2012 VOLVO S60 bulb

08 Maintenance and specifications
Replacing bulbs
08
310
4. Insert a new bulb, press it in slightly and
turn it clockwise.
5. Press the bulb holder until it clicks into
place and reinstall the cover.
Location of taillight bulbs
Taillight lens, right side
Brake lights (LEDs)
Brake light
Backup light
Turn signals
Rear fog light (driver’s side only)
NOTE
If an error message remains in the display
after a faulty bulb has been replaced, con-
tact an authorized Volvo workshop.
Backup lights
1. Open the panel on the inside of the trunk
lid.
2. Remove the bulb holder by turning it coun-
terclockwise.
3. Remove the defective bulb by pressing it in
slightly and turning it counterclockwise
before pulling it out.
4. Insert a new bulb, press it in slightly and
turn it clockwise.
5. Put the bulb holder in place and turn it
clockwise.
License plate lighting
1. Remove the screws with a screwdriver.
2. Carefully detach the entire bulb housing
and pull it out.
3. Replace the bulb.
4. Reinsert the entire bulb housing and
tighten the screws.

08 Maintenance and specifications
Replacing bulbs
08

* Option/accessory, for more information, see Introduction.311 Trunk lighting
G021758
NOTE
Before starting to replace a bulb, see
page 306.
The trunk lighting is located on opposite sides
of the trunk.
1. Insert a screwdriver and gently turn so that
the bulb housing comes loose.
2. Replace the bulb.
3. Check that the bulb illuminates and press
it back into the bulb housing.
Vanity mirror lighting
Removing the mirror glass
1. Insert a screwdriver underneath the lower
edge, in the center, turn and carefully pry
up the lug on the edge.
2. Carefully detach and lift out the entire mir-
ror glass.
3. Replace the bulb.
Reinstalling the mirror glass1. Press the three lugs at top edge of the mir-
ror glass back into position.
2. Press the three lower lugs back into posi-
tion.
Bulb specifications
Lighting func-
tionWat-
tageBulb
Extra high beam
(models with Active
Bending Lights*)55H7 LL
Low beam (halo-
gen)55H11 LL
High beam (halo-
gen)65H9
Front turn signals21HY21W
License plate light-
ing5C5W LL
Vanity mirror light-
ing1.2W2x4.6d
type T5
Glove compart-
ment lighting5SV8.5
(length
43mm)
Rear turn signals21PY21W SV
Rear fog light21H21W LL
Backup light21H21W LL

08 Maintenance and specifications
Replacing bulbs
08
312
Lighting func-
tionWat-
tageBulb
Brake light21P21W LL
Trunk lighting10SV8.5
(length
38mm)
NOTE
Please consult a Volvo retailer’s Parts
department for the most up-to-date speci-
fications.
