05 Infotainment
Bluetooth® hands-free connection
05

235
Method 2: using the cell phone’s menus
1. Activate the hands-free system by briefly
pressing the TEL button in the center con-
sole. If there is a cell phone connected,
disconnect it from the hands-free system.
2. Make the vehicle discoverable via the
Bluetooth
Ÿ function by pressing OK/
MENU and activating the menu selection
Phone settings
Discoverable.
3. Perform a search with the cell phone's
Bluetooth
Ÿ function (see the cell phone's
user's guide if necessary).
4.
Select
My Volvo Car in the list of devices
shown in the cell phone’s display.
5. When prompted, enter a PIN code of your
choice in the cell phone using the cell
phone's keypad. Enter the same PIN code
in the infotainment system using the sys-
tem's keypad in the center console.
6.
Connect to
My Volvo Car from the cell
phone.
The cell phone will be paired (registered) and
will be connected automatically to the infotain-
ment system. For more information on pairing
and connecting a cell phone, see page 237.
Making a call1.
Ensure that is shown at the top of the
center console display and that the hands-
free function is in telephone mode.
2. Dial the desired phone number using the
center console keypad or use the speed
dial function (see page 240). In normal
view (see page 207 for information about
the various display views). It is also possi-
ble to turn TUNE clockwise to access the
phone book and then counter-clockwise
for the call list. See page 237 for more
information about the phone book.
3.
Press OK/MENU
End or reject a call by pressing EXIT.
Disconnecting the cell phoneThe cell phone is automatically disconnected
from the infotainment system if it is moved out
of range.
The cell phone can be manually disconnected
from the hands-free system by pressing and
holding TEL or in phone mode, going to Phone
menu
Disconnect phone. See also page
236 for more information about connections.
The hands-free system is also deactivated
when the ignition is switched off (or if the
driver’s door is opened on vehicles equipped
with the optional keyless drive).When the cell phone is disconnected from the
hands-free system, a call in progress can be
continued using the cell phone’s own speaker
and microphone.
Even if the cell phone has been disconnected
manually, some phones may reconnect auto-
matically to the most recently used hands-free
unit, for example when a new call is initiated.
Handling calls
Incoming calls
Press OK/MENU (or the thumb wheel on
the steering wheel keypad) to answer a
call, even if the infotainment system is cur-
rently in another mode (e.g.,
RADIO orMEDIA).
Press EXIT to reject a call.
Automatic answerThis function means that incoming calls will be
answered automatically. Activate or deactivate
the function in the menu system under Phone
menu
Call optionsAuto answer.
Call settingsWhile a call is in progress, press OK/MENU or
the thumb wheel on the steering wheel keypad
to access the following functions:

05 Infotainment
Bluetooth® hands-free connection
05
236
•Mute: mute the infotainment system’s
microphone.
•Mobile phone: transfer the call from
hands-free to the cell phone. On certain
cell phones, the connection will be broken,
which is normal. The hands-free function
will ask if you would like to reconnect.
•Dial number: dial a third party during an
ongoing call using the number keys (the
current call will be put on hold).
Call listsCall lists are copied to the hands-free function
each time a cell phone is connected and the
lists are updated while the phone is connected.
In normal view, turn TUNE counter-clockwise
to see the
All calls list.
In phone mode, the various call lists can be
displayed in Phone menu
Call lists:
•All calls
•Missed calls
•Answered calls
•Dialed calls (certain cell phones show this
list in reverse order)
•Call duration
If no number has been stored, this menu can
be accessed by pressing and holding 1.
Voice mailIn normal view, a speed dial number for voice
mail can be programmed and accessed by
pressing and holding 1.
The number for voice mail can be changed in
phone mode in Phone menu
Call options
Voicemail numberChange number.
Sound settings
Call volumeCall volume can be only be adjusted during a
call. Use the buttons in the steering wheel key-
pad or the infotainment system’s VOL control.
Infotainment system volumeIf no phone call is in progress, volume for the
infotainment system can be adjusted in the
normal way with the infotainment system's
VOL control or from the steering wheel keypad.
Infotainment system sound can be automati-
cally muted when a phone call is received in
Phone menu
Phone settingsSounds
and volume
Mute radio/media.
Ringing volume
In phone mode, go to Phone menuPhone
settings
Sounds and volumeRingvolume and adjust the volume by turning
VOL. Save the setting by pressing EXIT.
Ringing tonesThe hands-free system’s integrated ringing
tones can be selected in Phone menu
Phone settingsSounds and volume
Ring signalsRing signal 1, etc.
NOTE
The connected cell phone’s ring tone may
not be switched off when one of the hands-
free system's ringing tones is used.
If you prefer to use the connected cell phone’s
ring tone1, go to Phone menuPhone
settings
Sounds and volumeRing
signals
Mobile phone ring signal.
More information about pairing and
connecting cell phones
A maximum of 10 cell phones can be paired
with the hands-free system. Pairing only needs
to be done once for each phone. After pairing,
the cell phone no longer needs to be in sight or
discoverable. Only one cell phone can be
actively connected to hands-free at a time.
1Not supported by all cell phones.

