DESCRIPTION
2-3
2
EAU32231
Right view(FZ8-S)
10
12 11
23 5
46
1
9
8
7
1. Luggage strap holder (page 3-24)
2. Fuse box (page 6-34)
3. Battery (page 6-33)
4. Rear brake fluid reservoir (page 6-25)
5. Coolant reservoir (page 6-14)
6. Engine oil filler cap (page 6-11)
7. Front fork rebound damping force adjusting screw (page 3-20) 8. Front fork spring preload adjusting bolt (page 3-20)
9. Front fork compression damping force adjusting screw (page 3-20)
10.Engine oil level check window (page 6-11)
11.Brake pedal (page 3-14)
12.Rear brake light switch (page 6-24)
U42PE4E0.book Page 3 Wedne
sday, August 6, 2014 3:25 PM

DESCRIPTION
2-4
2(FZ8-SA)
911 10
24
5
3
1
8
7
6
1. Luggage strap holder (page 3-24)
2. Fuse box (page 6-34)
3. Rear brake fluid reservoir (page 6-25)
4. Coolant reservoir (page 6-14)
5. Engine oil filler cap (page 6-11)
6. Front fork rebound damping force adjusting screw (page 3-20)
7. Front fork spring preload adjusting bolt (page 3-20)
8. Front fork compression damping force adjusting screw (page 3-20)
9. Engine oil level check window (page 6-11) 10.Brake pedal (page 3-14)
11.Battery (page 6-33)U42PE4E0.book Page 4 Wedne
sday, August 6, 2014 3:25 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-4
3
EAU49397
Indicator lig hts and warning
lig hts
EAU11021
Turn si gnal in dicator li ght “ ”
This indicator light flashes when the
turn signal switch is pushed to the left
or right.
EAU11061
Neutral in dicator li ght “ ”
This indicator light comes on when the
transmission is in the neutral position.
EAU11081
Hi gh beam in dicator li ght “ ”
This indicator light comes on when the
high beam of the headlight is switched
on.
EAU11255
Oil level warnin g lig ht “ ”
This warning light comes on if the en-
gine oil level is low.
The electrical circuit of the warning
light can be checked by turning the key
to “ON”. The warning light should
come on for a few seconds, and then
go off.
If the warning light does not come on
initially when the key is turned to “ON”,
or if the warning light remains on, have
a Yamaha dealer check the electrical
circuit.
TIP Even if the oil level is sufficient, the
warning light may flicker when rid-
ing on a slope or during sudden
acceleration or deceleration, but
this is not a malfunction.
 This model is also equipped with a
self-diagnosis device for the oil
level detection circuit. If a problem
is detected in the oil level detec-
tion circuit, the following cycle will
be repeated until the malfunction
is corrected: The oil level warning
light will flash ten times, then go
off for 2.5 seconds. If this occurs,
have a Yamaha dealer check the
vehicle.
EAU1142E
Coolant temperature warnin g
li g ht “ ”
This warning light comes on if the en-
gine overheats. If this occurs, reduce
the load on the engine immediately. If
message “HI” flashes in the coolant
temperature display, stop the vehicle,
then stop the engine and let the engine
cool.
1. Turn signal indicator light “ ”
2. Immobilizer system indicator light
3. Neutral indicator light “ ”
4. High beam indicator light “ ”
5. Engine trouble warning light “ ”
6. Oil level warning light “ ”
7. Coolant temperature warning light “ ”
8. Anti-lock Brake System (ABS) warning light “ ” (for ABS models)
ABS
123
45678
ABS
U42PE4E0.book Page 4 Wedne sday, August 6, 2014 3:25 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-5
3The electrical circuit of the warning
light can be checked by turning the key
to “ON”. The warning light should
come on for a few seconds, and then
go off.
If the warning light does not come on
initially when the key is turned to “ON”,
or if the warning light remains on, have
a Yamaha dealer check the electrical
circuit.
NOTICE
ECA10022
Do not continue to operate the en-
g
ine if it is overheatin g.TIP For radiator-fan-equipped vehi-
cles, the radiator fan(s) automati-
cally switch on or off according to
the coolant temperature in the ra-
diator.
