2013 Citroen C3 PICASSO RHD navigation

.Familiarisation
7
This air freshener diffuser diffuses the
fragrance that you have selected throughout
the passenger compar tment by means of its
location in the ventilation system.

Dual-zone digital air conditioning

This system allows you to set a different level of comfort for the driver and front
passenger. It then controls this level
automatically relative to the ambientconditions.

Cruise control / Speed limiter

These two functions control the speed of
the vehicle in relation to the value that
you have programmed.

Audio and communication
systems
These systems benefit from the latest
technology: MP3 compatible audiosystem, eMyWay audio and navigationsystem, auxiliary sockets, emergency or assistance call. 5
6
53
135 / 137
199
Interior

Multifunction screens
38







Monochrome screen A associated with the eMyWay satellite
navigation colour screen
This displays the following information:
- ambient temperature (this flashes if there isa risk of ice),
- trip computer (refer to the end of the
section).
Warning messages or information messagesmay appear temporarily. These can be cleared
by pressing the "Back"
button.


Controls

There are three display control buttons:


- "Back"
to abandon the operation in
progress,-"MENU"to scroll through the menus or sub-menus, -"OK"
to select the menu or sub-menu
required.


Main menu
)Press the "MENU"
button to scroll through
the various menus of the main menu:- vehicle configuration,
- options,
- language,
- units. )Press the "OK"button to select the menurequired.
Displays in screen A

2
Multifunction screens
39
Options
Once the "Options" menu has been selected, you can star t diagnostics of the status of the
equipment (active, not active, faulty).
Language
Once the "Language" menu has been
selected, you can change the language used
by the display (Français, Italiano, Nederlands,
Portugues, Portugues-Brasil, Deutsch, English,
Espanol).

Units
Once the "Units" menu has been selected, you can change the units of the followingparameters:


- temperature (°C or °F),

- fuel consumption (l/100 km, mpg or km/l).
The chosen language will also be usedin the eMyWay satellite navigationcolour screen.
For safety reasons, configuration of the multifunction screen by the driver mustonly be done when stationary.

Once the fuel consumption unit has been changed to l/100 km or km/l, the information relating to speed anddistance also changes to kilometres.

Vehicle confi guration
Once the "Vehicle configuration" menu has
been selected, you can activate or deactivate
the following systems:


- wiper linked with reverse gear (refer to the
"Visibility" section),

- "guide-me-home" lighting (refer to the
"Visibility" section),

- daytime lighting (refer to the "Visibility" section).

Multifunction screens
40
Displays in the eMyWay
satellite navi
gation colour
screen

Display confi guration

This menu allows you to adjust the brightness
of the display, the display contrast and the colour of the map (day/night and auto mode) to
set the date and time, the date format, the time format....
Setting the date and time) Press the SETUP button.)
Select the "Date & Time" function and
press the dial to confirm.
) Select the "Set date & time" function and
press the dial to confirm.
Voice synthesis
This menu allows you to adjust the voicesynthesis.
For more information, refer to the Audio and
telematics section.
Vehicle parameters
This menu allows cer tain systems to be activated or deactivated. This displa
ys the following information:
- time,
- date,
- audio functions,
- navigation system information.


"SETUP" menu

Press the SETUP button to access the
"SETUP"
menu. It gives you access to thefollowing functions:


- Display configuration,

- Voice synthesis,

- Vehicle parameters.

- Tr i p c o m p u t e r.


For safety reasons, configuration of the multifunction screen by the driver mustonly be done when stationary.


Tr ip computer

This menu allows trip computer information to
be displayed.
)Adjust the settings one by one using the
directional arrows confirming each time
with the dial.)Select the "Date format" function and press
the dial to conform. )Confirm the desired format using the dial.)Select the "Time format" function andpress the dial to confirm. )Confirm the desired format using the dial.

2
Multifunction screens
47





Tr ip computer, a few definitions


When the range falls below 20 miles (30 km),
dashes are displayed. After filling with at least5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).
Range
(miles or km)The distance which can still be
travelled with the fuel remainingin the tank. Related to theaverage fuel consumption over
the last few miles (kilometres)travelled.


Current fuel consumption
(mpg or l/100 km or km/l)
Calculated over the last few seconds.


Average fuel consumption
(mpg or l/100 km or km/l)
Calculated since the last trip
computer reset.


Distance travelled
(miles or km)
Calculated since the last tripcomputer reset.
Average speed
(mph or km/h)Calculated since the last trip computer reset.
Distance remaining todestination
(miles or km)This is the distance remaining to be
travelled to the final destination. It
is either calculated instantly by the
navigation system, if guidance isactivated, or entered by the user.
If the distance is not entered, dashes
are displayed in place of the digits.

Stop & Start time counter
(minutes / seconds or hours / minutes)
If your vehicle is fitted with Stop & Star t, a time counter calculates the
time spent in STOP mode during a journey.
It resets to zero ever
y time theignition is switched on with the key.

If dashes are displayed continuouslywhile driving in place of the digits, contact a CITROËN dealer or aqualified workshop.


This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.
This function is only displayed from 20 mph (30 km/h).

9
Driving
141





Reversing camera

A reversing camera is activated automatically
when reverse gear is engaged.
The colour image is provided in the navigationscreen.
The space between the blue lines represents thewidth of your vehicle except for the door mirrors.
The blue lines represent the general direction of the vehicle.
The red lines represent a distance of about
30 cm beyond the edge of your vehicle's
rear bumper. The audible signal becomes
continuous from this limit.
The green lines represent distances of
about 1 and 2 metres beyond the edge of your
vehicle's rear bumper.


Clean the reversing camera regularly using a soft, dry cloth.



The reversing camera cannot in any circumstances be a substitute for thevigilance and responsibility of the driver.

11
Practical information
173

Dashboard fuses

The fusebox is located in the glove box.


Access to the fuses
)
refer to the paragraph "Access to the tools".

Fuse tables
Fuse N°RatingFunctions
FH36 5
A Tr a i l e r r e l ay unit.
FH3
715 A Trailer accessories socket supply.
FH3
820 A Navigation.
FH39
- Not used.
FH4
030 A Tr a i l e r r e l ay unit.
Fuse N°RatingFunctions
F115 A Rear wiper.
F2
- Not used.
F3
5 A Airbags and pretensioners control unit.
F410 A Steering wheel angle sensor, air conditioning, clutch switch,
par ticle filter pump, diagnostic socket, air flow meter.
F530 A Electric windows panel, passenger's electric window control,
front electric windows motor.
F
630 A Rear electric windows motor and driver's electric window motor.
F7
5 A Courtesy and front map reading lamps, torch, rear reading lamps.

Practical information
174
Fuse N°RatingFunctions
F8
20 A Multifunction screen, audio system, navigation radio.
F
930 A
Audio system (fitted as an option), 12 V socket.
F1
015 A Steering mounted controls.
F1115 A
Ignition, diagnostic socket.
F12 15 A
Rain / sunshine sensor, trailer rela
y unit.
F13 5
A Main stop switch, engine relay unit.
F1415 A Parking sensors control unit, seat belt unfastened warninglamp, airbag control unit, instrument panel, air conditioning,USB Box.
F1
530 A
Locking.
F1
6- Not used.
F1740 A
Rear screen and door mirrors demist/defrost.
S
H- PA RC shunt.