05 Infotainment
Bluetooth® hands-free connection
05
238
Contact shortcutsA quick way of searching the phone book for
contacts in normal view is to turn TUNE clock-
wise to access the phone book and then coun-
ter-clockwise to select a contact from the list.
Press OK/MENU to call.
Each name in the phone book has a default
phone number. If the
symbol is displayed to
the right of it, this indicates that there are addi-
tional phone numbers for this contact. To use
a phone number other than the default one,
press the
button on the center console
control panel. Turn TUNE to select a different
phone number and press OK/MENU to call.
It is also possible to search for a contact by
using the center console keypad to enter the
first letter(s) of the contact's name (see also the
following table "Buttons in the center console"
for each button's function).
The list of contacts can also be accessed from
normal view by pressing and holding the button
on the center console keypad with the first let-
ter of the contact's name. For example, press-
ing and holding button 6 would provide direct
access to the section of the list with contacts
whose names begin with
M.
Buttons in the center console
ButtonFunction
Space . , - ? @ : ; / ( ) 1
A B C Å Ä Æ À Ç 2
D E F È É 3
G H I Ì 4
J K L 5
M N O Ö Ø Ñ Ò 6
P Q R S ß 7
T U V Ü Ù 8
W X Y Z 9
Shift between upper and lower
case
+ 0 p w
# *
Searching for contacts
Searching for contacts using the text wheel
List of characters
Switch between character entry modes
(see the following table)
Phone book (list of contacts)
To search for or edit a contact in phone mode,
go to Phone menu
Phone book
Search.
1.
Turn TUNE to the desired letter and press
OK/MENU to confirm. The number/letter
keys on the center console can also be
used.
2. Continue to the next letter, etc. The results
of the search will be displayed in the phone
book (3).

06 During your trip
Refueling
06

269
Opening/closing the fuel cap
Fuel vapor expands in hot weather. Open the
filler cap slowly.
After refueling, close the fuel filler cap by turn-
ing it clockwise until it clicks into place.
CAUTION
•Do not refuel with the engine running2.
Turn the ignition off or to position I. If the
ignition is on, an incorrect reading could
occur in the fuel gauge.
•Avoid overfilling the fuel tank. Do not
press the handle on the filler nozzle
more than one extra time. Too much fuel
in the tank in hot weather conditions can
cause the fuel to overflow. Overfilling
could also cause damage to the emis-
sion control systems.
Emission controls
Three-way catalytic converter
•Keep your engine properly tuned. Certain
engine malfunctions, particularly involving
the electrical, fuel or distributor ignition
systems, may cause unusually high three-
way catalytic converter temperatures. Do
not continue to operate your vehicle if you
detect engine misfire, noticeable loss of
power or other unusual operating condi-
tions, such as engine overheating or back-
firing. A properly tuned engine will helpavoid malfunctions that could damage the
three-way catalytic converter.
•Do not park your vehicle over combustible
materials, such as grass or leaves, which
can come into contact with the hot exhaust
system and cause such materials to ignite
under certain wind and weather condi-
tions.
•Excessive starter cranking (in excess of
one minute), or an intermittently firing or
flooded engine can cause three-way cata-
lytic converter or exhaust system over-
heating.
•Remember that tampering or unauthorized
modifications to the engine, the Engine
Control Module, or the vehicle may be ille-
gal and can cause three-way catalytic con-
verter or exhaust system overheating. This
includes: altering fuel injection settings or
components, altering emission system
components or location or removing com-
ponents, and/or repeated use of leaded
fuel.
NOTE
Unleaded fuel is required for vehicles with
three-way catalytic converters.
2If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's
performance will not be affected. Use only Volvo original or approved fuel filler caps.

