2013 Acura ZDX warning light

290Handling the Unexpected
OverheatingHow to Handle OverheatingOverheating symptoms are as follows:
•The temperature gauge needle is at the mark or the engine suddenly loses
power.
•Steam is coming out of the engine compartment.■First thing to do
1.Immediately park the vehicle in a safe place.
2.Turn off all accessories and turn on the hazard warning lights.
uNo steam or spray present: keep the engine running and open the hood.
uSteam or spray is present: turn off the engine and wait until it subsides.
Then open the hood.
1How to Handle OverheatingNOTICEContinuing to drive with the temperature gauge
needle at the mark may damage the engine.
3
WARNING
Steam and spray from an overheated
engine can seriously scald you.
Do not open the hood if steam is coming
out.
H
H

292Handling the Unexpected
Indicator, Coming On/BlinkingIf the Low Oil Pressure Indicator Comes On
■Reasons for the indicator to come on
Comes on when the engine oil pressure is low.■What to do as soon as the indicator comes on
1.Immediately park the vehicle on level ground in a safe place.
2.If necessary, turn the hazard warning lights on.■What to do after parking the vehicle
1.Stop the engine and let it sit for about three minutes.
2.Open the hood and check the oil level.2Oil Check P. 239
3.Start the engine and check the low oil pressure indicator.
uThe light goes out: Start driving again.
uThe light does not go out within 10 seconds: Stop the engine and
contact a dealer for repairs immediately.
If the Charging System Indicator Comes On
■Reasons for the indicator to come on
Comes on when the battery is not being charged.■What to do when the indicator comes on
Turn off the climate control system, rear defogger, and other electrical
systems, and immediately contact a dealer for repairs.
1If the Low Oil Pressure Indicator Comes OnNOTICERunning the engine with low oil pressure can cause
serious mechanical damage almost immediately.1If the Charging System Indicator Comes On
If you need to stop temporarily, do not turn off the
engine. Restarting the engine may rapidly discharge
the battery.

318Index
Engine Coolant......................................... 243
Adding to the Radiator ............................ 244
Adding to the Reserve Tank ..................... 243
Overheating............................................. 290
Temperature Gauge................................... 86
Engine Oil.................................................. 238
Adding .................................................... 240
Checking ................................................. 239
Displaying Oil Life .................................... 231
Low Oil Pressure Indicator .................. 66, 292
Recommended Engine Oil ........................ 238
Exhaust Gas Hazard
(Carbon Monoxide)................................... 63
Exterior Care (Cleaning)........................... 272
Exterior Mirrors......................................... 143FFeatures..................................................... 167
Filters
Dust and Pollen ....................................... 269
Oil ........................................................... 241
Flat Tire..................................................... 277
Floor Mats................................................. 271
Fluids
Automatic Transmission ........................... 245
Brake ....................................................... 246
Engine Coolant ........................................ 243
Windshield Washer .................................. 248
Fog Light Indicator..................................... 73
Folding Down the Rear Seats................... 150Foot Brake................................................ 213
Forward Collision Warning (FCW)........... 196
Front Airbags (SRS)..................................... 37
Front Seat Heaters and Seat
Ventilation.............................................. 161
Front Seats................................................ 144
Adjusting ................................................ 144
Fuel...................................................... 13, 221
Economy ................................................. 224
Gauge ....................................................... 86
Instant Fuel Economy ................................ 90
Low Fuel Indicator ..................................... 69
Range ....................................................... 90
Recommendation .................................... 221
Refueling................................................. 221
Fuel Economy........................................... 224
Fuel Fill Cap........................................ 13, 223
Message.................................................. 293
Fuel Fill Door...................................... 13, 222
Fuses
Locations................................................. 295
GGasoline (Fuel)
Economy ................................................. 224
Gauge ....................................................... 86
Information ............................................. 221
Instant Fuel Economy ................................ 90
Low Fuel Indicator ..................................... 69
Refueling................................................. 221Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 189
Glass (care)............................................... 273
Glove Box................................................. 154
HHalogen Bulbs.......................................... 250
Handling the Unexpected....................... 275
Hazard Warning Button.............................. 2
Head Restraints........................................ 146
Headlights................................................ 132
Aiming.................................................... 249
Automatic Operation .............................. 133
Dimming......................................... 132, 134
Operating ............................................... 132
Heaters (Seat)................................... 161, 162
High-Beam Indicator.................................. 73
HomeLink® Universal Transceiver........... 169IIdentification Numbers............................ 307
Engine and Transmission ......................... 307
Vehicle Identification............................... 307
Illumination Control................................ 137
Button .................................................... 137
Immobilizer System.................................. 122
Indicator ................................................... 74
Indicators.................................................... 66

319Index
ABS (Anti-lock Brake System) .................... 70
BSI (Blind Spot Information) ...................... 76
Charging System............................... 67, 292
CRUISE CONTROL ............................. 75, 194
CRUISE MAIN.................................... 75, 193
Door and Tailgate Open ...................... 26, 71
Fog Light .................................................. 73
Forward Collision Warning (FCW) ............. 77
High-Beam................................................ 73
Immobilizer System ................................... 74
Keyless Access System............................... 75
Lane Departure Warning (LDW) ................ 78
Lights On .................................................. 73
Low Fuel ................................................... 69
Low Oil Pressure ............................... 66, 292
Low Tire Pressure/TPMS ............ 72, 208, 210
Malfunction Indicator Lamp .............. 67, 293
Parking Brake and Brake System ....... 66, 294
Seat Belt Reminder.............................. 28, 69
Security System Alarm............................... 75
SH-AWD®......................................... 76, 204
Shift Position............................................. 68
Side Airbag Off ................................... 47, 74
Supplemental Restraint System ........... 45, 70
System Message ....................................... 72
Transmission ............................................. 68
Turn Signal ............................................... 73
VSA® (Vehicle Stability Assist)
System ............................................ 71, 202
VSA® OFF.......................................... 71, 203
Information.............................................. 305Information Buttons................................... 87
Instant Fuel Economy................................. 90
Instrument Panel........................................ 65
Brightness Control ................................... 137
Interior Lights........................................... 152
Interior Rearview Mirror.......................... 142
JJack (Wheel Nut Wrench)........................ 281
Jump Starting........................................... 287KKey Number Tag....................................... 107
Keyless Access System............................... 109
Keyless Lockout Prevention..................... 111
Keys........................................................... 106
Lockout Prevention .................................. 111
Number Tag ............................................ 107
Rear Door Won’t Open ............................ 114
Remote Transmitter ................................. 108
Types and Functions ................................ 106
Kickdown.................................................. 188
LLane Departure Warning (LDW)............. 199
LATCH (Child Seats).................................... 54
Lights................................................. 132, 249
Automatic ............................................... 133
Bulb Replacement ................................... 249
Daytime Running Lights........................... 134
Fog Lights ............................................... 134
High-Beam Indicator.................................. 73
Interior .................................................... 152
Light Switches ......................................... 132
Lights On Indicator .................................... 73
Turn Signals ............................................ 132
Load Limits................................................ 175
Locking/Unlocking.................................... 106
Auto Door Locking/Unlocking.................. 115
Childproof Door Locks............................. 114
From Inside ............................................. 113
From Outside .......................................... 108
Keys ........................................................ 106
Using a Key ..................................... 109, 111
Lockout Prevention System..................... 111
Low Battery Charge................................. 292
Low Fuel Indicator...................................... 69
Low Oil Pressure Indicator................. 66, 292
Lower Anchors............................................ 54
Luggage (Maximum Load Limit)............. 175
