2013 HONDA CROSSTOUR display

291
uuCustomized Features*u
Continued
Features


Show with Turn Signal
Reference Lines
Next Maneuver Pop up
Default
Fixed Guideline
Dynamic Guideline



Default

Default
Sound
Source Select Setup
Cover Art
Connect Bluetooth Audio Device
Bluetooth Device List
Recording from CD
Recording Quality
HDD Info
Gracenote Album DB Info Update
Update Gracenote Album Info
Delete all HDD Data
USB/Bluetooth Connection Priority *
Camera
Settings
Rear
Camera
LaneWatch
Audio
Settings
Display Brightness
Contrast
Black Level
ColorTint
* Not available on all models
Main MenuTable of contents

294
uuCustomized Features*u
Features
■
List of customizable options
*1:Default Setting Setup
Group Customizable Features Description Selectable Settings
System
Settings
Display
BrightnessChanges the brightness of the audio/information screen.—
ContrastChanges the contrast of the audio/information screen.—
Black levelChanges the black level of the audio/information screen.—
BeepSelects whether a beeper sounds or not when
you operate the selector knob.On
*1
/Off
Blue-
tooth
BluetoothTurns the Bluetooth® on and off.On *1
/Off
Bluetooth Device ListPairs a new phone to HFL, edits and deletes a
paired phone, and create a security PIN.
2Phone Setup P. 339—
Edit Pairing CodeChanges a pairing code.
2To change the pairing code setting P. 341Random*1
/Fixed
Voice RecognitionTurns the voice recognition on and off.On *1
/Off
Models without navigation system
Main MenuTable of contents

295
uuCustomized Features*u
Continued
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
System
Settings
Clock
Clock/
Wallpaper
Type
Clock TypeChanges the clock display type.Analog
/Digital *1
/
Small Digital /Off
Wallpaper
●
Changes the wallpaper type.
● Imports an image file for a new wallpaper.
● Deletes an image file for a wallpaper.
2 Wallpaper Setup P. 189Blank/Galaxy *1
/
Metallic /Add New
Clock AdjustmentAdjust Clock.
2Setting the Clock P. 88—
Clock FormatSelects the digital clock display from 24H to 12H.12H*1
/24H
Others
LanguageChanges the display language.English *1
/French /
Spanish
Display Operation
Restriction TipsSelects whether the display operation restriction
message is shown or not.On *1
/Off
Background ColorChanges the background color of the audio/
information screen and the audio with touch screen *
.Blue *1
/Amber /Red /
Green
Header Clock DisplaySelects whether the clock display comes on or not.On *1
/Off
Factory Data ResetResets all the settings to their factory default.
2Defaulting All the Settings P. 315Yes/No
DefaultCancels /Resets all customized items in the
System Settings group as default.Yes/No
* Not available on all models
Main MenuTable of contents

296
uuCustomized Features*u
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Vehicle
SettingsDriver
Assist
System
Setup
*Forward Collision Warning
Distance
* Changes at which distance FCW alerts, or turns
FCW on and off. Long
*1
/Normal /
Short /Off
Meter
Setup Adjust Outside Temp.
Display
Adjust the temperature reading by a few degrees. -5

298
uuCustomized Features*u
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Vehicle
Settings Door
SetupAuto Door Lock
Changes the setting for the automatic locking feature. With Vehicle Speed
*1
/
Shift from P /Off
Auto Door Unlock Changes the setting for when the doors unlock
automatically. Driver Door with Shift
to P
*1
/All Doors with
Shift to P /Driver Door
with IGN Off /All Doors
with IGN Off /Off
Key And Remote Unlock
Mode Sets up either the driver’s door or all doors to
unlock on the first push of the remote. Driver Door
*1
/All
Doors
Keyless Lock Answer Back LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds. On
*1
/Off
Security Relock Timer Changes the time it takes for the doors and the
tailgate to relock and the security system to set
after you unlock the vehicle without opening any
door or the tailgate. 90seconds
/
60seconds /
30seconds *1
Mainte-
nance
Info. Maintenance Reset
Resets the engine oil life display when you have
performed the maintenance service. —
Default All
Cancels/Resets all customized items in the
Vehicle Settings group as default. Yes
/No
Main MenuTable of contents

299
uuCustomized Features*u
Continued
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Audio
Settings
SoundAdjusts the settings of the audio speaker’s sound.
2Adjusting the Sound P. 191-6 ~ C*1
~ +6 (Bass ,
Treble , Fader , Balance
and Subwoofer ), Off /
Low /Mid *1
/High (SVC )
Source Select PopupSelects whether the list of selectable audio
sources comes on or not when Audio is selected
on the Function Change screen.On/Off *1
Cover ArtTurns on and off the cover art display.On*1
/Off
Connect Bluetooth Audio DeviceConnects, disconnects or pairs a Bluetooth®
Audio device to HFL.—
Bluetooth Device ListEdits or deletes a Bluetooth® Audio device paired
to HFL.—
USB/Bluetooth Connection Priority *Selects the connection to have priority.Bluetooth
/USB *1
DefaultCancels/Resets all customized items in the
Audio
Settings group as default.Yes/No
iPod ®, USB, Pandora ® or Aha TM
mode
Bluetooth ® Audio, Pandora ® or Aha TM
mode
Bluetooth ® Audio, Pandora ® or Aha TM
mode
iPod ®, Bluetooth ® Audio, Pandora ® or Aha TM

mode
* Not available on all models
Main MenuTable of contents

301
uuCustomized Features*u
Continued
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Phone
Settings
Connect PhonePairs a new phone to HFL, connects or
disconnects a paired phone.
2Phone Setup P. 339—
Bluetooth Device ListPairs a new phone to HFL, edits or deletes a
paired phone, or creates a security PIN.
2Phone Setup P. 339—
Phone
Edit Speed DialEdits, adds or deletes a speed dial entry.
2Speed Dial P. 350—
Auto TransferSets calls to automatically transfer from your
phone to HFL when you enter the vehicle.On*1
/Off
Auto AnswerSets whether to automatically answer an
incoming call after about four seconds.On /Off *1
Ring ToneSelects the ring tone.Fixed *1
/Mobile
Phone /Off
Automatic Phone SyncSets a phonebook data to be automatically
imported when a phone is paired to HFL.On *1
/Off
Use Contact PhotoDisplays a caller’s picture on an incoming call
screen.On *1
/Off
Main MenuTable of contents

303
uuCustomized Features*u
Continued
Features
*1:Default SettingSetup
Group Customizable Features Description Selectable Settings
Camera
Settings Lane-WatchShow with Turn Signal
Select whether the LaneWatch display comes on
when you move the turn signal lever to the
passenger side.
On
*1
/Off
Reference Lines Selects whether the reference lines come on the
LaneWatch monitor. On
*1
/Off
Display Brightness
Adjusts the LaneWatch display settings. —
Contrast
Black Level
Color
Tint
Default
Cancels/Resets all customized items in the LaneWatch
group as default. Yes
/No
Default Cancels/Resets all customized items in the LaneWatch
group as default. Yes
/No
Rear
Camera Fixed Guideline
Selects whether the fixed guidelines come on or
not on the rear camera monitor. On
*1
/Off
Dynamic Guideline Selects whether the dynamic guidelines come on
or not on the rear camera monitor. On
*1
/Off
Default Cancels/Resets all customized items in the
Rear
Camera group as default. Yes
/No
Main MenuTable of contents
