E-85 Usage In Non-Flex Fuel Vehicles
Non-FFV vehicles are compatible with gasoline contain-
ing 10% ethanol (E10). Gasoline with higher ethanol
content may void the vehicle’s warranty.
If a Non-FFV vehicle is inadvertently fueled with E-85
fuel, the engine will have some or all of these symptoms:
•operate in a lean mode
•OBD II “Malfunction Indicator Light” on
•poor engine performance
•poor cold start and cold drivability
•increased risk for fuel system component corrosionTo fix a Non-FFV vehicle inadvertently fueled once with
E-85 perform the following:
•drain the fuel tank (see your authorized dealer)
•change the engine oil and oil filter
•disconnect and reconnect the battery to reset the
engine controller memory
More extensive repairs will be required for prolonged
exposure to E-85 fuel.
MMT In Gasoline
MMT is a manganese-containing metallic additive that is
blended into some gasoline to increase octane. Gasoline
blended with MMT provides no performance advantage
beyond gasoline of the same octane number without
MMT. Gasoline blended with MMT reduces spark plug
530 STARTING AND OPERATING

If you REGULARLY tow a trailer for more than 45 min-
utes of continuous operation, then change the transmis-
sion fluid and filter as specified for “police, taxi, fleet, or
frequent trailer towing.” Refer to the “Maintenance
Schedule” for the proper maintenance intervals.
Electronic Speed Control – If Equipped
•Do not use in hilly terrain or with heavy loads.
•When using the speed control, if you experience speed
drops greater than 10 mph (16 km/h), disengage until
you can get back to cruising speed.
•Use speed control in flat terrain and with light loads to
maximize fuel efficiency.
Cooling System
To reduce potential for engine and transmission over-
heating, take the following actions:
City Driving
When stopped for short periods, shift the transmission
into NEUTRAL and increase engine idle speed.
Highway Driving
Reduce speed.
Air Conditioning
Turn off temporarily.
5
STARTING AND OPERATING 555

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 3.6L..........591
ONBOARD DIAGNOSTIC SYSTEM — OBD II . .592
▫Loose Fuel Filler Cap Message............593
EMISSIONS INSPECTION AND
MAINTENANCE PROGRAMS.............593
REPLACEMENT PARTS..................595
DEALER SERVICE......................595
MAINTENANCE PROCEDURES...........596
▫Engine Oil..........................597
▫Engine Oil Filter......................599▫Engine Air Cleaner Filter................599
▫Exhaust System......................600
▫Maintenance-Free Battery...............603
▫Air Conditioner Maintenance.............604
▫Body Lubrication.....................607
▫Windshield Wiper Blades...............607
▫Cooling System......................608
▫Brake System........................615
▫Automatic Transmission................617
7

American Petroleum Institute (API) Engine Oil
Identification Symbol
This symbol means that the oil has
been certified by the American Pe-
troleum Institute (API). The manu-
facturer only recommends API Cer-
tified engine oils.
CAUTION!
Do not use chemical flushes in your engine oil as the
chemicals can damage your engine. Such damage is
not covered by the New Vehicle Limited Warranty.
Engine Oil Viscosity – 3.6L Engine
SAE 5W-20 engine oil is recommended for all operating
temperatures. This engine oil improves low temperature
starting and vehicle fuel economy.
The engine oil filler cap also shows the recommended
engine oil viscosity for your engine. For information on
engine oil filler cap location, refer to the “Engine Com-
partment” illustration in this section.
NOTE:SAE 5W-30 engine oil approved to Fiat 9.55535-S1
or Fiat 9.55535-S3 may be used when SAE 5W-20 engine
oil meeting MS- 6395 is not available.
Synthetic Engine Oils
You may use synthetic engine oils provided the recom-
mended oil quality requirements are met, and the recom-
mended maintenance intervals for oil and filter changes
are followed.
598 MAINTAINING YOUR VEHICLE

3. Push the bulb into the socket, twist the socket into the
lamp assembly and reinstall the lamp assembly into
place ensuring the locking tab is secure.
FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)20 Gallons 76 Liters
Engine Oil with Filter
3.6L Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters
Cooling System *
3.6L Engine (MOPAR® Antifreeze/Engine Coolant
10 Year/150,000 Mile Formula or equivalent)13.4 Quarts 12.6 Liters
* Includes heater and coolant recovery bottle filled to MAX level. Add 2.9 Qts (2.8 L) if equipped with a rear
heater.
638 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant We recommend you use MOPAR® Antifreeze/Coolant 10 Year/
150,000 Mile Formula OAT (Organic Additive Technology) meeting the
requirements of Chrysler Material Standard MS-12106.
Engine Oil We recommend you use API Certified SAE 5W-20 Engine Oil, meeting the
requirements of Chrysler Material Standard MS-6395. Refer to your oil filler
cap for correct SAE grade.
Engine Oil Filter We recommend you use MOPAR® Engine Oil Filters.
Spark Plugs We recommend you use MOPAR® Spark Plugs (Gap 0.043 in [1.1 mm]).
Fuel Selection 87 Octane
7
MAINTAINING YOUR VEHICLE 639

Adding Engine Coolant (Antifreeze)............611
Adding Fuel.............................537
Adding Washer Fluid......................608
Additives, Fuel...........................531
Adjustable Pedals.........................235
Airbag..................................74
Airbag Deployment........................85
Airbag Light.............................82
Airbag Maintenance........................87
Airbag, Side..............................78
Airbag, Window (Side Curtain)................78
Air Cleaner, Engine (Engine Air Cleaner Filter). . . .599
Air Conditioner Maintenance.................604
Air Conditioning..........................431
Air Conditioning Controls...................431
Air Conditioning Filter.....................455
Air Conditioning, Rear Zone.................437
Air Conditioning Refrigerant.................604
Air Conditioning System....................431Air Conditioning System, Zone Control..........431
Air Pressure, Tires.........................507
Alarm Light.............................320
Alarm (Security Alarm)......................17
Alterations/Modifications, Vehicle...............7
Antenna, Satellite Radio.....................373
Antifreeze (Engine Coolant)..................610
Disposal..............................613
Anti-Lock Warning Light....................314
Anti-Theft System..........................17
Appearance Care.........................619
Ashtray................................278
Assistance Towing.........................160
Assist, Hill Start..........................493
Auto Down Power Windows..................42
Automatic Dimming Mirror..................131
Automatic Door Locks......................38
Automatic Headlights......................222
Automatic Temperature Control (ATC)..........440
662 INDEX

Automatic Transmission....................464
Adding Fluid..........................618
Fluid and Filter Changes..................618
Fluid Change..........................618
Fluid Level Check.......................618
Fluid Type............................617
Gear Ranges...........................469
Special Additives.......................617
Torque Converter.......................476
Auto Up Power Windows....................42
Battery.................................603
Jump Starting..........................579
Keyless Transmitter Replacement (RKE)........28
Saving Feature (Protection)................228
Belts, Seat...............................118
Blind Spot Monitoring......................136
Body Mechanism Lubrication.................607
B-Pillar Location..........................502Brake Assist System.......................487
Brake Control System, Electronic..............486
Brake Fluid.............................640
Brake System............................615
Fluid Check...........................615
Parking..............................481
Warning Light.........................320
Brake/Transmission Interlock.................466
Bulb Replacement.........................635
Bulbs, Light.............................120
Calibration, Compass......................340
Camera, Rear............................249
Capacities, Fluid..........................638
Caps, Filler
Fuel.................................537
Power Steering.........................481
Radiator (Coolant Pressure)................612
Carbon Monoxide Warning
..................11710
