2013 Citroen C3 PICASSO RHD towing

3
Comfort
49
In order for these systems to be fully effective, follow the guidelines on operation andmaintenance below:)
If the interior temperature remains very high after the vehicle has been parked in
the sun for a considerable time, first ventilate the passenger compartment for a few minutes. Place the air flow control at a sufficient level to provide an adequate renewal of air in the passenger compartment.)
To obtain an even air distribution, take care not to obstruct the exterior air intake grilleslocated at the base of the windscreen, the nozzles, the vents and the air outlets, as well as the air extractor located in the passenger compar tment on both sides of the rear shelf. )
Do not cover the sunshine sensor, located on the dashboard (behind the instrument panel) ; this is used for regulation of the air conditioning system.)
Operate the air conditioning system for 5 to 10 minutes, once or twice a month to keep itin good working order. )
Ensure that the passenger compartment filter is in good condition and have the filter elements replaced regularly (refer to the "Checks" section). We recommend the use of a combined passenger compartment filter. Thanks to its second special active filter, it contributes to the purification of the air breathed by the occupants and the cleanliness of the passenger compartment (reduction of allergic symptoms, bad odours and greasy deposits).)
To ensure correct operation of the air conditioning system, you are also advised to haveit checked regularly.)
If the system does not produce cold air, do not use it and contact a CITROËN dealer or a qualified workshop.

The condensation created by the air conditioning results in a dischargeof water under the vehicle which is perfectly normal.
The air conditioning system does notcontain chlorine and does not present any danger to the ozone layer.

When towing the maximum load on a steep gradient in high temperatures, switching off theair conditioning saves engine power and so improves towing capacity.
Recommendations for ventilation and air conditioning

Fittings
100
2-position adjustable boot
The two-position adjustable boot floor allows you to:
- maximise the volume of the boot,
- par tition the boot
(stowing the rear shelf...),
- obtain a flat floor from the boot opening to
the front seats, when the rear bench seat isin the folded and fully back position.

Placing the adjustable boot fl oor in the low position
)
Lift the adjustable boot floor by pulling on
the strap.) Move the adjustable boot floor rear wards
and then down, following the guides on
the sides.



Placing the adjustable boot fl oor in the high position
)Lift the adjustable boot floor by pulling the strap.)Move the adjustable boot floor rearwards
then up to its high position.
In the high position, the adjustable boot floor
allows stowing of the rear parcel shelf and
fragile objects.
The ad
justable boot floor is fitted with four stowing rings to secure your loads using the net
available as an accessory.
Ensure that your boot is empty beforehandling the adjustable boot floor.

8
Safety
113














Direction indicators






Hazard warning lamps
)
Press this button, the direction indicators flash.
They can operate with the ignition off.
Automatic operation of
hazard warnin
g lamps
When braking in an emergency, depending on
the deceleration, the hazard warning lampscome on automatically.
They switch off automatically the first time youaccelerate. ) You can also switch them off by pressing
the button.










Horn
)
Press one of the spokes of the steering wheel.
Audible warning to aler t other road users to an
imminent danger.

"Motorway" function

Move the stalk briefly upwards or downwards,
without going beyond the point of resistance;
the corresponding direction indicators will flash 3 times. A visual warnin
g by means of the directionindicators to alert other road users to a vehiclebreakdown, towing or accident.
)Lower the lighting control stalk fully when moving to the left. )Raise the lighting control stalk fully when moving to the right.

If you forget to cancel the direction indicators for more than twenty seconds, the volume of the audible signal will increase if the speed is above40 mph (60 km/h).

Use the horn moderately and only in thefollowing cases:


- immediate danger,

- over taking a cyclist or pedestrian,

- when approaching an area wherethere is no visibility.

Driving
140
Deactivation
Reactivation
With the engine running, press button Ato deactivate the system permanently. The indicator lamp in the button comes on.
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure thatthe sensors are not covered with mud,frost or snow.
Press button A again to reactivate the system. The indicator lamp in the button goes off.
If there is an operating fault, when reverse gear
is engaged, the ser vice warning lamp comes
on, accompanied by an audible signal (shortbeep) and a message in the multifunction screen.