07 Wheels and tires
Tire Sealing System
07
304
WARNING
If heavy vibrations, unsteady steering
behavior, or noises should occur while driv-
ing, reduce speed and park the vehicle in a
safe place. Recheck the tire for bumps,
cracks, or other visible damage, and
recheck its inflation pressure. If the pressure
is below 19 psi (1.3 bar), do not continue
driving. Have the vehicle towed to a trained
and qualified Volvo service technician.
Stage 2: Checking inflation pressure1. Connect the tire sealing system as descri-
bed in stage 1.
2. Refer to the inflation pressure table in this
chapter for the correct inflation pressure. If
the tire needs to be inflated, start the tire
sealing system’s compressor. If neces-
sary, release air from the tire by turning the
air release knob counterclockwise.
CAUTION
The compressor should not be used for
more than 10 minutes at a time to avoid
overheating.
WARNING
If you interrupt your trip for more than 1
hour, check the inflation pressure in the
damaged tire again before continuing.
Replacing the sealing compound
container
The sealing compound container must be
replaced if:
•the tire sealing system has been used to
repair a tire
•the container’s expiration date has passed
(see the date on decal).
NOTE
•After use, the sealing compound bottle,
the hose, and certain other system
components must be replaced. Please
consult your Volvo retailer for replace-
ment parts.
•If the sealing compound bottle’s expi-
ration date has passed, please take it to
a Volvo retailer or a recycling station
that can properly dispose of harmful
substances.
Inflating tires
The tire sealing system can be used to inflate
the tires. To do so:
1. Park the car in a safe place.
2. The compressor should be switched off.
Ensure that the on/off switch is in position
0 (the 0 side of the switch should be
pressed down).
3. Take out the electrical wire and hose.
4. Remove the valve cap from the tire’s infla-
tion valve and screw the hose connector
onto the valve as tightly as possible by
hand.
5. Connect the electrical wire to the nearest
12-volt socket in the vehicle.
6. Start the vehicle’s engine.
WARNING
•The vehicle’s engine should be running
when the tire sealing system is used to
avoid battery drain. Therefore, be sure
the vehicle is parked in a well ventilated
place, or outdoors, before using the sys-
tem.
•Children should never be left unattended
in the vehicle when the engine is running.

07 Wheels and tires
Tire Sealing System
07
305
7. Check the tire’s inflation pressure on the
gauge. Switch off the compressor briefly to
get a clear reading from the pressure
gauge.
8. Refer to the tire inflation table in this chap-
ter for the correct inflation pressure. If the
tire needs to be inflated, start the tire seal-
ing system’s compressor (press the on/off
switch to position I). If necessary, release
air from the tire by turning the air release
knob counterclockwise.
CAUTION
The compressor should not be used for
more than 10 minutes at a time to avoid
overheating.
9. Turn off the compressor (press the on/off
switch to position 0) when the correct infla-
tion pressure has been reached.
10. Unscrew the hose from the tire’s inflation
valve and reinstall the valve cap.
11. Disconnect the electrical wire from the
12-volt socket.

07 Wheels and tires
Changing a wheel
07

307
Lug wrench and towing eyelet
5. Screw the towing eyelet into the lug
wrench as shown in the illustration.
CAUTION
The towing eyelet must be screwed into the
lug wrench as far as possible.
6. With the vehicle still on the ground, use the
lug wrench/towing eyelet to loosen the
wheel nuts ½ – 1 turn by exerting down-
ward (counterclockwise) pressure.
Jack attachment points
7. There are two jack attachment points on
each side of the vehicle. Position the jack
correctly in the attachment (see the illus-
tration) and crank while simultaneously
guiding the base of the jack to the ground.
The base of the jack must be flat on a level,
firm, non-slippery surface. Before raising
the vehicle, check that the jack is still cor-
rectly positioned in the attachment.

08 Maintenance and specifications
Replacing bulbs
08
324
NOTE
Before starting to replace a bulb, see
page 322.
1. Open the retaining clamps by pressing
them to the sides.
2. Pull the cover straight out.
Reinstall the cover in the reverse order.
Low beam, Halogen
1. Remove the headlight housing from the
vehicle (see page 322).
2. Remove the cover over the bulbs (see
page 323).3. Unplug the connector from the bulb.
4. Remove the bulb by pressing the holder
downward.
5. Press the new bulb into the socket until it
snaps into place. It can only be secured in
one position.
6. Put the cover back into position and rein-
stall the headlight housing.
High beam, Halogen
1. Remove the headlight housing from the
vehicle (see page 322).
2. Remove the cover over the bulbs (see
page 323).3. Remove the bulb by turning it counter-
clockwise and pulling it straight out.
4. Remove the connector from the bulb.
5. Press the new bulb into the socket and turn
it clockwise to put it in place. It can only be
secured in one position.
6. Reinsert the bulb holder into the headlight
housing.
7. Put the cover back into position and rein-
stall the headlight housing.
Extra high beam2
1. Remove the headlight housing from the
vehicle (see page 322).
2Models with optional Active Bending Lights only.
