2013 Citroen C4 PICASSO RHD fuse

Contents
2
Hazard warning lamps 222
Horn 222
Emergency or assistance call 223
Warning triangle 223
Tyre under-infl ation detection 224
ESC system 227
Seat belts 230
Airbags 235
Child seats 241
ISOFIX mountings 252
Child lock 259
Safety
Te m p o r a ry puncture repair kit 260
Changing a wheel 268
Snow chains 278
Changing a bulb 279
Changing a fuse 288
12 V battery 295
Energy economy mode 298
Changing a wiper blade 299
To w i ng the vehicle 300
To w i ng a trailer 302
Roof bars 304
Very cold climate screen 306
Accessories 307
Practical information
Bonnet 310
Petrol engines 311
Diesel engines 312
Fuel 313
Misfuel prevention (Diesel) 315
Running out of fuel (Diesel) 317
Checking levels 318
Checks 321
Checks
Petrol engines 323
Petrol weights 324
Diesel en
gines 325
Diesel weights 328
Dimensions 331
Identifi cation markings 333
Technical data
Emergency or assistance 335
Touch screen tablet 337
Audio and telematics
Visual search
Lighting controls 202
Automatic illumination of headlamps 207
Automatic headlamp dipping 208
Daytime running lamps 210
Headlamp adjustment 211
Directional lighting 213
Wiper controls 214
Screenwash 216
Automatic rain sensitive wipers 217
Courtesy lamps 219
Panoramic sunroof 220
Interior mood lighting 221
Visibility
Alphabetical index

10
Familiarisation
Interior
1.
Bonnet release lever.2.
Fusebox.3.
Steering wheel adjustment controls. 4.
Door mirror controls.Electric window controls.5.
Side adjustable air vents.Side window demisting vents.
6.Quar ter light demisting windows.
7
. Driver's airbag.
Horn. 8.Courtesy lamp and map reading lamps. 9. Panoramic glass roof panel blind control. 10.CITROËN Localised Emergency Call - CITROËN Localised Assistance Call(depending on country of sale).11.
Windscreen demisting/defrosting vent.12.Scented air freshener.13.Central adjustable air vents.14.Passenger's airbag. 15.
Glove box.16.
Central storage.
Audio sockets, 12V accessory socket (120 W max), 230V socket (120 W max).17.Storage below steering wheel (handbookpack). 18.Gear lever (manual gearbox). 19. Console (fixed/removable).
20.
Storage or rear multi-media.
Rear 12 V accessory socket (120 W max.).

50
Monitoring
Under-inflationfixed.The pressure in one or more wheelsis too low. Check the pressure of the tyres as soon as possible.
This check should preferably be carried out when the
tyres are cold.
You must reinitialise the system after the adjustment
of one or more tyre pressures and after changing one or more wheels.

+
flashing then fixed, accompanied by the Service warning lamp.The s
ystem has fault: the tyrepressures are no longer monitored.Check the tyre pressures as soon as possible.
Have the system checked by a CITROËN dealer or a
qualified workshop.
Warning / indicator lampStateCauseAction / Observations
Foot on thebrake pedal*fixed. The brake pedal is not pressed. With an electronic gearbox, press the brake pedal to start the engine (lever in position N ).
If you wish to release the parking brake withoutpressing the brake pedal, this warning lamp will
remain on.
With an automatic gearbox, press the brake pedal to move the gear selector out of position P.P
flashing. With an electronic gearbox, if you hold the vehicle on an incline using
the accelerator for too long, the clutch overheats. Use the brake pedal and/or the parkin
g brake.
Foot on theclutch*fixed. In the STOP mode of Stop & Start,changing to START mode is refused
because the clutch pedal is not fully down.You must declutch full
y to allow the change to engineSTA R T m o d e .
*
Only with the type 1 instrument panel

187
4
Driving
comes on in the door mirror on the side in
question as soon as a vehicle - car, lorry,
bicycle - is detected and the following conditions are fulfilled:


- all the vehicles must be moving in the same
direction,

- the speed of your vehicle is between 7 and 87 mph (12 and 140 km/h),

- the difference in speed between your
vehicle and the other vehicles must be lessthan 6 mph (10 km/h),

- the traffic must be flowing normally,

- in the case of an over taking manoeuvre,
if this is prolonged and the vehicle beingover taken remains in the blind spot,

- you are driving on a straight or slightly cur ved road,

- your vehicle is not pulling a trailer, a caravan...
No aler t will be given in the
following situations:
- in the presence of stationary objects (parked vehicles, barriers, street lamps,road signs...),
- with vehicles moving in the opposite
direction,
- driving on a sinuous road or a sharp corner,
- when overtaking
(or being over taken by) a
very long vehicle (lorry, coach...) which is at the same time detected at the rear in theblind spot angle and present in the driver's
for ward field of vision,

- in ver
y heavy traffic: vehicles detected in front and behind are confused with a lorryor a stationary object,

- when overtaking quickly.

288
Practical information
Before changing a fuse: )
the cause of the failure must be identified
and rectified,)
all electrical consumers must b switched off,)
the vehicle must be immobilised with the
ignition off, ) identify the failed fuse using the tables and layout drawings in the following pages.


Changing a fuse
GoodFailed

The replacement of a fuse not shown inthe tables below may cause a seriousmalfunction of your vehicle. Contact a CITROËN dealer or a qualifiedworkshop.
Tweezer





















Changing a fuse
The extraction tweezer is located in the
dashboard fusebox compartment.
F
or access to it: )unclip the cover by pulling at the top right,
then left, )disengage the cover completely, bycarefully pulling in the direction indicated
by the arrow,
)remove the tweezer.

Access to the tools

To replace a fuse, you must:)
use the special tweezer to extract the fuse from its housing and check the condition of
its filament. ) always replace the failed fuse with a fuse of the same rating (same colour); using a
di
fferent rating could cause faults (risk of fire).
If the fuse fails again soon after replacement,
have the vehicle's electrical system checked by
a CITRO

289
7
Practical information
CITROËN will not accept responsibilityfor the cost incurred in repairing your vehicle or for rectifying malfunctions resulting from the installation of accessories not supplied and notrecommended by CITROËN andnot installed in accordance with its instructions, in par ticular when the combined consumption of all of the additional equipment connectedexceeds 10 milliamperes.


Installing electricalaccessories

Your vehicle's electrical system isdesigned to operate with standard or optional equipment.
Before installing other electrical equipment or accessories on your vehicle, contact a CITROËN dealer or aqualified workshop.
Configurations
The type of electrical system of the vehicle depends on its level of equipment.
To i d e n t i fy the type of electrical system on your vehicle, open the bonnet: the presence of anadditional fusebox in front of the battery indicates that it is type 2.
The type 1 electrical system does not have any fuses in front of the battery.

290
Practical information

Type 1 fuse tables
Fusebox 1


Dashboard fuses

The fusebox is located in the lower dashboard (left-hand side).
Access to the fuses
)Refer to the paragraph "Access to the tools".
Fuse N°RatingFunctions
F
85 A Steering mounted controls
F1
820 A Touch screen tablet, audio and navigation system, CD player,USB por ts and auxiliary sockets.
F1
615 A
Front 12V socket.
F1
515 A
Boot 12V socket.
F2
85 A STA R T/STOP button.
F3
015 A Rear wiper.
F27 15 A
Front screenwash pump, rear screenwash pump.
F2
615 A
Horn.
F20 5
A Airbags.
F215 A Instrument panel.
F1
95 A Rain and sunshine sensor.
F12 5
A Keyless starting unit.
F2 5
A Manual headlamp adjustment control.

291
7
Practical information
Fusebox 2
Fuse N°RatingFunctions
F
915 A Rear 12V socket.