Practical information
156














Changing a wheel
The tools are installed under the boot floor.
For access to them:)open the boot, )remove the boot floor, )lift up the boot carpet, )remove the box containing the tools, )remove the polystyrene storage box.

Other accessories
5.
Removable towing eye.
Refer to the paragraph "Towing the vehicle".
Access to the tools
Procedure for changing a faulty wheel for the spare wheel using the tools provided with the vehicle.


List of tools

All of these tools are specific to your vehicle. Do not use them for other purposes.
1.Wheelbrace.
For removing the wheel trim and removing
the wheel fixing bolts. 2. Jack with integral handle.
For raising the vehicle. 3. "Bolt cover" tool.
For removing the bolt protectors (covers)on alloy wheels. 4.Socket for the security bolts (located in theglove box).
For adapting the wheelbrace to the special "security" bolts (if your vehicle has them).

11
Practical information
183





Towing the vehicle


Access to the tools

The towing eye is installed under the boot floor.
To gain access to it: )open the boot, )remove the adjustable boot floor, )lift up the boot carpet, )remove the towing eye from the tool holder.
Procedure for havin
g your vehicle towed or for towing another vehicle using a removable towing eye.
General recommendations
Obser ve the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The person at the wheel of the towed vehicle must have a valid driving licence.When towing a vehicle with all four wheels on the ground, always use an approved towingbar; rope and straps are prohibited. When towing a vehicle with the engine off, there is no longer any power assistance for braking or steering. In the following cases, you must always call on a professional recovery service: - vehicle broken down on a motor way or fast road, - 4 wheel drive vehicle, - when it is not possible to put the gearbox into neutral, unlock the steering, or release theparking brake, - towing with only two wheels on the ground, - where there is no approved towing bar available...

Practical information
184
To w i ng your vehicle
)On the front bumper, driver's side, removethe protective access cover located alongside the front fog lamp, using the flat
end of the towing eye.

)On the rear bumper, unclip the cover by pressing at the bottom. )Screw the towing eye in fully. )Install the towing bar. )Switch on the hazard warning lamps on
the towed vehicle.



To w i ng another vehicle
Failure to obser ve this special conditioncould result in damage to cer tainbraking components and the absenceof braking assistance the next time theengine is star ted.



When removing the protective accesscover, take care to avoid damaging thepaintwork with the towing eye.
)
Screw the towing eye in fully.)
Install the towing bar. )
Switch on the hazard warning lamps on the
towed vehicle.) Place the gear lever in neutral.

11
Practical information
185








Towing a trailer, ...
Driving advice


Cooling

Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its coolingcapacity is not dependent on the engine speed.) To lower the engine speed, reduce your speed.
The maximum towed load on a long incline depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
Side wind
) Take into account the increased sensitivityto side wind.

)If the warning lamp and the STOPwarning lamp come on, stop the
vehicle and switch off the engine
as soon as possible.
Towbar suitable for the attachment of a trailer or installation of a bic
ycle carrier, with additional lighting and signalling.
Distribution of loads
)
Distribute the load in the trailer so that the
heaviest items are as close as possible to
the axle and the nose weight approaches the
maximum permitted without exceeding it.
Air density decreases with altitude, thusreducing engine per formance. Above
1 000 metres, the maximum towed load must
be reduced b
y 10 % for every 1 000 metres of altitude.

We recommend the use of genuine CITROËN towbars and their harnesses that have been tested and approvedfrom the design stage of your vehicle,and that the fitting of the towbar isentrusted to a CITROËN dealer or aqualified workshop.
If the towbar is not fitted by a CITROËN dealer, it is imperative that it isfitted in accordance with the vehiclemanufacturer's instructions.

Driving with a trailer places greater demands
on the towing vehicle and the driver must takepar ticular care.

Your vehicle is primaril
y designed for transporting people and luggage, but it may also be used for towing a trailer.
R
efer to the "Technical data" section for details
of the weights and towed loads which apply toyour vehicle.
