2012 VOLVO C70 dimensions

Contents
7
09
09 Maintenance and servicing
Volvo maintenance.................................. 214
Maintaining your car............................... 215
Hood.......................................................217
Engine compartment............................... 218
Engine oil................................................ 219
Fluids...................................................... 221
Wiper blades........................................... 223
Battery..................................................... 224
Replacing bulbs...................................... 226
Fuses...................................................... 234
10
10 Audio
Introduction ............................................ 244
Audio functions....................................... 245
Radio functions....................................... 251
CD player................................................ 259
Audio menu............................................. 262
Bluetooth
® hands-free connection......... 263
11
11 Specifications
Label information.................................... 270
Dimensions and weights......................... 272
Fuel, oils, and fluids................................ 275
Engine oil................................................ 277
Engine specifications.............................. 278
Electrical system..................................... 280
Three-way catalytic converter................. 281
Overview of information and warning sym-
bols......................................................... 282
Volvo programs....................................... 284

07 Wheels and tires
Temporary spare
07
195 Temporary spare
The spare tire in your vehicle1 is called a "Tem-
porary Spare".
Recommended tire pressure (see the placard
on the B-pillar or on the fuel filler door) should
be maintained irrespective of which position on
the car the temporary spare tire is used.
In the event of damage to this tire, a new one
can be purchased from your Volvo retailer.
WARNING
Current legislation prohibits the use of the
"Temporary Spare" tire other than as a tem-
porary replacement for a punctured tire. It
must be replaced as soon as possible by a
standard tire. Road holding and handling
may be affected with the "Temporary
Spare" in use. Do not exceed a speed of
50 mph (80 km/h) with the "Temporary
Spare" in use.
CAUTION
The car must not be driven with wheels of
different dimensions or with a spare tire
other than the one that came with the car.
The use of different size wheels can seri-
ously damage your car's transmission.
1Not on models equipped with the Tire sealing system.

268
Label information.................................................................................. 270
Dimensions and weights....................................................................... 272
Fuel, oils, and fluids..............................................................................275
Engine oil............................................................................................... 277
Engine specifications............................................................................ 278
Electrical system................................................................................... 280
Three-way catalytic converter............................................................... 281
Overview of information and warning symbols..................................... 282
Volvo programs..................................................................................... 284

11 Specifications
Dimensions and weights
11
272
Dimensions
PositionDimensionIn (mm)
AWheelbase103.9 (2640)
BLength181.7 (4615)
CLoad length, floor33.5 (850)
DTrunk lid upapprox. 7.9 (200)
E1Height55.1 (1400)
E2Heightapprox. 78.7 (2000)

11 Specifications
Dimensions and weights
11

273
PositionDimensionIn (mm)
FLoad height, roof up
Load height, roof down20.4 (525)
10.2 (265)
GTrack, front60.1 (1550)
HTrack, rear61.4 (1560)
ILoad width, floor37.8 (960)
JWidth72.3 (1836)A
KWidth incl. door mirrors (folded out)79.6 in. (2025)
LWidth incl. door mirrors (folded in)72.7 in. (1847)
AModels with optional keyless drive 72.9 in. (1851)
Weights
CategoryUSACanada
Gross vehicle weight4560 lbs2070 kg
Capacity weight640 lbs290 kg
Permissible axle weight, front2440 lbs1110 kg
Permissible axle weight, rear2370 lbs1075 kg
Curb weight3810-3820 lbs1720-1740 kg
Max. trailer weight (w/o brakes)1653 lbsAll models: 750 kg

11 Specifications
Dimensions and weights
11
274
CategoryUSACanada
Max. trailer weight (with brakes)2000 lbsAll models: 900 kg
Max. tongue weight165 lbsAll models: 75 kg
CAUTION
The maximum permissible axle loads and/
or the gross vehicle weight must not be
exceeded.
WARNING
When adding accessories, equipment, lug-
gage and other cargo to your vehicle, the
total capacity weight must not be exceeded.