 If the engine overheats, see page
6-46 for further instructions.
U42PE4E0.book Page 5 Wedne sday, August 6, 2014 3:25 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-6
3
DisplayConditions What to do
Under 40 °C
(Under 104 °F) Message “Lo” is displayed. OK. Go ahead with riding.
40–116 °C
(104–242 °F) Coolant temperature is dis-
played.
OK. Go ahead with riding.
117–134 °C
(243–274 °F) Coolant temperature flash-
es.
Warning light comes on.Reduce the load on the engine by riding
at a moderate pace, at low rpm, until
the coolant temperature goes down.
If the temperature does not go down,
stop the engine. (See page 6-46.)
Above 134 °C
(Above 274 °F) Message “HI” flashes.
Warning light is on.Stop the engine and allow it to cool.
(See page 6-46.)
ABSABS
U42PE4E0.book Page 6 Wedne
sday, August 6, 2014 3:25 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-8
3
EAU46767
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
makin g any settin g chan ges to the
multi-function meter unit. Chan gin g
settin gs while ri din g can distract the
operator an d increase the risk of an
acci dent.
The multi-function meter unit is
equipped with the following:
 a speedometer
 a tachometer
 an odometer
 two tripmeters (which show the
distance traveled since they were
last set to zero)
 a fuel reserve tripmeter (which
shows the distance traveled since
the left segment of the fuel meter
started flashing)
 a clock
 a fuel meter
 a coolant temperature display
 a self-diagnosis deviceTIPBe sure to turn the key to “ON” be-
fore using the “SELECT” and “RE-
SET” buttons.
 For the UK only: To switch the
speedometer and odometer/trip-
meter displays between kilome-
ters and miles, press the
“SELECT” button for at least one
second.
Speed ometer
The speedometer shows the vehicle’s
traveling speed.
Tachometer
The electric tachometer allows the rid-
er to monitor the engine speed and
keep it within the ideal power range.
When the key is turned to “ON”, the ta-
chometer needle will sweep once
across the r/min range and then return
to zero r/min in order to test the electri-
cal circuit.NOTICE
ECA10032
Do not operate the en gine in the ta-
chometer red zone.
1. Fuel meter
2. Coolant temperature display
3. Speedometer
4. Tachometer
5. Odometer/tripmeter/fuel reserve tripmeter
6. “SELECT” button
7. “RESET” button
8. Clock
ABS
1
2
3
4
87 6 5
1. Tachometer
2. Tachometer red zone
ABS1
2
U42PE4E0.book Page 8 Wedne sday, August 6, 2014 3:25 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-10
3
Fuel meter
The fuel meter indicates the amount of
fuel in the fuel tank. The display seg-
ments of the fuel meter disappear to-
wards “E” (Empty) as the fuel level
decreases. When the last segment on
the left starts flashing, refuel as soon as
possible.
TIPThis fuel meter is equipped with a self-
diagnosis system. If a problem is de-
tected in the electrical circuit, the fol-
lowing cycle is repeated until the
malfunction is corrected: fuel level seg-
ments and symbol “ ” flash eight times, then go off for approximately 3
seconds. If this occurs, have a Yamaha
dealer check the electrical circuit.
Coolant temperature
display
The coolant temperature display indi-
cates the temperature of the coolant.NOTICE
ECA10022
Do not continue to operate the en-
g ine if it is overheatin g.
Self-d iagnosis device
This model is equipped with a self-di-
agnosis device for various electrical
circuits.
If a problem is detected in any of those
circuits, the engine trouble warning
light will come on and the display will
indicate an error code.
If the display indicates any error codes,
note the code number, and then have
a Yamaha dealer check the vehicle.
The self-diagnosis device also detects
problems in the immobilizer system
circuits.
1. Fuel meter
1
1. Coolant temperature display
1
1. Error code display
2. Immobilizer system indicator light
3. Engine trouble warning light “ ”
ABS
1
3
2
U42PE4E0.book Page 10 Wedne sday, August 6, 2014 3:25 PM
