2013 Citroen C3 PICASSO sensor

Driving
140





Rear parking sensors System comprising four proximity sensors, located in the rear bumper.
This detects obstacles
(person, vehicle, tree, gate, etc.) behind the vehicle. However, itcannot detect obstacles located just below thebumper. Activation
The system is activated as soon as reverse gear is engaged, accompanied by an audiblesignal. The proximity information is given by:
- an audible signal, which becomes more
rapid as the vehicle approaches the
obstacle,
- a
graphic in the multifunction screen, with
blocks which become increasingly closer to
the vehicle (depending on version).
Detection zone

When the distance between the rear of thevehicle and the obstacle is less than thirtycentimetres, the audible signal becomescontinuous and the "Danger" symbol appears
in the multifunction screen.
On completion of the manoeuvre, when you exit
reverse gear, the system becomes inactive. An object, such as a stake, a roadworks cone or any other similar object may be detected at the beginning of themanoeuvre, but may no longer be detected when the vehicle comes close to it.
The parking sensors system cannot, in any circumstances, take the place of the vigilance and responsibility of thedriver.

9
Driving
141

Deactivation Reactivation

With the engine running, press button A
todeactivate the system permanently. Theindicator lamp in the button comes on.
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure that the sensors are not covered with mud,frost or snow.
Press button Aagain to reactivate the system.
The indicator lamp in the button goes o
ff.
If there is an operating fault, when reverse gear is engaged, the ser vice warning lamp comes
on, accompanied by an audible signal (short
beep) and a message in the multifunction screen.

Practical information
174

Dashboard fuses

The fusebox is placed in the lower dashboard(left-hand side).


Access to fuses
)
refer to the paragraph "Access to tools".


Fuse tables
Fuse N°RatingFunctions
FH3
65 A Tr a i l e r r e l ay unit.
FH37 15 A
Trailer accessories socket supply.
FH3
820 A Aftermarket navigation.
FH39
20 A Heated seats.
FH4
030 A Tr a i l e r r e l ay unit.
Fuse N°RatingFunctions
F115 A Rear wiper.
F2
- Not used.
F
35 A Airbags and pretensioners control unit.
F410 A Steering wheel angle sensor, air conditioning, clutch switch, par ticle filter pump, diagnostic socket,airflow meter.
F530 A Electric window switch panel, passenger's electric windowcontrol, front electric window motor.
F
630 A
Rear electric window motor and driver's electric window motor.
F7 5
A Courtesy and front map reading lamps, glove box lighting,
torch, rear reading lamps.

11
Practical information
175
Fuse N°RatingFunctions
F
820 A Multifunction screen, audio system, navigation radio.
F
930 A Audio system (aftermarket), 12 V socket.
F1
015 A Steering wheel controls.
F1115 A
Ignition, diagnostic socket.
F12 15 A
Rain / sunshine sensor, trailer rela
y unit.
F1
35 A Main stop switch, engine relay unit.
F1415 A Parking assistance control unit, seat belt unfastened warninglamp, airbag control unit, instrument panel, air conditioning,USB Box.
F1
530 A Locking.
F1
6- Not used.
F1740 A
Rear screen and door mirrors demist/defrost.
S
H- PA RC shunt.

Practical information
178
Fuse N°RatingFunctions
F1230 A Windscreen wipers slow / fast speed.
F13
40 A Built-in systems inter face supply (ignition positive).
F14
30 A Valvetronic supply (petrol).
F1
510 A Right-hand main beam headlamp.
F1
610 A
Left-hand main beam headlamp.
F17 15 A
Left-hand dipped beam headlamp.
F18 15 A
Ri
ght-hand dipped beam headlamp.
F1
915 A Multifunction engine management supply (petrol engine),
air cooling electrovalves (Diesel).
F20 10 A Multi
function engine management supply (petrol engine),
Turbo pressure regulation electrovalve (Diesel), engine coolantlevel sensor (Diesel).
F2
15 A Fan assembly control supply, APC, ABS ESP relays.

11
Practical information
187











Fitting roof bars
To fit longitudinal and/or transverse roof bars, visit your CITROËN dealer or a qualified workshop.
Maximum authorised weight on the roof rack: 60 kg. If the height exceeds 40 cm, adapt the speed of the vehicle to the profile of the road to avoid
damaging the roof bars and the fixings on the roof. Be sure to refer to national legislation in order to comply with the regulations for transporting objects which are longer than the vehicle.


Braking

Towing a trailer increases the braking distance.
To avoid overheating of the brakes on a longmountain type of descent, the use of engine
braking is recommended.
Tyres
)Check the tyre pressures of the towingvehicle and of the trailer, obser ving the recommended pressures.



Lighting
)Check the electrical lighting and signalling on the trailer.



The rear parking sensors will be deactivated automatically if a genuine
CITROËN towbar is used.

Practical information
188
"Comfort":
front and rear parking sensors, insulated module, reading lamp, sun blinds, head restraint-mounted coat hanger, centre armrest, air deflector, scented air freshener car tridges, portable ashtray, solar films for windows...


"Protection":

mats *
, seat covers, mudflaps, bumper protectors, vehicle protective cover, dog guard,pet seat and boot covers...
"Transport solutions":
boot liner, boot carpet, towbar, towbar wiring harness, transverse and longitudinal roof
bars, bicycle carrier, ski carrier, roof box, bootspacers, boot net, business/commercial vehicle
conversion kit, sliding boot floor...

"Safety and security":

anti-theft alarm, warning triangle, high visibility
vest, breathalyzer, first aid kit, snow chains,
non-skid covers, security wheel bolts, vehicle
tracking system, child seats, fire extinguisher,
caravan mirror, glass security films...


"Style":

allow wheels, chromed mirror shells, leather
steering wheel, gear lever knob, aluminium
footrest, wheel caps...





Accessories A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
They are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.

*
To avoid any risk of jamming of the pedals:
- ensure that the mat is positioned and
secured correctl
y,
- never fit one mat on top of another.

.
277 Alphabetical index
