05 Infotainment system
BluetoothŸŸ handsfree*
05
* Option/accessory, for more information, see Introduction.253
screen. Now the mobile phone can be con-
trolled from the audio system.
To call1.
Make sure that the symbol appears
at the top of the TV screen and that the
handsfree function is in phone mode.
2. Dial either the desired number or speed
dial number, see page 258. Or in normal
view turn TUNE to the right to access the
phone book, and to the left for the call reg-
ister for all calls. For information on the
phone book, see page 255.
3.
Press OK/MENU.
The call is interrupted with EXIT.
Disconnecting the mobile phoneAutomatic disconnection takes place if the
mobile phone moves out of the audio system's
range. The connection to the mobile phone can
be interrupted manually via a long press on
TEL or in phone mode under Phone menu
Disconnect phone. For more information
on connection, see page 254.
The handsfree function is deactivated when
the engine is switched off or when a door is
opened
2.When the mobile phone has been discon-
nected an ongoing call can be continued by
using the mobile phone's built-in microphone
and speaker.
NOTE
Even when your mobile phone has been
manually disconnected, some mobile
phones may automatically couple up to the
last handsfree unit connected, e.g. when a
new call begins.
Making and receiving calls
Incoming call–
Press OK/MENU to answer the call, even
if the audio system is in e.g. RADIO orMEDIA mode.
Refuse or end with EXIT.
Automatic answerThe automatic answer function means that
calls are accepted automatically.
–Activate/deactivate in phone mode under
Phone menu
Call optionsAuto
answer.
In call menuPress OK/MENU during an ongoing call to
access the following functions:
•Mute - audio system microphone is
muted.
•Mobile phone - the call is transferred from
handsfree to the mobile phone. For some
mobile phones the connection is interrup-
ted. This is normal. The handsfree function
asks if you want to reconnect.
•Dial number - option to call a third party
using the number keys (current call set in
standby).
Call listsThe call lists are copied to the handsfree func-
tion at each new connection and are then
updated during the connection. In normal view,
turn to the left with TUNE to see the call register
for
All calls .
In phone mode it is possible to see all the call
lists under Phone menu
All calls:
•All calls
•Missed calls
•Answered calls
•Dialled calls
•Call duration
2Only Keyless Drive.
ProCarManuals.com

05 Infotainment system
BluetoothŸŸ handsfree*
05
254* Option/accessory, for more information, see Introduction.
NOTE
Certain mobile phones show a list of the last
dialled numbers in reverse order.
Voice mailboxIn normal view a speed dial number for the
voice mailbox can be programmed in and then
accessed later via a long press on 1.
Voice mailbox number is changed in phone
mode under Phone menu
Call options
Voicemail numberChange number. If
there is no number stored then this menu can
be reached with one long press on 1.
Audio settings
Phone call volumeThe phone call volume can only be changed
during a call. Use the steering wheel keypad*
or turn the VOL control.
Audio system volumeProviding there is no ongoing call taking place,
the audio system volume is controlled as usual
by turning VOL.
If an audio source is active during an incoming
call then it can be muted automatically. Acti-
vate/deactivate in phone mode under Phonemenu
Phone settingsSounds and
volume
Mute radio/media.
Ring volume
In phone mode go to Phone menuPhone
settings
Sounds and volumeRing
volume and adjust by turning VOL. Press
EXIT to save.
Ring signalsThe handsfree function has integrated ring sig-
nals that can be selected in phone mode under
Phone menu
Phone settingsSounds
and volume
Ring signalsRing signal 1
etc.
NOTE
For some mobile phones, the ringtone on
the phone connected will not be switched
off when one of the inbuilt signals for the
handsfree system is used.
In order to select the connected phone's ring
signal3, go in phone mode to Phone menu
Phone settingsSounds and volume
Ring signalsMobile phone ring signal.
More on pairing and connecting
A maximum of ten mobile phones can be
paired (registered). Pairing is performed once
per phone. After pairing the phone no longer
needs to be visible/detectable. A maximum of
one mobile phone can be connected at a time.
Automatic connectionWhen the handsfree function is active and the
last mobile phone connected is in range it is
connected automatically. If the last connected
mobile phone is not available then the system
will try to connect a mobile phone that was
paired earlier. When the audio system
searches for the last phone connected its name
is shown in the TV screen.
Manual connectionIf you want to change the connected mobile
phone, go in phone mode to Phone menu
Change phone.
Remove the deviceA connected mobile phone can be deregis-
tered and removed. This is performed in phone
mode under Phone menu
Remove
Bluetooth device.
3Not supported by all mobile phones.
ProCarManuals.com

