2012 YAMAHA MT-03 clock

TABLE OF CONTENTS
SAFETY INFORMATION.....................1-1
Safe riding .........................................1-1
Protective apparel.............................1-2
Modifications .....................................1-2
Loading and accessories ..................1-2
Gasoline and exhaust gas ................1-4
DESCRIPTION.....................................2-1
Left view ............................................2-1
Right view .........................................2-2
Controls and instruments ..................2-3
INSTRUMENT AND CONTROL
FUNCTIONS........................................3-1
Immobilizer system...........................3-1
Main switch/steering lock ..................3-2
Indicator and warning lights ..............3-3
Multi-function meter unit ...................3-5
Tachometer .......................................3-6
Odometer, tripmeter modes ..............3-6
Clock mode .......................................3-7
Self-diagnosis devices......................3-7
Indicator lights brightness
control mode..............................3-8
Anti-theft alarm (optional) .................3-8
Handlebar switches...........................3-9
Clutch lever .....................................3-10
Shift pedal.......................................3-10
Brake lever ......................................3-11Brake pedal.....................................3-11
Fuel tank cap...................................3-11
Fuel .................................................3-12
Fuel tank breather/overflow hose ...3-13
Catalytic converter..........................3-13
Seats ...............................................3-14
Adjusting the shock absorber
assembly..................................3-16
Sidestand........................................3-18
Ignition circuit cut-off system ..........3-19
PRE-OPERATION CHECKS...............4-1
Pre-operation check list ....................4-2
OPERATION AND IMPORTANT
RIDING POINTS..................................5-1
Starting the engine............................5-1
Shifting ..............................................5-2
Tips for reducing fuel consumption ...5-3
Engine break-in .................................5-3
Parking..............................................5-4
PERIODIC MAINTENANCE
AND MINOR REPAIR.........................6-1
Owner’s tool kit.................................6-1
Periodic maintenance and
lubrication chart..........................6-2
Removing and installing panels ........6-6
Checking the spark plug ...................6-6Engine oil and oil filter element.........6-8
Coolant............................................6-12
Replacing the air filter element
and cleaning the check hoses ...6-13
Adjusting the engine idling speed ...6-14
Checking the throttle cable
free play...................................6-15
Valve clearance...............................6-15
Tires ................................................6-16
Cast wheels....................................6-19
Adjusting the clutch lever
free play...................................6-19
Checking the front and rear
brake pads...............................6-20
Checking the brake fluid level .........6-21
Changing the brake fluid .................6-22
Drive chain slack .............................6-23
Cleaning and lubricating the
drive chain ................................6-24
Checking and lubricating the
cables .......................................6-25
Checking and lubricating the
throttle grip and cable ..............6-25
Checking and lubricating the
brake and clutch levers ............6-26
Lubricating the brake pedal............6-26
Checking and lubricating the
sidestand..................................6-27
Lubricating the side suspension .....6-27

1
2
3
4
5
6
7
8
9
10
INSTRUMENT AND CONTROL FUNCTIONS
3-5
The electrical circuit of the warning
light can be checked by turning the
key to “ON”.
If the warning light does not come on
for a few seconds, and then go off,
have a Yamaha dealer check the elec-
trical circuit.
NOTE:
This model is also equipped with a
self-diagnosis device for the fuel level
detection circuit. If the fuel level detec-
tion circuit is defective, the following
cycle will be repeated until the mal-
function is corrected: The fuel level
warning light will flash eight times, and
then go off for 3.0 seconds. If this oc-
curs, have a Yamaha dealer check the
vehicle.
EAUB1392
Multi-function meter unit
1. Speedometer
2. Tachometer
3. Clock
4. Odometer/Tripmeters/Fuel reserve tripmeter
5. “SELECT” button
6. “RESET” button
EWA12421
WARNING0
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit.
The multi-function meter unit is equip-
ped with the following:
●a speedometer (which shows the
riding speed)
●a tachometer (which shows en-
gine speed)
●an odometer (which shows the to-
tal distance traveled)
●two tripmeters (which show the
distance traveled since they were
last set to zero)
●a fuel reserve tripmeter (which
shows the distance traveled since
the fuel level warning light came on)
●a clock
●a self-diagnosis device
●an indicator lights brightness con-
trol mode
To switch the speedometer and
odometer/tripmeter displays between
kilometers and miles, push the “SE-
LECT” and “RESET” buttons together
and turn the key to “ON”. When the
digits start flashing on the display,
push the “SELECT” button to choose
kilometers or miles.
NOTE:
Be sure to turn the key to “ON” before
using the “SELECT” and “RESET”
buttons.