12 Index
12
287
Bulbs
headlights........................................... 226
list of................................................... 232
Bulbs, replacing....................................... 226
C
Capacities, fluids..................................... 275
Capacity weight............................... 185, 273
Catalytic converter, three-way................. 281
CD player................................................. 259
Cell phone, hands-free connection......... 263
Central locking system - remote key....... 122
Chains...................................................... 188
Changing a wheel.................................... 199
Child restraints
recalls and registration......................... 40
Child restraint systems.............................. 41
booster cushions.................................. 47
ISOFIX/LATCH anchors........................ 48
Child safety................................................ 39
booster cushions.................................. 47
child restraint systems.......................... 41Climate system
air distribution....................................... 95
air vents................................................ 90
Electronic Climate Control.................... 91
Interior Air Quality System.................... 92
passenger compartment filter.............. 88
recirculation.......................................... 92
refrigerant.....................................88, 275
Climate system, general information......... 88
Clock
setting................................................... 81
Cold weather precautions........................ 141
Compact disc care..................................260
Compass in rearview mirror....................... 78
Conserving electrical current................... 142
Convertible top (Power retractable hard
top)........................................................... 106
Coolant.................................................... 275
changing............................................. 221
checking level of................................. 221
Courtesy lighting...................................... 111
Crash mode............................................... 38
Cruise control............................................ 72
Cup holders.....................................113, 116
Curb weight.....................................185, 273
D
Daytime running lights.........................64, 65
Detachable key blade.............................. 124
Detachable trailer hitch............................ 166
Dimensions.............................................. 272
Disconnecting the front passenger’s air-
bag............................................................. 29
Display.......................................................61
Dolby Pro Logic II (DPL II)........................ 248
Door mirrors............................................... 79
Door Mounted Inflatable Curtain system
(DMIC)........................................................ 34
Driver distraction warning.......................... 15
Driving economically................................ 140
Driving through water..............................140
DSTC, stability system............................ 158
E
Economical driving.................................. 140
Electrical current – conserving................ 142
Electrical system...................................... 280

12 Index
12
292
tire sealing system.............................. 189
tread wear indicator............................ 178
uniform tire quality grading................. 187
winter driving...................................... 188
Tire sealing system.................................. 189
Towing a trailer........................................ 164
trailer hitch.......................................... 166
Towing the vehicle................................... 160
Trailer hitch - detachable......................... 166
Trailer towing........................................... 164
Transmission
Geartronic........................................... 152
shiftlock override................................ 153
Tread wear indicator................................ 178
Treble....................................................... 248
Trip computer............................................ 70
Trips, long distance................................. 142
Trunk
loading................................................117
opening from the inside...................... 133
opening mechanically......................... 133
Trunk divider (Power retractable hard
top)........................................................... 107
Turn signals............................................... 68
indicator lights...................................... 54U
Uniform Tire Quality Grading...................187
V
Valet locking............................................ 126
Vehicle dimensions.................................. 272
Vehicle Event Data..................................... 13
Vehicle loading........................................ 185
Vehicle maintenance................................ 214
performed by the owner.....................215
Vehicle towing.........................................160
Vehicle weights........................................ 273
VIN (Vehicle Identification Number)......... 271
Volvo and the environment........................ 14
Volvo maintenance.................................. 214
Volvo On Call Roadside Assistance........ 284
W
Warning flashers, hazard........................... 76
Warning symbol......................................... 56Warranties................................................ 214
Washer fluid..................................... 221, 275
Washer fluid reservoir......................218, 221
Water, driving through............................. 140
Weights.................................................... 273
Wheel nuts............................................... 198
Wheels.....................................................176
changing............................................. 199
storing................................................. 177
Whiplash Protection System (WHIPS)....... 35
Wind blocker (power retractable hard top)
(Power retractable hard top).................... 110
Windows
power.................................................... 77
Windshield washer fluid reservoir............218
Windshield wiper blades.......................... 223
Windshield wipers...................................... 74
rain sensor............................................ 75
Winter tires............................................... 188
Wiper blades
replacing windshield wipers............... 223
