2013 Citroen C4 PICASSO stop start

310
Checks











Bonnet
Open the left hand front door.


Do not open the bonnet under verywindy conditions.When the engine is hot, handle the exterior safety catch and the stay with care (risk of burns), using the protected area.
)
Lift the safety catch and raise the bonnet.

)Unclip the stay from its housing and place it
in the support slot to hold the bonnet open.

Opening
)Pull the release lever, located at the bottom
of the door aper ture, towards you.
Before doing anything under the bonnet,switch off the Stop & Start system toavoid any risk of injury resulting from anautomatic change to START mode.
The cooling fan may star t after switching off the engine: take care with ar ticles and clothing that might become caught by the fan blades.


Closing
)Take the stay out of its suppor t slot. )Clip the stay back into its housing. )Lower the bonnet and release it at the end of its travel. )Pull on the bonnet to check that it haslatched correctly.
When the bonnet is open, take care not to damage the safety catch.

313
8
Checks























Fuel
Capacity of the tank: approximately 57 litres (petrol) or 55 litres (Diesel).


Low fuel level
Refuelling
When the low fuel level is reached,
this warning lamp in the instrumentpanel comes on, accompanied by anaudible warning, a message and the
last bar of the fuel gauge comes on in orange.
) Take care to select the pump that delivers
the correct type of fuel for your vehicle.) Introduce the nozzle so as to push in themetal non-return flap A.)
Make sure that the nozzle is pushed in as
far as possible before star ting to refuel (risk
of blowback). ) Maintain this position throughout the
refuelling operation.) Push the fuel flap to close it.
If you are filling your tank to the top, do
not persist after the 3rd cut- off; this could cause malfunctions.
A label on the inside of the fuel filler flapreminds you of the type of fuel to use,
depending on your engine type.
Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge. When it
first comes on, about 6 litresof fuel
remain in the tank.
Until sufficient fuel has been added, this warninglamp appears every time the ignition is switched
on, accompanied by an audible warning and amessage. This audible warning and message
are repeated with increasing frequency as the fuel level drops towards "0".
Refuel as soon as possible to avoid running out.
Opening the filler flap may result in an inrush of air. This is entirely normal and results from the
sealing of the fuel system.
) Press the rear edge of the flap to open it
(the filler cap is par t of it).
With Stop & Star t, never refuel with the
system in STOP mode; you must switchoff the ignition with the START/STOP button.

321
8
Checks






Checks
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctl
y tightened, particularly in summer and winter.

Refer to the maintenance andwarranty guide for details of the
replacement inter vals for these
components.
Air filter and passenger compartment filter
Replace the oil filter each time theengine oil is changed.
Refer to the maintenance andwarranty guide for details of the
replacement interval for this component.
Oil filter The presence of this label, in particular with
the Stop & Start system, indicates the use of a specific 12 V lead-acid battery with special
technology and specification. The involvement
of a CITROËN dealer or a qualified workshop is
essential when replacing or disconnecting the
battery.
Unless other wise indicated, check these components in accordance with the maintenance and warrant
y guide and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
Dependin
g on the environment (e.g. dustyatmosphere) and the use of the vehicle(e.g. city driving), replace them twiceas often if necessar y.y
A clogged passenger compar tment filter may have an adverse effect on the performance
of the air conditioning system and generateundesirable odours.
Particle emissions filter (Diesel)
The start of saturation of thepar ticle filter is indicated by the
fixed illumination of this warning lamp accompanied by a warning
message.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, thisindicates a low additive level.


On a new vehicle, the first par ticlefilter regeneration operations may beaccompanied by a "burning" smell,
which is perfectly normal.
Following prolonged operation of thevehicle at very low speed or at idle, you may, in exceptional circumstances, notice the emission of water vapour atthe exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment. When carrying out work on the battery, re
fer
to the "12 V battery" section for details of theprecautions to be taken before disconnecting
the battery and following its reconnection.

9
327
Technical data

* The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).











Diesel engines and gearboxes

.../S: e-HDi model fitted with Stop & Start.3D...:CITROËN C4 Picasso (5-seat).3E...:
CITROËN Grand C4 Picasso (5-seat). 3A...:
CITROËN Grand C4 Picasso (7- s e at).
Diesel enginese-HDi 150 Airdream
Gearboxes

Manual(6-speed)

Automatic
(6-speed)
Model codes:3D... 3E... 3A...
AHXM/S - M/1S


AHXT/S - T/1S

Cubic capacity (cc)

1 997
Bore x stroke
(mm) 85 x 88

Max power * : EU standard
(kW)
11 0

Max power engine speed (rpm) 3 750
Max torque: EU standard
(Nm)370

Max torque en
gine speed (rpm) 1 750

F
uel

Diesel

Catalytic converter
yes

Particle emission filter
yes
Oil capacities (in litres)

Engine (with filter replacement) 6.1

359
Level 1Level 2Level 3Comments
Navigation

Settings
Navi
gationRecent destinations
Display recent destinations
Calculator
y criteria
Fastest
Choose the navigation criteria.
The map displays the route chosen according to these criteria.
Shortest
Tim
e/distance
Ecolo
gical
T
olls
Ferries
Strict - Close
Show route on map Display the map and start navigation.
Confi rm
Save the options.
Save current location Save the current address.
Stop navi
gation Delete the navigation information.
Voice synthesis Choose the volume for voice and announcement of street names.
Diversion
Detour from your initial route by a certain distance.
Navi
gation


Map

Zoom in.

