Continued173
uuBefore DrivinguDriving Preparation
Driving
•Store or secure all items on board properly.
uCarrying too much cargo, or improperly storing it, can affect your vehicle's
handling, stability, stopping distance, and tires, and make it unsafe.
2 Maximum Load Limit P. 175
• Do not pile items higher than the seat height.
uThey can block your view and may be thrown forward in the event of sudden
braking.
• Do not place anything in the seat footwells. Make sure to secure the floor mats.
uAn object or unsecured floor mat can interfere with your brake and accelerator
pedal operation while driving.
• If you have any animals on board, do not let them move around in the vehicle.
uThey may interfere with driving and a crash could occur.
• Securely close and lock both doors and the hatch.
2 Locking/Unlocking the Doors from the Inside P. 102
• Adjust your seating position properly.
2 Adjusting the Seats P. 121
• Adjust the mirrors and steering wheel properly for your driving.
uAdjust them while sitting in the proper driving position.
2 Adjusting the Mirrors P. 119
2 Adjusting the Steering Wheel P. 118
■Interior Checks1Interior Checks
The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area, have the aiming
readjusted at a dealer or by a qualified technician.
Main MenuTable of Contents

242
Maintenance
Replacing Light Bulbs
Headlight Bulbs
When replacing, use the following bulbs.1.Remove the cover.
2. Push the tab to remove the coupler.
3. Rotate the old bulb to the left to remove.
4. Insert a new bulb into the headlight
assembly and turn it to the right.
5. Insert the coupler into the connector of the
bulb.
High beam headlight:60 W (HB3 for halogen bulb type)
Low beam headlight:55 W (H11 for halogen bulb type)
35W (D4S for high voltage discharge)
■High Beam Headlight
1Headlight Bulbs
NOTICE
Halogen bulbs get very hot when lit.
Oil, perspiration, or a scratch on the glass can cause
the bulb to overheat and shatter.
The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the cargo area, have the aiming
readjusted at a dealer or by a qualified technician.
When replacing a halogen bulb, handle it by its base,
and protect the glass from contact with your skin or
hard objects. If you touch the glass, clean it with
denatured alcohol and a clean cloth.
The exterior lights' inside lenses (headlights, brake
lights, etc.) may fog temporarily after a car wash or
while driving in the rain. This does not impact the
exterior light function.
However, if you see a large amount of water or ice
accumulated inside the lenses, have your vehicle
inspected by a dealer.
Cover
TabCoupler
Bulb
Main MenuTable of Contents

320
Index
Fuel Economy............................................ 219
Fuel Fill Cap ......................................... 20, 218
Message .................................................. 294
Fuel Fill Door ....................................... 20, 217
Fuses .......................................................... 297
Inspecting and Changing ......................... 300
Locations ......................................... 297, 298
G Gasoline (Fuel) Economy ................................................. 219
Gauge ....................................................... 81
Information ............................................. 216
Instant Fuel Economy ................................. 81
Low Fuel Indicator ..................................... 68
Refueling ................................................. 216
Gauges ......................................................... 81
Gear Shift Lever Positions Automatic Transmissi on (CVT) ................. 183
Glass (care) ................................................ 267
Glove Box .................................................. 127
H
Halogen Bulbs ........................................... 242
Handling the Unexpected ........................ 269
HandsFreeLink ® (HFL) ............................... 158
HFL Buttons ............................................. 158
HFL Menus .............................................. 160
HFL Status Display.................................... 159 Phone Setup............................................ 162
Hatch ......................................................... 104
Door/Hatch Open Indicator........................ 31
Unable to Open....................................... 303
Hazard Warning Button .............................. 2
Head Restraints ........................................ 123
Headlights ................................................. 112
Aiming .................................................... 242
Automatic Operation............................... 112
Dimming ......................................... 111, 113
Operating........................................ 111, 113
Heaters (Seat) ........................................... 133
HFL (HandsFreeLink ®)............................... 158
High Temperature Indicator ...................... 72
High-Beam Indicator .................................. 73
Hill Start Assist System ............................. 180
Honda IMA System ..................................... 10
I Identification Numbers ............................ 308
Engine and Transmission ......................... 308
Vehicle Identification ............................... 308
Ignition Switch ......................................... 110
Illumination Control ................................. 116
Knob ....................................................... 116
IMA Battery Charge Level Indicator .......... 82
IMA System Indicator ................................. 72
Immobilizer System .................................. 106
Indicator.................................................... 75 Indicators
.................................................... 66
7-Speed Manual Shift Mode ..................... 74
ABS (Anti-lock Brake System) .................... 69
Auto Idle Stop........................................... 75
Charging System............................... 67, 293
CRUISE CONTROL ............................. 75, 201
CRUISE MAIN.................................... 75, 200
Door Open................................................ 31
ECON Mode ............................................. 76
EPS (Electric Power Steering)
System ............................................ 71, 295
Fog Light .................................................. 74
High Temperature ..................................... 72
High-Beam................................................ 73
IMA System .............................................. 72
Immobilizer System ................................... 75
Lights On .................................................. 74
Low Fuel ................................................... 68
Low Oil Pressure ............................... 66, 292
Low Temperature...................................... 73
Low Tire Pressure/TPMS .................... 71, 205
Malfunction Indicator Lamp .............. 67, 294
NORMAL Mode ........................................ 76
Parking Brake and Brake System ....... 66, 295
Plus Sport System...................................... 77
Seat Belt Reminder.............................. 33, 68
Security System Alarm............................... 75
Shift Down ............................................... 76
Shift Lever Position.................................... 74
Shift Up .................................................... 76
Side Airbag Off ................................... 52, 73
