2013 Citroen C4 PICASSO RHD engine

316
Checks
Quality of the fuel used for
petrol engines
The petrol engines are perfectly compatible
with E10 or E24 type petrol biofuels (containing10 % or 24 % ethanol), conforming to Europeanstandards EN 228 and EN 15376.
E85 type fuels (containing up to 85 % ethanol)
are reserved exclusively for vehicles marketed
for the use of this type of fuel (BioFlex
vehicles). The quality of the ethanol mustcomply with European standard EN 15293.
Quality of the fuel used for
Diesel engines

The Diesel engines are perfectly compatible
with biofuels which conform to current andfuture European standards (Diesel fuel whichcomplies with standard EN 590 mixed with abiofuel which complies with standard EN 14214)
available at the pumps (containing up to 7 %Fatty Acid Methyl Ester).
The B30 biofuel can be used in cer tain Diesel engines; however, this use is subject to strict
application of the special ser vicing conditions.Contact a CITROËN dealer or a qualified
workshop.
The use of any other type of (bio)fuel (vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel system).

317
8
Checks











Running out of fuel (Diesel)

On vehicle fitted with HDi engines, the fuel system must be primed if you run out of fuel;
refer to the corresponding engine compar tment
view.
1.6 litre HDi engine
)
Fill the fuel tank with at least five litres of diesel.
)
Open the bonnet.)
If necessary, unclip the styling cover for
access to the priming pump.) Squeeze and release the priming pumprepeatedly until resistance is felt (there may be resistance at the first press). )
Operate the star ter until the engine starts(if the engine does not star t at the first
attempt, wait around 15 seconds before
tr
ying again). ) If the engine does not star t after a few
attempts, operate the priming pump again
then star t the engine.) Clip the styling cover back in place. )
Close the bonnet.


If the tank on your vehicle is fitted witha misfuel prevention device, refer to the"Misfuel prevention (Diesel)" section.


If the engine does not star t first time, don't keep trying but star t the procedureagain from the beginning.

318
Checks






Checking levels


Ta k e c a r e w h e n w o r k i ng under the bonnet, as certain areas of the engine may be extremelyhot (risk of burns) and the cooling fan could star t at any time (even with the ignition off).
Oil level

The check is carried out either when
the ignition is switched on using theoil level indicator in the instrument
panel, or using the dipstick.
Engine oil change

Refer to the maintenance and warranty guidefor details of the interval for this operation.
In order to maintain the reliability of the engine
and emission control system, the use of
additives in the engine oil is prohibited.

Oil specifi cation

The oil must be the correct grade for your engine and conform to the manufacturer'srecommendations.
Check all of these levels re
gularly, in line with the maintenance and warranty guide. Top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.
Dipstick

There are two marks on the dipstick:
A= maximum
If you fill past this mark, contact a CITROËN dealer or a qualified workshop. B= minimum
Top up the level through the
oil filler orifice, using thecorrect grade of oil for your engine. The level must never be below this mark.
It will onl
y be correct if the vehicle is on level ground and the engine has been off for more
than 30 minutes.It is normal to top up the oil level between
two ser vices (or oil changes). CITROËNrecommends that you check the level, and top
up if necessary, every 3 000 miles (5 000 kms).
After topping up the oil, the check whenswitching on the ignition with the oil level
indicator in the instrument panel is not valid
durin
g the 30 minutes after topping up.

319
8
Checks

The coolant level should be closeto the "MA X" mark but should never exceed it.
In addition, as the cooling system is pressurised, wait at least one hour after switching off the
engine before carrying out any work.
To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop. When
the pressure has dropped, remove the cap and
top up the level.


Fluid specifi cation

The coolant must conform to the
m
anufacturer's recommendations. Th
e brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
Brake fluid level

Changing the fl uid

Refer to the maintenance and warranty guidefor details of the inter val for this operation.


Fluid specifi cation

The brake fluid must conform to themanufacturer's recommendations and meet the
DOT3 or DOT4 standard.
The cooling fan may star t after switching off the engine: take care with ar ticles and clothing that might become caught by the fan blades.
When the engine is warm, the temperature of
the coolant is regulated by the fan.

321
8
Checks






Checks
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctl
y tightened, particularly in summer and winter.

