2013 Citroen C3 bluetooth

06
262

RECEIVING A CALL

An incomin
g call is announced by a ring and a superimposed
display in the vehicle's screen.

Select the YES tab on the display
using the buttons and confi rm bypressing OK.

Press this button to acce
pt the call.
MAKING A CALL

From the Bluetooth telephone
function Audio menu, select Manage
the telephone call then Call, Call list or Directory.

Pr
ess this button for more than two seconds for
access to your directory, then navigate with the
thumb wheel.

Or

To dial a number, use your telephone's keypad,with the vehicle stationary.

Durin
g a call, press this button for more than2 seconds.

Confi rm with OK to end the call.
BLUETOOTH FUNCTIONS


ENDING A CALL

06
263

Initiate the pairing between the telephone and
the vehicle. This pairing can be initiated from
the vehicle's telephone function menu or via the
telephone's ke
ypad. See steps 1 to 9 on theprevious pages. During the pairing phase, the
vehicle must be stationary with the key in the
i
gnition.
Select the telephone to be connected from the telephone functionmenu.
The audio s
ystem connects to a newly paired telephone automatically.






BLUETOOTH AUDIO STREAMING *


Wireless transmission of the telephone's music fi les via the audioequipment. The telephone must be able to manage the appropriate
Bluetooth profi les (Profi les A2DP / AVRCP).
*

Depending on the compatibility of the telephone.
**

In certain cases, playing of the Audio fi les must be initiated from the
keypad.
***
If the tele
phone supports the function.
Activate the streaming source by
pressin
g the SOURCE button ** .
The tracks to be played can becontrolled as usual via the buttons on
the audio system control panel and
the steering mounted controls *** .
The contextual information can bedisplayed on the screen.
BLUETOOTH FUNCTIONS

07
268
SCREEN MENU MAP

BLUETOOTH TELEPHONE
Connect/Disconnect a device
Consult the paired device BLUETOOTH CONFIGURATION
Telephone function
Audio Streamin
g function
Delete a paired device
P
erform a Bluetooth search
Calls lis
t
CALL

Directory
Terminate the current call MANAGE THE TELEPHONE CALL
Activate private mod
e
1
2
3
3
3
4
4
4
2
3
4
2
3
3
video brightness adjustment
DISPLAY CONFIGURATION DEFINE THE VEHICLE PARAMETERS *



PERSONALISATION-CONFIGURATION
normal video
inverse video
bri
ghtness (- +) adjustment
date and time adjustment
day/month/year adjustment
hour
/minute adjustment
choice of 12 h / 24 h mode
choice of units
l/100 km - mp
g - km/l
°
Celsius / °Fahrenheit
CHOICE OF LANGUAGE
1
2
4
3
2
4
4
3
4
4
2
3
4
4
4
* The parameters vary according to vehicle.

269
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWERSOLUTION

There is a difference insound quality between thedifferent audio sources (radio, CD...).
For optimum sound quality, the audio settings (Volume, Bass, Treble,Ambience, Loudness) can be adapted to the different sound sources, whichmay result in audible differences when changing source (radio, CD...).

Check that the audio settings (Volume, Bass, Treble, Ambience, Loudness) are adapted to the sources listened to. It is advisable to set the AUDIOfunctions (Bass, Treble, Front-Rear Balance, Left-Right Balance) to the middle position, select themusical ambience "None" and set the loudness correction to the "Active" position in CD mode or tothe "Inactive" position in radio mode.

The CD is ejected automatically or is not played by the player.
The CD is inserted upside down, is unplayable, does not contain any audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not recognised by the audio equipment.


- Check that the CD is inserted in the player the right way up.


- Check the condition of the CD: the CD cannot be played if it is too damaged.


- Check the content in the case of a recordedCD: consult the advice in the "Audio" section.


- The audio equipment's CD player does not play DVDs.


- Due to their quality level, certain writeable CDswill not be played by the audio system.

The message "USBperipheral error" is displayed on the screen.

The Bluetooth connection is cut.
The battery of the peripheral may not be suffi ciently charged.
Recharge the battery of the peripheral device.
The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick.

The CD player sound is poor. The CD used is scratched or of poor quality.
Insert good quality CDs and store them in suitableconditions.
The audio equipment settings (bass, treble, ambiences) are unsuitable. Set the treble or bass level to 0, without selectingan ambience.

.
Alphabetical index
275
ABS and EBFD systems.............................107Accessories ................................................182Accessory socket, 12V.................................91Adjusting headlamps....................................83Adjusting head restraints ..............................62Adjusting the steering wheel.........................65Airbags ...................................................97, 111Airbags, curtain ....................................113,114Airbags, front........................................111,114Airbags, lateral.....................................113,114Air conditioning.................................53, 54, 57Air conditioning, digital..................................57Air conditioning, manual ...............................54Air filter........................................................r142Air flow....................................................54, 58Air intake.................................................55, 58Air recirculation.......................................55, 58Air vents ........................................................52Ambient temperature (display) ......................23Anti-lock braking system (ABS)..................107Anti-pinch ......................................................70Anti-theft........................................................67Armrest, front................................................90Assistance call ....................................106,196Audible warning..........................................106Audio streaming (Bluetooth)...............236, 263Audio system...............................................251Automatic illumination of headlamps......79, 82Automatic operation of hazard warning lamps .... 105Automatic rain sensitive windscreen
wipers...................................................84, 86Auxiliary socket...................................237,260Auxiliary sockets ...................91, 237, 258, 260
Child lock.....................................................104Children ..........................................95-104,112Child seats ............................................95-103Child seats, conventional..............................98Clock .............................................................38Closing the boot......................................66, 75Closing the doors ....................................66,72Connectors, audio .................91, 237,258, 260Coolant level...............................................141Courtesy mirror.............................................r90Cruise control..............................................130Cup holder.....................................................r89
AB
C
Capacity, fuel tank........................................76CD MP3...............................................233,257Central locking........................................66, 73Changing a bulb ................................... 157-163Changing a fuse ...................................164-170Changing a wheel................................149-156Changing a wiper blade ........................86,175Changing the remote control battery ............68Changing the time.........................................38Checking levels ...................................140,141Checking the engine oil level................37, 140Checking tyre pressures (using the kit) ......148Checks .................................................138-143
Battery.................................................142, 171Battery, charging .........................................172Battery, remote control...........................68,69Black panel....................................................39Blind ................................................................6Bluetooth (hands-free)......................................220,261Bluetooth (telephone)..........................220, 261Bonnet .........................................................136Boot...............................................................75Boot lamp..............................................88,163Brake discs ..................................................143Brake lamps................................................161Brake pads .................................................. 143Braking assistance system .........................107
Daytime running lamps.................................83Deactivating the passenger airbag........................................................112Deactivating the rear windows......................71Defrosting ................................................56,59Demisting................................................56,59Dials and gauges .................................... 23, 24Diesel additive level....................................141Dimensions.................................................193Dipped beam .........................................79,158Dipstick..................................................37,140Direction indicators.....................105, 15 8, 161Doors.............................................................72Doors emergency control.............................74Door pockets .................................................89Driving economically ....................................21
D
