenate. E-15 fuel will adversely
affect the emission control devices
and systems of the vehicle and should
not be used. Damage caused by such
fuel is not covered by the INFINITI new
vehicle limited warranty.
. If a methanol blend is used, it should
contain no more than 5% methanol
(methyl alcohol, wood alcohol). It
should also contain a suitable amount
of appropriate cosolvents and corro-
sion inhibitors. If not properly formu-
lated with appropriate cosolvents and
corrosion inhibitors, such methanol
blends may cause fuel system damage
and/or vehicle performance problems.
At this time, sufficient data is not
available to ensure that all methanol
blends are suitable for use in INFINITI
vehicles.
If any undesirable driveability problems
such as engine stalling or hard hot starting
are experienced after using oxygenate- blend fuels, immediately change to a
non-oxygenate fuel or a fuel with a low
blend of MTBE.
Take care not to spill gasoline during
refueling. Gasoline containing oxygenates
can cause paint damage.
E-15 fuelGUID-926048B6-9F6A-457D-B048-67135BCCC7F6E-15 fuel is a mixture of approximately
15% fuel ethanol and 85% unleaded
gasoline. E-15 can only be used in vehicles
designed to run on E-15 fuel. Do not use E-
15 in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified with small, square,
orange and black label with the common
abbreviation or the appropriate percentage
for that region.
E-85 fuelGUID-BE764F0C-6A10-497C-B4F9-CD1D0E122DA3E-85 fuel is a mixture of approximately
85% fuel ethanol and 15% unleaded
gasoline. E-85 can only be used in a
Flexible Fuel Vehicle (FFV). Do not use E-
85 fuel in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified by a small, square,
orange and black label with the common
abbreviation or the appropriate percentage
for that region.
Aftermarket fuel additivesGUID-663D952D-0F24-4D6E-ABBF-21302053695CINFINITI does not recommend the use of
any aftermarket fuel additives (Example:
fuel injector cleaner, octane booster, intake
valve deposit removers, etc.) which are
sold commercially. Many of these additives
intended for gum, varnish or deposit
removal may contain active solvent or
similar ingredients that can be harmful to
the fuel system and engine.
Octane rating tipsGUID-527A0AB1-299D-45DA-9B92-4DDA2444B93CUsing unleaded gasoline with an octane
rating lower than recommended above can
cause persistent, heavy spark knock.
(Spark knock is a metallic rapping noise.)
If severe, this can lead to engine damage.
If you detect a persistent heavy spark
knock even when using gasoline of the
stated octane rating, or if you hear steady
spark knock while holding a steady speed
on level roads, have an INFINITI retailer
correct the condition. Failure to correct the
condition is misuse of the vehicle, for
which INFINITI is not responsible.
Incorrect ignition timing will result in
knocking, after-run or overheating. This in
turn may cause excessive fuel consumption
or damage to the engine. If any of the
Technical and consumer information9-5
Condition:
