2013 Citroen C3 PICASSO RHD stop start

Multifunction screens
46
- the current information
tab with:
●
the range,
●
th
e current fuel consumption,
●
the distance remaining to be travelled or the Stop &Start time counter,
Monochrome screen C


Information displays
)
Press the button, located at the end of
the wiper stalk, to display the various tripcomputer tabs in succession:
- the trip
"1"tab with:
●
the distance travelled,
●
the avera
ge fuelconsumption,
●
the average speed,for the first trip.

- the tri
p "2"tab with:


●
the distance travelled,

●
the avera
ge fuel
consumption,

●
the average speed, for the second trip.
)Pressing the button again returns you to
the normal display.

Trip zero reset
)When the trip required is displayed, press
the button on the end of the wiper stalk for
more than two seconds.
Trips "1"
and "2"are independent but their useis identical.
For example, trip "1"
can be used for daily figures, and trip "2"
for monthly figures.

2
Multifunction screens
47





Tr ip computer, a few definitions


When the range falls below 20 miles (30 km),
dashes are displayed. After filling with at least5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).
Range
(miles or km)The distance which can still be
travelled with the fuel remainingin the tank. Related to theaverage fuel consumption over
the last few miles (kilometres)travelled.


Current fuel consumption
(mpg or l/100 km or km/l)
Calculated over the last few seconds.


Average fuel consumption
(mpg or l/100 km or km/l)
Calculated since the last trip
computer reset.


Distance travelled
(miles or km)
Calculated since the last tripcomputer reset.
Average speed
(mph or km/h)Calculated since the last trip computer reset.
Distance remaining todestination
(miles or km)This is the distance remaining to be
travelled to the final destination. It
is either calculated instantly by the
navigation system, if guidance isactivated, or entered by the user.
If the distance is not entered, dashes
are displayed in place of the digits.

Stop & Start time counter
(minutes / seconds or hours / minutes)
If your vehicle is fitted with Stop & Star t, a time counter calculates the
time spent in STOP mode during a journey.
It resets to zero ever
y time theignition is switched on with the key.

If dashes are displayed continuouslywhile driving in place of the digits, contact a CITROËN dealer or aqualified workshop.


This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.
This function is only displayed from 20 mph (30 km/h).

Comfort
54
programme
The automatic comfor t programme
may not be sufficient to quicklydemist or defrost the windscreen
and side windows
(humidity, several
passengers, ice, etc.).
)To switch the system off, press this buttonagain or on "AUTO"
. The indicator lamp in
the button goes off and the indicator lamp in the "AUTO"
button comes on.
With Stop & Start, when demisting hasbeen activated, the STOP mode is notavailable.
)Press this button to activate the automatic
visibility programme. The indicator lamp in
the button comes on. The system automatically controls the air conditioning, the air flow and the air intake andprovides optimum distribution of the ventilation
to the windscreen and side windows. I
f you wish, you can make a different choice
from that offered by the system by changing
a setting. The other functions will still be controlled automatically.) Pressing the "AUTO"
button returns thesystem to completely automatic operation.
For maximum cooling or heating of the passenger compar tment, it is possible to exceed the minimum value 14 or the maximum value 28.)Turn control 2
or 3
to the left until "LO"
is displayed or to the right until "HI"is displayed.


Manual operation
)
Press this button to switch off
the air conditioning.

5. Air conditioning On / Off

Switching the system off could result in
discomfort (humidity, condensation).)Press this button again to return to automatic operation of the air conditioning.The indicator lamp in the "A/C"
buttoncomes on.

Access
66
Locating your vehicle
)Press the closed padlock to locate your locked vehicle in a car park.
This is indicated by lighting of the cour tesylamps and flashing of the direction indicators for a few seconds.


Electronic engine immobiliser

The key contains an electronic chip which has
a special code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
This electronic engine immobiliser locks theengine management system a few minutes
after the ignition is switched off and prevents
starting of the engine by anyone who does not have the key.
Anti-theft protection
In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal and a message in the screen.
Folding the key
)First press this button to fold the key.
If you do not press the button when foldingthe key, there is a risk of damage to the mechanism.

Ignition switch



- Position 1: Stop

- Position 2: Ignition

- Position 3: Starting


Starting the vehicle
)Inser t the key in the ignition switch.
The system recognises the star ting code. )Turn the key fully towards the dashboard toposition 3 (Starting).)When the engine starts, release the key. In this case,
your vehicle will not start; contact
a CITROËN dealer as soon as possible.
Keep safely the label attached to the keys given
to you on acquisition of the vehicle.

Access
68

Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would haveto be reinitialised.
No remote control can operate when the key is in the ignition switch, even when the ignition is switched off, except for reinitialisation.


Locking the vehicle

Driving with the doors locked may make access to the passenger compar tment by theemergency services more difficult in an emergency.
However, the vehicle unlocks automatically in the event of a serious impact causing airbag deployment. As a safety precaution, never leave children alone in the vehicle, except for a very shor t period.
In all cases, it is essential to remove the key from the ignition switch when leaving the vehicle.


Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions.


When purchasing a second-hand vehicle

Have the pairing of all of the keys in your possession checked by a CITROËN dealer, to ensure that only your keys can be used to open and start the vehicle.
Lost keys

Visit a CITROËN dealer with the vehicle's registration document, your personal identification documents and if possible the key code label.
The CITROËN dealer will be able to look up the key code and the transponder coderequired to order a new key.
Do not throw the remote controlbatteries away, they contain metals which are harmful to the environment.
Take them to an approved collectionpoint.

9
Driving
125





Parking brake


Applying
)Pull the parking brake lever fully up toimmobilise your vehicle.
When the vehicle is being driven, if this warning lampand the STOPwarning lamp come on, accompanied by an audible signal and a message on the
multifunction screen, this indicates that the parkingbrake is still on or has not been properly released.

Releasing
)Pull the parking brake lever gently, press
the release button then lower the lever fully.









6-speed manual
gearbox
Engaging 5th or 6th gear
) Move the lever fully to the right to engage 5th or 6th gear.



Engaging reverse gear
)
Raise the ring under the knob and move
the gear lever to the left then for wards.
When parking on a slope, direct your wheels against the pavement, apply the parking brake and engage a gear.

Only engage reverse gear when thevehicle is stationary with the engine at idle.

As a safety precaution and to facilitate starting of the engine:


- always select neutral,

- press the clutch pedal.

Driving
132








Stop & Start The Stop & Star t system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The engine restar ts automatically - START mode - as soon as you want to move off. The restart takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Star t system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.
Operation
Going into engine STOP mode
The "ECO"warning lamp comes
on in the instrument panel and the
engine goes into standby:
- with the 6-speed electronic
gearbox
system, at speeds below 5 mph (8 km/h),
when you press the brake pedal or put thegear lever in position N.
A time counter calculates thesum of the periods in STOP
mode during a journey. It rests
itself to zero every time the
ignition is switched on with thekey.

Special cases: STOP mode not available
STOP mode is not invoked when:


- the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded 6 mph(10 km/h) since the last engine start usingthe key,

- the engine is needed to maintain acomfortable temperature in the passenger compartment,

- demisting is active,

- some special conditions (battery charge,
engine temperature, braking assistance,ambient temperature...) where the engine isneeded to assure control of a system.

The "ECO"warning lamp flashes for
a few seconds then goes off.
This operation is per fectly normal.
Never refuel with the engine in STOPmode; you must switch off the ignition with the key.
For your comfor t, during parkingmanoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear.STOP mode does not affect the functionality of the vehicle, such as for example, braking, power steering...

9
Driving
133

Going into engine START mode
The "ECO"warning lamp goes
off and the engine starts with theelectronic gearboxsystem:


- gear lever in position Aor M
, when yourelease the brake pedal,

- or gear lever in position N
and the brake pedal released, when you move the gear lever to position A
or M,

- or when you engage reverse gear.

Special cases: START invoked automatically
For reasons of safety and for your comfort,START mode is invoked automatically when:
- you open the driver's door,
- you unfasten the driver's seat belt,
- the speed of the vehicle exceeds 7 mph(11 k m/h) with the electronic gearbox system,
- some special conditions (battery charge,engine temperature, braking assistance,
ambient temperature...) where the engine is
needed for control of a system.
Th
e "ECO"
warning lamp flashes for
a
few seconds, then goes off.
This operation is per fectly normal.

Deactivation
At any time, press the "ECO OFF"
switch todeactivate the system.
This is confirmed by the switch warning lamp coming on accompanied by a message in the screen.


If the system has been deactivatedin STOP mode, the engine restar ts immediately.