Refer to the maintenance andwarranty guide for details of the
replacement inter vals for these
components.
Air filter and passenger compartment filter
Replace the oil filter each time theengine oil is changed.
Refer to the maintenance andwarranty guide for details of the
replacement interval for this component.
Oil filter The presence of this label, in particular with
the Stop & Start system, indicates the use of a specific 12 V lead-acid battery with special
technology and specification. The involvement
of a CITROËN dealer or a qualified workshop is
essential when replacing or disconnecting the
battery.
Unless other wise indicated, check these components in accordance with the maintenance and warrant
y guide and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
Dependin
g on the environment (e.g. dustyatmosphere) and the use of the vehicle(e.g. city driving), replace them twiceas often if necessar y.y
A clogged passenger compar tment filter may have an adverse effect on the performance
of the air conditioning system and generateundesirable odours.
Particle emissions filter (Diesel)
The start of saturation of thepar ticle filter is indicated by the
fixed illumination of this warning lamp accompanied by a warning
message.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, thisindicates a low additive level.


On a new vehicle, the first par ticlefilter regeneration operations may beaccompanied by a "burning" smell,
which is perfectly normal.
Following prolonged operation of thevehicle at very low speed or at idle, you may, in exceptional circumstances, notice the emission of water vapour atthe exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment. When carrying out work on the battery, re
fer
to the "12 V battery" section for details of theprecautions to be taken before disconnecting
the battery and following its reconnection.

322
Checks
Brake wear depends on the styleof driving, par ticularly in the case of vehicles used in town, over shor t
distances. It may be necessary to
have the condition of the brakes checked, even between vehicle services.
Unless there is a leak in the circuit, a drop in
the brake fluid level indicates that the brake
pads are worn.















Brake pads
For information on checking brake
disc wear, contact a CITROËN dealer
or a qualified workshop.


Brake disc wear















Only use products recommended by CITROËN or products of equivalent quality and specification.

In order to optimise the operation of units as important as those in the braking system, CITROËN selects and offers very specific products.
After washing the vehicle, dampness,or in wintry conditions, ice can form on the brake discs and pads: braking efficiency may be reduced. Make lightbrake applications to dry and defrost the brakes.

Electric parking brake


For more information, refer to the "Electric parking brake - Operating faults" section. This s
ystem does not require any routine servicing. However, in theevent of a problem, have the systemchecked by a CITROËN dealer or a qualified workshop.
Manual gearbox

The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for the details of
the level checking inter val for thiscomponent.
6-speed electronic gearbox
The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for details of the checking interval for this component.
Automatic gearbox

The gearbox does not require anymaintenance (no oil change).
Refer to the maintenance and
warranty guide for details of the levelchecking interval for this component.
To avoid damaging the electrical units, the use of a high pressure washer in the engine compar tment is strictlyprohibited.

9
323
Technical data
Petrol enginesVTi 120THP155
Gearboxes
Manual(5-speed)


Manual(6-speed)
Model codes:3D... 3E... 3A...5FS0/1
5FV8 - 8/1

Cubic capacity (cc)
1 598

1 598

Bore x stroke (mm)
77 x 85.8
77 x 85.8

Max power * : EU standard (kW)
88
115

Max power en
gine speed (rpm) 6 000
6 000

Max torque: EU standard
(Nm)

160240

Max torque en
gine speed (rpm) 4 2501 400

F
uel Unleaded Unleaded
Catal
ytic converter yes
yes
Oil capacities (in litres)

Engine (with filter replacement)
4.25

4.25


* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).















Petrol engines and gearboxes
3D...:CITROËN C4 Picasso (5-seat).3A...:CITROËN Grand C4 Picasso (7- s e at).3E...:
CITROËN Grand C4 Picasso (5-seat).

324
Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg). **

The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Petrol enginesVTi 120THP155
Gearboxes
Manual(5-speed)
Manual (6-speed)

Model codes:3D... 3E... 3A ... 5FS0/1 3D... 3E... 3A ...5FV8 - 8/1


-
Unladen weight1 252 - 1 276 - 1 278

1 296 - 1 311 - 1 313



- Kerb wei
ght *


1 327 - 1 351 - 1 353

1 371 - 1 386 - 1 388



- Gross vehicle wei
ght (GV W)

1 900 - 2 060 - 2 1101 940 - 2 100 - 2 150



- Gross train weight (GT W)

on a 12 % gradient2 900 - 2 860 - 2 860 3 360 - 3 350 - 3 350



- Braked trailer
(within GTW limit) on a 10 % or 12 % gradient
1 000 - 800 - 750
1 420 - 1 250 - 1 200



- Braked trailer
**
(with load transfer within the GTW limit)

1 200 - 1 100 - 1 050

1 620 - 1 550 - 1 500



- Unbraked trailer
660 - 675 - 675 685 - 690 - 690



- Recommended nose weight
70 - 70 - 70
70 - 70 - 70














Petrol weights and towed loads (in kg)
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.
