395Handling the Unexpected
Shift Lever Does Not MoveFollow the procedure below if you cannot move the shift lever out of the
(P

position.
1.Set the parking brake.
2.Remove the key from the ignition switch.
3.Wrap a cloth around the tip of a small flat-
tip screwdriver. Put it into the shift lock
release slot as shown in the image, and
remove the cover.
4.Insert the key into the shift lock release slot.
5.While pushing the key in, press the shift
lever release button and place the shift lever
into
(N
.
uThe lock is now released. Have the shift
lever checked by a dealer as soon as
possible.
■
Releasing the Lock
Slot
Cover
Release
Button
Shift Lock
Release Slot

405
uuFusesuFuse Locations
Continued
Handling the Unexpected
Located under the dashboard.
Fuse locations are shown on the label on
the side panel.
Locate the fuse in question by the fuse
number and label number.■
Driver Side Fuse Box
Fuse Label
■Circuit protected and fuse rating
Circuit Protected
Amps
1
Door Lock Motor 1 (Lock)
7.5 A
2
Door Lock Motor 2 (Lock)
7.5 A
3
Driver’s Door Lock Motor
(Lock)
7.5 A
4
Door Lock Motor 1 (Unlock)
7.5 A
5
Door Lock Motor 2 (Unlock)
7.5 A
6
Driver’s Door Unlock
7.5 A
7
Door Lock Main
20 A
8
Not Used
−
9
Driver’s Side Power Slide
Door Closer
*
20 A
10 Rear Fuse Box 15 A
11
Meter
7.5 A
12Primary Under-hood Fuse
Box20 A
13
Accessory
7.5 A
14 STS 7.5 A
15
Driver’s Power Seat Sliding
20 A
16 Moonroof
*
20 A
17
Rear Left Power Window
20 A
18 − −
19
Driver’s Power Window
20 A
20 − −
21
Fuel Pump
20 A
22 Passenger’s Side Fuse Box 15 A
23
VSA
7.5 A
24 ACG AS 7.5 A25
STRLD
7.5 A
26 HAC 7.5 A
27
DRL
7.5 A
28 ACC Key Lock 7.5 A
29
Driver’s Power Seat
*
Lumbar Support
7.5 A
30 TPMS 7.5 A
31
−
−
32Driver’s Power Seat
Reclining20 A
33
Driver’s Side Power Slide
Door Motor
*
40 A
34 − −
Circuit Protected
Amps
* Not available on all models

427Index
Keys........................................................ 109
Locking/Unlocking the Doors
from the Inside...................................... 113
Locking/Unlocking the Doors
from the Outside................................... 111
Lockout Prevention System ..................... 112
DOT Tire Quality Grading........................ 365
Driving...................................................... 279
Automatic Transmission .......................... 294
Braking ................................................... 308
Cruise Control ........................................ 297
Shifting Gear .......................................... 295
Starting the Engine ................................. 291
Driving Position Memory System............ 148
Dust and Pollen Filter.............................. 376EElapsed Time........................................ 92, 99
Electronic Stability Control (ESC)............ 300
Emergency................................................ 409
Emissions Testing (Readiness Codes)...... 417
Engine....................................................... 414
Coolant .................................................. 342
Jump Starting ......................................... 393
Oil .......................................................... 337
Starting................................................... 291
Switch Buzzer ......................................... 140
Engine Coolant........................................ 342
Adding to the Radiator ........................... 343
Adding to the Reserve Tank .................... 342Overheating ............................................ 396
Temperature Gauge .................................. 86
Engine Oil................................................. 337
Adding .................................................... 339
Checking ................................................. 338
Displaying Oil Life ............................ 327, 331
Low Oil Pressure Indicator.................. 72, 398
Recommended Engine Oil........................ 337
Exhaust Gas Hazard
(Carbon Monoxide).................................. 68
Exterior Care (Cleaning)........................... 379
Exterior Mirrors........................................ 152
FFeatures..................................................... 193
Filters
Dust and Pollen ....................................... 376
Oil ........................................................... 340
Flat Tire..................................................... 383
Flip-up Trash Bag Ring............................. 171
Floor Mats................................................. 378
Fluids
Automatic Transmission........................... 344
Brake....................................................... 345
Engine Coolant........................................ 342
Power Steering ........................................ 346
Windshield Washer.................................. 346
Fog Light Indicator..................................... 80
Folding Down the Rear Seats.......... 161, 165
Foot Brake................................................. 309Front Airbags (SRS)..................................... 42
Front Seats................................................ 153
Adjusting ................................................ 153
Fuel...................................................... 17, 318
Economy ................................................. 321
Gauge ....................................................... 86
Instant Fuel Economy .................... 88, 92, 99
Low Fuel Indicator ..................................... 75
Range ........................................... 88, 92, 99
Recommendation .................................... 318
Refueling................................................. 318
Fuel Economy........................................... 321
Fuel Fill Cap........................................ 17, 320
Message.................................................. 399
Fuel Fill Door...................................... 17, 319
Fuses.......................................................... 403
Inspecting and Changing......................... 408
Locations................. 403, 404, 405, 406, 407
GGasoline (Fuel)
Economy ................................................. 321
Gauge ....................................................... 86
Information ............................................. 318
Instant Fuel Economy .................... 88, 92, 99
Low Fuel Indicator ..................................... 75
Refueling................................................. 318
Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 295