Zoom out.
Use the arrows to move the map.
Calculatory criteria
Add a waypoint.

Switch to 2D map.

364
05
Towards a new destination


Choosing a new destination

Select "Enter destination
".

Select "Save " to save the address entered as acontact entry.
The s
ystem allows up to 200 entries.
Select "Confi rm" or press "Show route on map " to start navigation guidance. Select "Address
".

Select the " Country:
" from the list offered then in the same way :
th
e " City:" or its post code, the "Road:
", the
" N°:
". Confi rm each time.
Select "Navigate to".

Choose the restriction criteria : "Include tollroads", " Include ferries
", "Traffi c", " Strict
","Close".

Choose the navigation criteria : " Fastest
" or
" Shortest " or " Time/distance" or "Ecological".

To delete navi
gation information, press on
" Settings
" then " Stop navigation
".

To restore the navi
gation information press on
"Settings
" then " Resume navigation".

Press on Navigation
to display the primary page then go to the secondary page.
NAVIGATION - GUIDANCE

393
Level 1Level 2Level 3Comments
Telephone
Secondary page
Bluetooth menuSearch
Start the search for another peripheral device to connect.
Disconnect Stop the Bluetooth connection to the selected peripheral device.
Update Import the contacts from the selected telephone to store them in the audio system.
Delete
Delete the selected telephone.
Confi rm

Save the settings.
Telephone
Secondary page
Search for devicesTele
phone profi le
Start the search for peripheral devicesStreaming profi le
Internet pro
fi le
Telephone
Secondary page
Telephone optionsPut on hold
Cut the microphone temporarily so that the contact cannot hear your conversation with a passenger.
Update
Import the contacts from the selected telephone to save then in the audio system.
Choice of rin
gtone: Choose the telephone ringtone and volume.
Memory info. Contact records used and free, percentage of storage space used by internal contacts and Bluetoothcontacts.
Confi rm

Save the settings.

.
409
Alphabetical index
Paint colour code..........................................333Panoramic glass sunroof..............................f220Parcel shelf, rear...........................................r130Park Assist .................................................... 194Parking brake, electric..........................141, 322Parking lamps...............................................206Parking sensors, front ...................................190Parking sensors, rear....................................r189Particle emission filter...................r310, 319-321Passenger compartment filter......................r321Port, USB......................................................122Priming the fuel system ................................317Protecting children ........103, 234, 236, 243-259Puncture........................................................260
Replacing the air filter...................................r321Replacing the oil filter...................................r321Replacing the passenger compartment filter......................................r321Replacing wiper blades.........................218, 299Resetting the service indicator.......................r52Resetting the trip recorder..............................r54Reversing camera .........................................191Reversing lamp.....................................283-286Risk areas (update).......................................367Roof bars .......................................................304Routine checks.....................................321, 322Running out of fuel (Diesel) ..........................317
R
P
Safety for children.........103, 234, 236, 243-259Scented air freshener...................................r116Screen menu.......................342,344, 346,358,360, 362, 378,390,392Screenwash, front.........................................216Screenwash fluid level ..................................320Seat adjustment........................................84-94Seat belts..............................................230-234Seat configurations.........................................99Seats, electric.................................................86Seats, rear.................................................r92-98Serial number, vehicle..................................333Ser vice indicator.............................................r51Servicing.........................................................24Setting the clock .............................................57Sidelamps ............ 202, 206, 279, 281, 283,285Side repeater.................................................283Snow chains..................................................278
Radio.............................................................348RDS...............................................................350Reading lamps, rear......................................r125Rear foglamp ........................204, 283,285, 287Rear screen (demisting) ................................ 115Recharging the battery.................................297Reduction of electrical load..........................298Regeneration of the par ticle emissionsfilter.............................................................r321Reinitialising the remote control.....................70Remote control...........................................61-71Removable screen (snow shield) ..................306Removing a wheel........................................274Removing the mat......................................... 123Repair kit, puncture.......................................260Replacing bulbs....................................279-287Replacing fuses............................................288
S
Spare wheel...........................................271-273Speed limiter.........................................r167, 168Spotlamps, side ....................................210, 283Start ing using another battery .....................295Starting the vehicle...............135,137, 150, 15 4Steering mounted controls............................341Stopping the vehicle .............135,137, 150, 154Stop Start...............................60,114, 160,161,
295, 310,313,321Storage..........................................................118Storage boxes .......................................124, 126Storing driving positions .................................87Sun visor.......................................................r119Synchronising the remote control...................70Synthesiser, voice.........................................377System settings .............................................386
Table of weights............................324, 328-330Ta b l e s o f e ngines ..........................323,325-327Tables of fuses..............................................288Ta n k , fuel...............................................313, 315Te c hnical data.......................................323-330Te l e p h o ne.............................................394-398Te m p e r a t u r e a djustment ...............106, 107,109Te mperature control for heated seats ............90Temporary tyre repair kit...............................260TMC (Tr a f f i c i n f o)..........................................372Tools ......................................................268, 270Torch.............................................................134