05 Infotainment system
BluetoothŸŸ handsfree*
05
* Option/accessory, for more information, see Introduction.255
Version information BluetoothŸ
The car's current BluetoothŸ version can be
seen in phone mode under Phone menu
Phone settingsBluetooth software
version in car.
Phone book
There are two phone books. These are merged
into one in the car and are displayed as a single
phone book in the car.
•The car downloads the mobile phone's
phone book and only displays this phone
book when the mobile phone from which
this phone book was downloaded is con-
nected.
•The car also has a built-in phone book. This
contains all the contacts stored in the car
irrespective of which phone was con-
nected when saving them. These contacts
are visible for all users, regardless of the
mobile phone that is connected to the car.
If a contact is saved in the car then the
symbol
is shown in front of the con-
tact in the phone book.
NOTE
Changes made from the car to a record in
the mobile phone's telephone book will
result in a new record in the car's telephone
book, i.e. changes will not be saved to the
phone. From the car, this will now look like
you have double records, with different
icons. Note also that when a shortcut num-
ber is saved or a change to a contact is
made, this will result in a new record in the
car's phone book.
All use of the phone book requires that the
symbol appears at the top of the TV
screen and that the handsfree function is in
phone mode.
The audio system stores a copy of the phone
book from each paired mobile phone. The
phone book can be copied automatically to the
audio system during each connection.
–Activate/deactivate the function in phone
mode under Phone menu
Phone
settings
Phonebook download.
If the phone book contains a ringing caller's
contact information then this is shown in the TV
screen.
Quick search for contactsIn normal view turn TUNE to the right to obtain
a list of contacts. Turn TUNE to select and
press OK/MENU to call.
Under the name of the contact is the phone
number that is selected by default. If the sym-
bol
appears to the right of the contact then
there are several phone numbers stored for the
contact. Change and dial a different number
than the one that is selected by default by
pressing the button
on the control panel
in the centre console. Then turn TUNE to select
and press OK/MENU to call.
Search in the list of contacts by using the cen-
tre console's keypad to key in the start of the
contact's name (see "Character table keypad
in centre console" for button functions).
The list of contacts can also be accessed from
normal view by pressing and holding the button
on the centre console's keypad with the letter
that the contact searched for starts with. For
example, a long press on the button for 6 gives
instant access to that part of the list where the
contacts with the letter
M are located.
ProCarManuals.com

05 Infotainment system
BluetoothŸŸ handsfree*
05
256* Option/accessory, for more information, see Introduction.
Character table keypad in centre
console
KeyFunction
Space . , - ? @ : ; / ( ) 1
A B C Å Ä Æ À Ç 2
D E F È É 3
G H I Ì 4
J K L 5
M N O Ö Ø Ñ Ò 6
P Q R S ß 7
T U V Ü Ù 8
W X Y Z 9
Shift between upper and lower
case letter.
KeyFunction
+ 0 p w
# *
Searching for contacts
Search contacts using the text wheel.
Character list
Changing the input mode (see table below)
Phone book
To search for or edit a contact, go in phone
mode to Phone menu
Phone book
Search.
NOTE
There is no text wheel for High Performance,
so TUNE cannot be used there to input
characters: only the digit and letter buttons
on the control panel in the centre console
can be used for this.
1.
Turn4 TUNE to the desired letter, press
OK/MENU to confirm. The number and
letter buttons on the control panel in the
centre console can also be used.
2. Continue with the next letter and so on. The
result of the search is shown in the phone
book (3).
3. To change the input mode to numbers or
special characters, or to go to the phone
book, turn TUNE to one of the options (see
explanation in the table below) in the list for
changing the input mode (2), press OK/
MENU.
4Only applies to High Performance Multimedia and Premium Sound Multimedia.
ProCarManuals.com

05 Infotainment system
BluetoothŸŸ handsfree*
05
* Option/accessory, for more information, see Introduction.257
123/ABC
Change between letters and
numbers with OK/MENU.
MoreChange to special characters
with OK/MENU.
Leads to the phone book (3).
Turn TUNE to select a contact,
press OK/MENU to see the
saved numbers and other infor-
mation.
A short press on EXIT deletes an input char-
acter. A long press on EXIT will clear all entered
characters.
By pressing a number key in the centre console
when the text wheel is shown (see illustration
above), a new character list (1) appears in the
TV screen. Continue repeatedly pressing the
number key to the desired letter and then
release. Continue with the next letter and so
on. When a button is depressed the entry is
confirmed when another button is depressed.
To enter a number, hold in the corresponding
number key.
New contact
Entering letters for New contact.
Changing the input mode (see table below)
Input field
New contacts can be added in phone mode
under Phone menu
Phone bookNew
contact.
NOTE
There is no text wheel for High Performance,
so TUNE cannot be used there to input
characters: only the digit and letter buttons
on the control panel in the centre console
can be used for this.
1.
When the Name row is selected, press
OK/MENU to reach the input mode (illus-
tration above).
2.
Turn
4 TUNE to the desired letter, press
OK/MENU to confirm. The number and
letter buttons on the control panel in the
centre console can also be used.
3. Continue with the next letter and so on. The
name entered is shown in the input field (2)
in the TV screen.
4. To change the input mode to numbers,
special characters, change between
uppercase/lowercase letters, etc., turn
TUNE to one of the options (see explana-
tion in the table below) in the list (1) and
then press OK/MENU.
When the name has been fully entered, select
OK in the list on the TV screen (1) and press
OK/MENU. Now continue with the telephone
number in the same way as above.
When the telephone number has been entered,
press OK/MENU and select a telephone num-
ber type (
Mobile, Home, Work or General).
Press OK/MENU to confirm.
When all details have been filled in, select
Save
contact in the menu to save the contact.
4Only applies to High Performance Multimedia and Premium Sound Multimedia.
ProCarManuals.com

05 Infotainment system
BluetoothŸŸ handsfree*
05
258* Option/accessory, for more information, see Introduction.
123/ABC
Change between letters and
numbers with OK/MENU.
MoreChange to special characters
with OK/MENU.
OKSave and go back to Add con-
tact with OK/MENU.
Change between uppercase and
lowercase letters with OK/
MENU.
Press OK/MENU, the cursor
moves to the input field (2) at the
top of the TV screen. The cursor
can now be moved, with TUNE,
to the appropriate place to e.g.
insert new letters or delete with
EXIT. To be able to insert new
letters first go back to the input
mode, by pressing OK/MENU.
Speed dial numbersUse phone mode to add speed dial numbers
under Phone menu
Phone bookSpeed
dial.
Dialling with speed dial numbers can be per-
formed in phone mode using the number keys
on the keypad in the centre console, by press-
ing a number key and then pressing OK/
MENU. If there is no contact stored on thespeed dial number then an option is shown to
save a contact to the selected speed dial num-
ber.
Receiving a vCardIt is possible to receive a vCard to the car's
phone book from other mobile phones (other
than the one currently connected to the car). In
order to allow this the car is set to visible mode
for Bluetooth
Ÿ. The function is activated in
phone mode under Phone menu
Phone
book
Receive vCard.
Memory statusMemory status of the car's phone book and the
connected mobile phone's phone book can be
seen in phone mode under Phone menu
Phone bookMemory status.
Delete phone bookThe car's phone book can be deleted, this is
carried out in phone mode under Phone menu
Phone bookClear phone book.
NOTE
Deleting the car's telephone book only dele-
tes contacts in the car's telephone book.
Contacts in the mobile phone's phone book
are not deleted.
ProCarManuals.com

