2013 Acura ZDX windshield wipers

Visual Index
6Quick Reference Guide
❙Fog Lights
(P134, 250)
❙How to Refuel
(P222)
❙Maintenance Under the Hood
(P235)
❙Windshield Wipers
(P135, 256)
❙Power Door Mirrors
(P143)
❙Tires
(P258, 277)
❙Door Lock/Unlock Control
(P108)
❙Headlights
(P132, 249)
❙Front Turn Signal/Parking/Side Marker/Daytime Running
Lights
(P132, 251)
❙High-Mount Brake Light
(P255)
❙Opening/Closing the Tailgate (P116)❙Tailgate Open Handle
(P117)
❙Stop/Taillights
(P253)
❙Rear Turn Signal Lights
(P253)
❙Rear Side Marker Lights
(P253)
❙Rearview Camera () See the Navigation Manual❙Rear License Plate Lights
(P255)
❙Back-Up Lights
(P254)

135
uuOperating the Switches Around the Steering WheeluWipers and Washers
Continued
Controls
Wipers and Washers
The windshield wipers and washers can be
used when the power mode is in ON.■MIST
The wipers run at high speed until you release
the lever.■Wiper switch (OFF, INT, LO, HI)
Change the wiper switch setting according to
the amount of rain.■Adjusting the delay
Turn the adjustment ring to adjust the wiper
delay.■Washer
Sprays while you pull the lever toward you.
When you release the lever, the wipers make
one more sweep before stopping.
1Wipers and WashersNOTICEDo not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.NOTICEIn cold weather, the blades may freeze to the
windshield, becoming stuck.
Operating the wipers in this condition may damage
the wipers. Use the defroster to warm the
windshield, then turn the wipers on.
If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens. When the vehicle starts moving, the
wipers make a single sweep.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.
Turn the washers off if no washer fluid comes out.
The pump may get damaged.
Intermittent Time
Adjustment RingPull to
use
washer.MIST
INT: Low speed with
intermittent OFF
LO: Low speed wipe
HI: High speed wipe
Long delay
Short delay

uuOperating the Switches Around the Steering WheeluWipers and Washers
136Controls
Turn the headlights on and press the
headlight washer button to operate.
The headlight washers also operate when you
turn the windshield washers for the first time
after the power mode is set to ON.
■Headlight Washers
*
1Headlight Washers
*
The headlight washers use the same fluid reservoir as
the windshield washers.
Headlight
Washer Button
* Not available on all models

322Index
Tires........................................................... 258
Air Pressure ..................................... 259, 306
Checking and Maintaining ....................... 258
Compact Spare Tire ................................. 277
Inspection ................................................ 258
Labeling................................................... 259
Puncture (Flat Tire) ................................... 277
Regulations.............................................. 261
Rotation .................................................. 265
Tire Chains .............................................. 266
Wear Indicators ....................................... 263
Winter ..................................................... 266
Tools.......................................................... 276
Towing a Trailer........................................ 177
Equipment and Accessories...................... 178
Load Limits .............................................. 177
Towing Your Vehicle................................ 181
Emergency............................................... 301
TPMS (Tire Pressure Monitoring
System).................................................... 208
Indicator ............................................ 72, 294
Transmission.............................................. 189
Automatic ............................................... 189
Fluid ........................................................ 245
Number ................................................... 307
Sequential Shift Mode ............................. 191
Shift Position Indicator ....................... 68, 190
Trip Meter................................................... 89Troubleshooting....................................... 275
Blown Fuse.............................................. 295
Brake Pedal Vibrates .................................. 16
Buzzer Sounds When Opening Door.......... 17
Emergency Towing .................................. 301
Engine Won’t Start .................................. 284
Noise When Braking .................................. 17
Overheating ............................................ 290
Premium Gasoline ........................... 221, 306
Puncture/Flat Tire .................................... 277
Rear Door Won’t Open...................... 16, 114
Select Lever Won’t Move ......................... 289
Warning Indicators .................................... 66
Turn Signals.............................................. 132
Indicators (Instrument Panel) ..................... 73
UUnder-floor Storage Area........................ 156
Unlocking the Doors................................ 108VVanity Mirrors............................................... 5
Vehicle Identification Number................ 307
Vehicle Stability Assist (VSA®).................. 202
Off Button............................................... 203
Off Indicator.............................................. 71
System Indicator ........................................ 71
Viscosity (Oil).................................... 238, 306
VSA® (Vehicle Stability Assist).................. 202
WWarning and Information Messages........ 79
Warning Indicator On/Blinking............... 292
Warning Labels.......................................... 64
Warranties (Warranty Manual provided
separately).............................................. 312
Watts........................................................ 306
Wear Indicators (Tire).............................. 263
Wheel Nut Wrench (Jack Handle)........... 281
Window Washers..................................... 135
Adding/Refilling Fluid .............................. 248
Switch .................................................... 135
Windows (Opening and Closing)............ 125
Windshield............................................... 135
Cleaning ................................................. 273
Washer Fluid ........................................... 248
Wiper Blades........................................... 256
Wipers and Washers ............................... 135
Winter Tires.............................................. 266
Snow Tires .............................................. 266
Tire Chains.............................................. 266
Wipers and Washers................................ 135
Checking and Replacing Wiper Blades..... 256
Worn Tires................................................ 258