429Index
Integrated Sunshades.............................. 181
Interior Lights........................................... 168
Interior Rearview Mirror......................... 151JJack (Wheel Nut Wrench)........................ 386
Jump Starting........................................... 393KKey Number Tag...................................... 110
Keyless Lockout Prevention..................... 112
Keys........................................................... 109
Lockout Prevention ................................. 112
Master Keys ............................................ 109
Number Tag............................................ 110
Rear Door Won’t Open ........................... 114
Remote Transmitter ................................ 111
Types and Functions................................ 109
Valet Key ................................................ 110
Won’t Turn ............................................... 20
Kickdown (Automatic Transmission)...... 294LLanguage (HFL)........................................ 255
LATCH (Child Seats)................................... 59
Lights................................................ 141, 347
Automatic............................................... 142
Bulb Replacement ................................... 347
Daytime Running Lights .......................... 143Fog Lights................................................ 143
High Beam Indicator .................................. 79
Interior .................................................... 168
Light Switches ......................................... 141
Lights On Indicator .................................... 79
Turn Signals............................................. 141
Load Limits................................................ 283
Locking/Unlocking.................................... 109
Auto Door Locking/Unlocking .................. 115
Childproof Door Locks ............................. 114
From Inside.............................................. 113
From Outside........................................... 111
Keys ........................................................ 109
Using a Key ............................................. 112
Lockout Prevention System...................... 112
Low Battery Charge.................................. 398
Low Fuel Indicator...................................... 75
Low Oil Pressure Indicator................. 72, 398
Lower Anchors............................................ 59
Luggage (Maximum Load Limit)............. 283
MMaintenance............................................. 323
Battery .................................................... 371
Brake Fluid .............................................. 345
Cleaning.................................................. 377
Climate Control System ........................... 376
Coolant ................................................... 342
Heating and Cooling System.................... 376
Maintenance Minder™............................ 327Oil ........................................................... 338
Power Steering Fluid................................ 346
Precautions ............................................. 324
Radiator .................................................. 343
Remote Control and Wireless
Headphone ........................................... 374
Remote Transmitter ................................. 372
Replacing Light Bulbs .............................. 347
Safety...................................................... 325
Service Items ................................... 329, 333
Tires ........................................................ 362
Transmission Fluid ................................... 344
Under the Hood ...................................... 335
Malfunction Indicator Lamp.............. 73, 399
Map Lights................................................ 169
Maximum Load Limit............................... 283
Meters, Gauges........................................... 86
Mirrors...................................................... 151
Adjusting ................................................ 151
Door ....................................................... 152
Exterior ................................................... 152
Interior Rearview ..................................... 151
Modifications (and Accessories).............. 322
Moonroof................................................. 139
MP3................................................... 207, 221
Multi-Information Display......................... 98
NNumbers (Identification).......................... 414

432Index
Noise When Braking .................................. 21
Overheating............................................. 396
Puncture/Flat Tire ..................................... 383
Select Lever Won’t Move ......................... 395
Sliding Door Won’t Open................... 20, 114
Warning Indicators .................................... 72
Tucking away the One-Motion Third row
magic Seat............................................... 165
Turn Signals............................................... 141
Indicators (Instrument Panel) ...................... 79UUnlocking the Doors................................. 111
Unlocking the Front Doors
from the Inside........................................ 113
USB Adapter Cable........................... 194, 195
USB Flash Drives........................................ 235VValet Key................................................... 110
Vanity Mirrors............................................... 5
Vehicle Identification Number................. 414
Vehicle Stability Assist (VSA®).................. 300
Off Button ............................................... 301
Off Indicator .............................................. 76
System Indicator ........................................ 76
Ventilation........................................ 182, 186
Viscosity (Oil)..................................... 337, 413
VSA® (Vehicle Stability Assist).................. 300
WWallpaper................................................... 94
Warning and Information Messages......... 84
Warning Indicator On/Blinking............... 398
Warning Labels........................................... 69
Warranties (Warranty Manual provided
separately).............................................. 419
Watts......................................................... 412
Wear Indicators (Tire).............................. 367
Wheel Cover............................................. 387
Wheel Nut Wrench (Jack Handle)........... 386
Window Washers..................................... 144
Adding/Refilling Fluid .............................. 346
Switch ..................................................... 144
Windows (Opening and Closing)............ 136
Windshield................................................ 144
Cleaning ................................................. 380
Defrosting ....................................... 184, 187
Washer Fluid ........................................... 346
Wiper Blades ........................................... 358
Wipers and Washers................................ 144
Winter Tires.............................................. 370
Snow Tires .............................................. 370
Tire Chains .............................................. 370
Wipers and Washers................................. 144
Checking and Replacing Wiper Blades ..... 358
WMA................................................. 207, 221
Worn Tires................................................ 362