1
2
3
4
5
6
7
8
9
10
INSTRUMENT AND CONTROL FUNCTIONS
3-7
Clock mode
1. Clock
2. “SELECT” button
3. “RESET” button
Turn the key to “ON”.
T
o set the clock
1. Push the “SELECT” button for at
least two seconds.
2. When the hour digits start flash-
ing, push the “RESET” button to
set the hours.
3. Push the “SELECT” button, and
the minute digits will start flash-
ing.
4. Push the “RESET” button to set
the minutes.
5. Push the “SELECT” button, and
then release it to start the clock.
Self-diagnosis devices
1. Engine trouble warning light “U”
2. Immobilizer system indicator light “ ”
This model is equipped with a self-diag-
nosis device for various electrical cir-
cuits. If any of those circuits are defec-
tive, the engine trouble warning light
will start flashing. If this occurs, have a
Yamaha dealer check the vehicle.
This model is also equipped with a
self-diagnosis device for the immobi-
lizer system.
Turn the key to "ON". If any of the im-
mobilizer system circuits are defec-
tive, the immobilizer system indicator
light will flash, and it will indicate an er-
ror code.
If this occurs, have a Yamaha dealer
check the vehicle. However, if the indi-
cator light slowly flashes five times,
and then quickly flashes two times re-
peatedly, this error could be caused by
signal interference. If this occurs, try
the following.
1. Use the code re-registering key to
start the engine.
NOTE:
Make sure there are no other immobi-
lizer keys close to the main switch,
and do not keep more than one immo-
bilizer key on the same key ring! Im-
mobilizer system keys may cause sig-
nal interference, which may prevent
the engine from starting.
2. If the engine starts, turn it off and
try starting the engine with the
standard keys.
3. If one or both of the standard keys
do not start the engine, take the
vehicle, the code re-registering
key and both standard keys to a
Yamaha dealer and have the
standard keys re-registered.

1
2
3
4
5
6
7
8
9
10
INSTRUMENT AND CONTROL FUNCTIONS
3-11
EAU26822
Brake lever
1. Brake lever
2. Position adjusting dial
3. Arrow mark
4. Distance
The brake lever is located at the right
handlebar grip. To apply the front
brake, pull the lever toward the han-
dlebar grip.
The brake lever is equipped with a po-
sition adjusting dial. To adjust the dis-
tance between the brake lever and the
handlebar grip, turn the adjusting dial
while holding the lever pushed away
from the handlebar grip. Make sure
that the appropriate setting on the ad-
justing dial is aligned with the “˙”
mark on the brake lever.
EAU12941
Brake pedal
1. Brake pedal
The brake pedal is on the right side of
the motorcycle. To apply the rear
brake, press down on the brake pedal.
EAU13070
Fuel tank cap
1. Lock cover
2. Open
To open the fuel tank cap
Open the fuel tank cap lock cover, in-
sert the key into the lock, and then turn
it 1/4 turn clockwise. The lock will be
released and the fuel tank cap can be
opened.

