Page 131 of 284
9
Driving
129
) Select position M.
To engage reverse gear R
, the vehicle must be
immobilised with your foot on the brake pedal.
) Select position R.
At very low speed, if reverse gear is requested,
this will only be acted on when the vehicle is
immobilised.
At high speed, if reverse gear is requested,
the N indicator flashes and the gearbox goes into neutral. To engage a gear again, put thegear lever in position A
or M.
Te m p o r a ry control of gear changing
You can temporarily take over control of gear changing using the "+"and "-"
steering mounted paddles: if the engine speed allows,
the request to change gear is acted on.
This function allows you to anticipate cer tain situations such as over taking a vehicle or the
approach to a corner.
After a few moments without any action on
the control paddles, the gearbox resumes
automatic control of the gears. The
gears engaged appear in
succession in the instrument panelscreen.
The
gear change requests are only acted on if
the engine speed permits.It is not necessary to release the accelerator
during gear changes.
When brakin
g or slowing down, the gearbox changes down automatically to allow the
vehicle to accelerate in the correct gear. On sharp acceleration, the gearbox will notchange up unless the driver acts on the gear lever or the steering mounted paddles.
Never select neutral Nwhile the vehicle is moving.
You can change mode at any time, bemoving the gear lever from M to A
or the other way round.
Engagement of reverse gear isaccompanied by an audible signal.
Manual mode
Reverse
Page 132 of 284
Driving
130
Stopping the vehicle
Operating fault
With the ignition on, the flashing of AUTO ,
accompanied by an audible signal and a
message in the screen, indicates a malfunction
of the gearbox.
Have it checked by a CITROËN dealer or aqualified workshop.
In all cases when parking, you must apply the parking braketo immobilise the vehicle.
When immobilising the vehicle, with theengine running, you must place the gear lever in neutral N.
Before carrying out any work in the
engine compartment, ensure that the gear lever is in neutral N
and that theparking brake is applied. Be
fore switching off the engine, you can:
- move to position Nto engage neutral,
or
- leave the gear engaged; in this case, it will not be possible to move the vehicle.
Page 133 of 284
9
Driving
131
Hill start assist
(with the 6-speed
electronic gearbox
system)
System which holds your vehicle temporarily (approximately 2 seconds) when star ting on a slope, the time it takes to move your foot from
the brake pedal to the accelerator pedal.
This function is onl
y active when:
- the vehicle is completely stationary, with your foot on the brake pedal,
- certain conditions on a slope are met,
- with the driver’s door closed.
The hill start assist function cannot bedeactivated.On an ascendin
g slope, with the vehicle
stationar y, the vehicle is held momentarily
when
you release the brake pedal:- provided you are in automated mode(position A) or in manual mode (position AM )
on an electronic gearbox.On a descendin
g slope, with the vehicle
stationar y and reverse gear engaged, the
vehicle is held momentarily when you
release the brake pedal.
Operating fault
If a malfunction of the system occurs, these
warning lamps come on. Contact a CITROËN
dealer or a qualified workshop to have the system checked.
Do not leave the vehicle while it is being held in the hill star t assist phase. If you need to leave the vehicle withthe engine running, manually applythe parking brake then ensure that the parking brake warning lamp is on (not flashing) in the instrument panel.
Operation
Page 134 of 284
Driving
132
Stop & Start The Stop & Star t system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The engine restar ts automatically - START mode - as soon as you want to move off. The restart takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Star t system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.
Operation
Going into engine STOP mode
The "ECO"warning lamp comes
on in the instrument panel and the
engine goes into standby:
- with the 6-speed electronic
gearbox
system, at speeds below 5 mph (8 km/h),
when you press the brake pedal or put thegear lever in position N.
A time counter calculates thesum of the periods in STOP
mode during a journey. It rests
itself to zero every time the
ignition is switched on with thekey.
Special cases: STOP mode not available
STOP mode is not invoked when:
- the driver's door is open,
- the driver's seat belt is not fastened,
- the vehicle has not exceeded 6 mph(10 km/h) since the last engine start usingthe key,
- the engine is needed to maintain acomfortable temperature in the passenger compartment,
- demisting is active,
- some special conditions (battery charge,
engine temperature, braking assistance,ambient temperature...) where the engine isneeded to assure control of a system.
The "ECO"warning lamp flashes for
a few seconds then goes off.
This operation is per fectly normal.
Never refuel with the engine in STOPmode; you must switch off the ignition with the key.
For your comfor t, during parkingmanoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear.STOP mode does not affect the functionality of the vehicle, such as for example, braking, power steering...
Page 135 of 284
9
Driving
133
Going into engine START mode
The "ECO"warning lamp goes
off and the engine starts with theelectronic gearboxsystem:
- gear lever in position Aor M
, when yourelease the brake pedal,
- or gear lever in position N
and the brake pedal released, when you move the gear lever to position A
or M,
- or when you engage reverse gear.
Special cases: START invoked automatically
For reasons of safety and for your comfort,START mode is invoked automatically when:
- you open the driver's door,
- you unfasten the driver's seat belt,
- the speed of the vehicle exceeds 7 mph(11 k m/h) with the electronic gearbox system,
- some special conditions (battery charge,engine temperature, braking assistance,
ambient temperature...) where the engine is
needed for control of a system.
Th
e "ECO"
warning lamp flashes for
a
few seconds, then goes off.
This operation is per fectly normal.
Deactivation
At any time, press the "ECO OFF"
switch todeactivate the system.
This is confirmed by the switch warning lamp coming on accompanied by a message in the screen.
If the system has been deactivatedin STOP mode, the engine restar ts immediately.
Page 136 of 284
Driving
134
Operating fault
In the event of a fault with the system, the
"ECO OFF"
switch warning lamp flashes thencomes on continuously.
Have it checked by a CITROËN dealer or aqualified workshop.
In the event o
f a fault in STOP mode, the
vehicle may stall. All of the warning lamps in the instrument panel come on. It is then
necessary to switch off the ignition and star t
the engine again using the key.
Maintenance
This system requires a battery with a specialspecification and technology (reference numbers available from a CITROËN dealer or a qualified workshop).
Fitting a battery not listed by CITROËN introduces the risk of malfunction of
the system.
Before doing anything under the bonnet,deactivate the Stop & Start system toavoid any risk of injury resulting from automatic operation of STA R T m o d e .
The Stop & Star t system makes use of advanced technology. All workon this type of battery must be doneby a CITROËN dealer or a qualifiedworkshop.
Press the "ECO OFF"switch again.
The system is active again; this is con
firmed
by the switch warning lamp going off,accompanied by a message in the screen.
The system is reactivated automaticallyat every new star t using the key.
Reactivation
Page 142 of 284
Driving
140
Deactivation
Reactivation
With the engine running, press button Ato deactivate the system permanently. The indicator lamp in the button comes on.
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure thatthe sensors are not covered with mud,frost or snow.
Press button A again to reactivate the system. The indicator lamp in the button goes off.
If there is an operating fault, when reverse gear
is engaged, the ser vice warning lamp comes
on, accompanied by an audible signal (shortbeep) and a message in the multifunction screen.
Page 145 of 284
10
Checks
143
Bonnet
)
Push the exterior safety catch Bto the leftand raise the bonnet.
)
Unclip the stay C
from its housing. )
Fix the stay in the notch to hold the bonnet open.
Closing
)
Take the stay out of the support notch. )
Clip the stay in its housing. )
Lower the bonnet and release it at the endof its travel. )
Pull on the bonnet to check that it is secured correctly.
)Open the front left door. )Pull the interior bonnet release lever A ,
located at the bottom of the door aper ture.
Opening
Before doing anything under the bonnet,
switch off the Stop & Star t system toavoid any risk of injury resulting from anautomatic change to STA R T m o d e .
The location of the interior bonnet release lever prevents opening of the bonnet while the front left door is closed.
Do not open the bonnet in high winds.
When the engine is hot, handle theexterior safety catch and the bonnetstay with care (risk of burns).