05 Infotainment system
Voice recognition* mobile phone
05
* Option/accessory, for more information, see Introduction.259 Introduction
The infotainment system's voice recognition1
allows the driver to voice-activate certain func-
tions in a BluetoothŸ-connected mobile phone
or in Volvo's navigation system - RTI (Road and
Traffic Information System).
NOTE
•The information in this section
describes the use of voice commands
to control a mobile phone connected
using Bluetooth
Ÿ. For detailed infor-
mation on using a mobile phone con-
nected using Bluetooth
Ÿ with the car's
Infotainment system see page 251.
•The Volvo navigation system RTI (Road
and Traffic Information System) has a
separate user manual which contains
more information on voice control and
voice commands to control that sys-
tem.
Voice commands offer convenience and help
the driver to avoid being distracted, and
instead concentrate on driving and focus
attention on the road and traffic conditions.
WARNING
The driver always holds overall responsibil-
ity for driving the vehicle in a safe manner
and complying with all applicable rules of
the road.
The voice recognition system allows the driver
to voice-activate certain functions of a
Bluetooth
Ÿ-connected mobile phone and in
Volvo's navigation system - RTI (Road and
Traffic Information System), while the driver
can keep his/her hands on the wheel at the
same time. The input data are in dialogue form
with spoken commands from the user and ver-
bal replies from the system. The voice recog-
nition system uses the same microphone as
the Bluetooth
Ÿ handsfree system (see illustra-
tion on page 251) and the voice recognition
system's replies come via the car's speakers.
Language
Language list.
Voice recognition is not possible for all lan-
guages. Languages available for voice recog-
nition are marked with an icon in the language
list -
. Changing the language is performed
in the menu system MY CAR, see page 146.
1Only applies to vehicles equipped with Volvo's navigation system - RTI (Road and Traffic Information System).
ProCarManuals.com

05 Infotainment system
Voice recognition* mobile phone
05
260* Option/accessory, for more information, see Introduction.
Remember
Steering wheel keypad.
Button for voice recognition
To activate the systemBefore voice commands to a mobile phone can
be used the mobile phone must be paired and
connected via Bluetooth
Ÿ handsfree. If a tele-
phone command is given and no mobile phone
is paired, then the system will provide informa-
tion about this. For information on pairing and
connecting a mobile phone, see page 252.
•Press the button for voice recognition (1) in
order to activate the system and initiate a
dialogue with voice commands. The sys-
tem will then display commonly used com-
mands in the TV screen in the centre con-
sole.Keep the following things in mind when you use
the voice recognition system:
•For a command - speak after the tone, with
normal voice at normal speed.
•Do not speak while the system is replying
(the system cannot understand commands
during this time).
•The car's doors, windows and sunroof*
must be closed.
•Avoid background noise in the passenger
compartment.
NOTE
If the driver is unsure of which command to
use, he (she) can say "Help" - the system
then responds with a few different com-
mands which can be used in the current sit-
uation.
Voice commands can be disabled by:
•saying "Cancel"
•not speaking
•a long press on the steering wheel but-
ton for Voice recognition
•Press EXIT or another source button
(e.g. MEDIA).
Help functions for voice recognition
•Instructions: A function that helps you get
familiar with the system and the procedure
for giving commands.
•Voice training: A function that enables the
voice recognition system to learn to know
your voice and your accent. The function
provides an opportunity to voice train two
user profiles.
The help functions can be accessed by press-
ing the MY CAR button on the control panel in
the centre console and then turning TUNE to
the desired menu option.
InstructionsThe instructions can be started in two ways:
NOTE
This instruction and voice training can only
be started when the car is parked.
•Press the button for Voice recognition and
say "Voice instructions".
•Activate the instructions in the menu sys-
tem MY CAR under Settings
Voice
settings
Voice tutorial. For a descrip-
tion of the menu system, see page 144.
The instructions are divided into 3 lessons,
which take around 5 minutes in total to com-
plete. The system starts with the first lesson.
ProCarManuals.com