INSTRUMENT AND CONTROL FUNCTIONS
3-12
1
2
3
4
5
6
7
8
9
10
To close the fuel tank cap
1. Push the fuel tank cap into posi-
tion with the key inserted in the
lock.
2. Turn the key counterclockwise to
the original position, remove it,
and then close the lock cover.
NOTE:
The fuel tank cap cannot be closed
unless the key is in the lock. In addi-
tion, the key cannot be removed if the
cap is not properly closed and locked.
EWA11090
WARNING0
Make sure that the fuel tank cap is
properly closed before riding.
EAU13210
Fuel
1. Fuel tank filler tube
2. Fuel level
Make sure that there is sufficient fuel
in the tank. Fill the fuel tank to the bot-
tom of the filler tube as shown.
EWA10880
WARNING0
• Do not overfill the fuel tank,
otherwise it may overflow when
the fuel warms up and expands.
• Avoid spilling fuel on the hot
engine.
ECA10070CAUTION:
Immediately wipe off spilled fuel
with a clean, dry, soft cloth, since
fuel may deteriorate painted sur-
faces or plastic parts.
EAU13390
Recommended fuel:
PREMIUM UNLEADED
GASOLINE ONLY
Fuel tank capacity:
15.0 L (3.96 US gal) (3.29 Imp.gal)
Fuel reserve amount (when the fuel
level warning light comes on):
4.25 L (1.12 US gal) (0.93 Imp.gal)

INSTRUMENT AND CONTROL FUNCTIONS
3-14
1
2
3
4
5
6
7
8
9
10
To install the passenger seat
1. Projection
2. Seat holder
1. Insert the projection on the front
of the passenger seat into the
seat holder as shown, and then
push the back of the seat down to
lock it in place.
2. Remove the key.
EAUB1311
Seats
Passenger seat
1. Open
To remove the passenger seat
1. Insert the key into the seat lock,
and then turn it counterclockwise.
2. Pull the passenger seat off.
ECA10700CAUTION:
The following precautions must be
observed to prevent a fire hazard or
other damages.
●Use only unleaded gasoline.
The use of leaded gasoline will
cause unrepairable damage to
the catalytic converter.
●Never park the vehicle near
possible fire hazards such as
grass or other materials that
easily burn.
●Do not allow the engine to idle
too long.

PERIODIC MAINTENANCE AND MINOR REPAIR
1. Parking lighting fuse
2. Signaling system fuse
3. Headlight fuse
4. Ignition fuse
5. Electronic fuel injection fuse
6. Radiator fan fuse
7. Backup fuse
8. Reserve fuses
The main fuse is located under the fu-
el tank. (See page 6-31.)
The fuse box which contains the fuses
for the individual circuits is located un-
der the rider seat. (See page 3-15.)
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specified
amperage.
ECA10640CAUTION:
Do not use a fuse of a higher am-
perage rating than recommended
to avoid causing extensive damage
to the electrical system and possi-
bly a fire.
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
6-32
1
2
3
4
5
6
7
8
9
10
Specified fuses:
Main fuse:
30 A
Fuse box:
Parking lighting fuse:
10 A
Signaling system fuse:
10 A
Headlight fuse:
20 A
Ignition fuse:
10 A
Electronic fuel injection fuse:
10 A
Radiator fan fuse:
7.5 A
Fuel injection system fuse:
10 A
Backup fuse (for odometer,
clock and immobilizer):
10 A

1
2
3
4
5
6
7
8
9
10
PERIODIC MAINTENANCE AND MINOR REPAIR
1. Remove the tail/brake light bulb
cover by removing the bolts.
2. Remove the socket (together with
the bulb) by turning it counter-
clockwise.
3. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
4. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
5. Install the socket (together with
the bulb) by turning it clockwise.
6. Place the tail/brake light bulb
cover in its original position, insert
the bolts and then tighten them to
the specified torque.EAU24202
Replacing a turn signal
light bulb
1. Screw
2. Turn signal light lens
3. Turn signal light bulb
1. Remove the turn signal light lens
by removing the screw.
2. Remove the defective bulb by
pushing it in and turning it coun-
terclockwise.
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw.
ECA11190CAUTION:
Do not overtighten the screw, oth-
erwise the lens may break.
6-35
Tightening torque:
Tail/brake light bulb cover bolt:
10 Nm (1.0 m·kgf, 7.2 ft·lbf)
