2012 VOLVO C30 Owner´s Manual

04 Interior
Front seats
04
113
WARNING
•If a front seat head restraint has been
removed, it must be put properly back
in place and it must lock (click) into one
of the available adjustment positions
before the seat is occupied.
•The front seat head restraints must be
in position and properly adjusted to the
height of the person sitting in the seat
when the vehicle is driven and when the
front passenger's seat is occupied.

04 Interior
Interior lighting
04
114
Interior lighting
G020201
Front courtesy lights and reading lights
Front driver's side reading light, on/off
Courtesy lighting
Front passenger's side reading light, on/off
The front seat reading lights can be switched
on and off by pressing buttons (1) or (3) when
the ignition key is position I or II, or when the
engine is running.
The courtesy lighting (2) can be set to three
positions:

Press the left side of the button: the interior
courtesy lighting turns on.
Neutral position: the interior courtesy light-
ing comes on when a door is opened, and
is switched off 10 seconds after the door is
closed.

Press the right side of the button: the inte-
rior courtesy lighting stays off.
Courtesy lighting – automatic function
The interior lighting has a built-in automatic
function that switches on the courtesy lighting
for 30 seconds when:
•the car is unlocked from the outside using
the key blade or remote key
•the engine is switched off and the ignition
key is turned to the 0 position.
The courtesy lighting lights up or remains on
for 5 minutes when:
•one of the doors is opened and left open.
•the courtesy lighting has not been
switched off (the right side of button 2
depressed).
The automatic lighting goes out when:
•the engine is started
•the car is locked from the outside using the
key blade or remote key.
If the courtesy lighting is not switched off man-
ually, it will be turned off automatically5 minutes after the engine has been switched
off.
Footwell lightingThe footwell (and courtesy lighting) comes on
or goes off when one of the side doors is
opened or closed.
Vanity mirror
G020210
Raise the cover to switch on the light.

04 Interior
Storage compartments
04

115

04 Interior
Storage compartments
04
116
Compartment on rear side of front seat
backrests
Compartment in door panel
Storage pocket (on the front side of the
front seat cushion, depending on choice of
upholstery)
Glove compartment
Storage compartment for e.g., CDs and
cup holders
Compartment in rear side panels, with
space for up to three beverage cans
WARNING
•Anchor any heavy objects to prevent
them from moving during sudden stops.
Glove compartment
G024208
The owners manual and maps can be stored
here. There are also holders for coins, pens and
fuel cards. The glove compartment can only be
locked and unlocked using the detachable key
blade from the central locking system's remote
key. See page 128 for information on removing
the key blade from the remote key, and page
136 for information about locking the glove
compartment.
Storage under the front, center armrest
G018371
There are two storage compartments under the
front, center armrest.
•Press the smaller button on the front edge
of the armrest and lift the armrest cover to
access a shallow storage compartment.
•Press the larger button and lift the entire
armrest to access a deeper compartment.

04 Interior
Storage compartments
04
117
CD storage
G026704
The deep storage compartment has room for
10 CD jewel cases. These cases must be
inserted with their spines upward in order to
allow space for 10 cases in the storage com-
partment
Cup holders in the center console
G018372
Two cup holders are located under the sliding
cover in the center console.
The cup holders can be lifted out if necessary.
To do so, grasp the indentation on the rear
edge of the cup holder and lift.
To put the cup holder back in place:
1. Slide the two locating tabs in the front side
of the cup holder into the two correspond-
ing recesses in the center console storage
space.
2. Press down the rear edge of the cup
holder.
To close the sliding cover, grasp the underside
of the front edge and pull.
Storage compartment behind the gear
lever
G019623
If the buttons for optional equipment are not
installed, the recess behind the gear lever can
be used as a storage compartment for coins,
etc.

04 Interior
Rear seat
04
118
Rear seat head restraints
Adjust the head restraint vertically
Both of the rear seating positions are equipped
with a head restraint that can be adjusted ver-
tically to two different positions to help suit the
height of the passenger. The upper edge of the
head restraint should be at least on a level with
the upper-most point of the seat occupant's
ear (see illustration).

To raise: Slide the head restraint up to the
desired height.

To lower: Press the catch at the base of the
right support and press the head restraint
down.

To remove: Pull the head restraint up far as
possible. Press the catch at the base of the
right support and pull the head restraint out
of the its holders.
WARNING
If a head restraint has been removed, it must
be put properly back in place and it must
lock (click) into one of the available adjust-
ment positions before the seat is occupied.
Folding down the rear seat backrests
G009109
CAUTION
•When the backrests are folded down,
the head restraints may be damaged if
they are not removed.
•To help prevent damage to the uphols-
tery when the backrest is folded down,
be sure that there are no objects on the
seat and that the seat belt is not buck-
led.
Both sections of the rear seat backrest can be
folded down, together or separately, to enable
you to transport long objects.

04 Interior
Rear seat
04

119
To fold down one or both sections:
1. Pull the catch on the upper outboard edge
of the backrest upward and forward to
release the backrest lock. A red lock indi-
cator (A) is visible when the backrest is not
locked in the upright position.
2. Fold the backrest down.
G007608
WARNING
•The red lock indicator is VISIBLE when
the backrest is NOT locked in position
and hidden when the backrest is cor-
rectly locked in place. When the back-
rest is in the upright position, push and
pull it to make sure that it is correctly
locked in place.
•When the rear seat is folded down, do
not place heavy objects against the
backs of the front seats. This places a
severe strain on the folded down back-
rest of the rear seat. Be sure to secure
cargo.
•Cargo must not be stacked higher than
the top of seat backs. This will reduce
the possibility of luggage, etc. becom-
ing projectiles during sudden maneu-
vers, rapid braking or an accident.
Rear seat armrest
G009152
The space between the rear seats can be used
for transporting long objects.
WARNING
Long loads should be securely anchored.

04 Interior
Rear seat
04
120
WARNING
•The center of the rear seat is not a seat-
ing position. This space is not equipped
with a seat belt or ISOFIX anchors. No
one should attempt to sit in this position
and child seats should never be placed
in the center of the rear seat.
•U.S. models: The rear seat center arm-
rest is fixed in the folded down position
and cannot be folded up.
•Canadian models: The rear seat arm-
rest can be moved up or down.
