702 4-3. Do-it-yourself maintenance
SIENNA_U (OM45477U)
FuseAmpereCircuit
35 ALT 140 A Charging system, horn, left-hand
headlight (low beam), right-hand
headlight (low beam), fog light, out-
side rear view mirror heaters, rear
window defoggers, windshield
wiper de-icer
36 RAD NO.1 15 A Audio system
37 DOME 7.5 A Vanity lights, personal/interior
lights, personal lights, engine
switch light, rear ceiling lights, door
courtesy lights, luggage compart-
ment light, gauges and meters,
clock
38 ECU-B 10 A Main body ECU, smart key system,
wireless remote control, power
back door, power sliding door, rear
view monitor, multi information dis-
play, power window, outside rear
view mirror control, steering angle
sensor, auto-anti glare inside rear
view mirror, AUTO ACCESS SEAT
remote control, front passenger
occupant classification system
39 ETCS 10 A Multiport fuel injection system/
sequential multiport fuel injection
system
40 A/F 20 A Multiport fuel injection system/
sequential multiport fuel injection
system
41 STRG LOCK
*620 A Steering lock system
42 ALT-S 7.5 A Charging system

815
6
Vehicle specifications
SIENNA_U (OM45477U)
6-2. Customization
Customizable features
ItemFunctionDefault settingCustomizedsetting
Smart key
system and
wireless
remote
control
(
P. 3 653) Unlocking operation
*
Drivers door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step
Automatic door lock
function to be activated
if door is not opened
after being unlocked
*
On Off
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked
*
60 seconds 30 seconds
120 seconds
Operation signal
*
(Emergency flashers) On Off
Operation signal
(Buzzer) On Off
Open door warning
function
(when locking the vehi-
cle) On Off
Your vehicle includes a variety of
electronic features that can be
personalized to suit your preferences. Programming these
preferences requires specialized eq uipment and may be performed
by your Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

816 6-2. Customization
SIENNA_U (OM45477U)
ItemFunctionDefault settingCustomizedsetting
Wireless
remote
control
(
P. 53) Wireless remote control On Off
Operation signal
(Buzzer volume)
Level 7Level 1 to 6
Off
Panic function On Off
Power sliding door
operation On Off
Press and hold Press twice
One short press
Power back door oper-
ation On Off
Press and hold Press twice
One short press
Smart key
system
( P. 36) Smart key system On Off
Number of permissible
times of continuous
smart lock
Twice Unlimited

845
Alphabetical index
SIENNA_U (OM45477U)
Back-up lights
Replacing light bulbs ............ 709
Wattage ................................ 796
Back door Back door ............................... 82
Wireless remote control.......... 53
Battery Checking .............................. 667
If the vehicle has discharged battery ............. 770
Preparing and checking before winter ...................... 352
Bluetooth
® audio ..................... 470
Bluetooth® phone .................... 529
Bottle holder ............................ 582
Brake
Fluid...................................... 665
Parking brake ....................... 242
Brake assist ............................. 327
Break-in tips ............................ 214
Brightness control Instrument light control ......... 245
Care Exterior ................................. 630
Interior .................................. 635
Seat belts ............................. 636
Cargo capacity ........................ 343
Cargo hooks ............................ 607
CD changer .............................. 422
CD player ................................. 422
Chains ...................................... 352 Child restraint system
Booster seats, definition ........189
Booster seats, installation .....194
Convertible seats, definition .............................189
Convertible seats,
installation ...........................194
Front passenger occupant classification system ...........183
Infant seats, definition ...........189
Infant seats, installation.........194
Installing CRS with LATCH anchors ..........197, 199
Installing CRS with seat belts ............................201
Installing CRS with top tether strap............205, 206
Child safety
Airbag precautions ................177
Back door precautions ............88
Battery precautions .......669, 774
Child restraint system............189
Child-protectors .......................71
How your child should wear the seat belt ........................132
Installing child restraints ........194
Moon roof precautions ..........154
Power window lock switch.....144
Power window precautions ...147
Removed key battery precautions .........................695
Seat belt extender precautions .........................136
Seat belt precautions ............133
Seat heater precautions ........599
Child-protectors .........................71
B
C

846 Alphabetical index
SIENNA_U (OM45477U)
CleaningExterior .................................. 630
Interior ...................................635
Seat belts ..............................636
Clock ................................. 252, 592
Compass ...................................617
Condenser ................................664
Console box ............................. 575
Conversation mirror ................593
Cooling system Engine overheating ............... 775
Cruise control
Cruise control ....................... 293
Dynamic radar cruise control .................................298
Cup holders ..............................579
Curtain shield airbags ............. 168
Customizable features............. 815 Daytime running light
system .................................... 270
Defogger
Rear window ......................... 405
Side mirrors........................... 405
Dimension ................................ 784
Dinghy towing .......................... 376
Display Dynamic radar cruise
control ................................. 298
Multi-information display ....... 252
Trip information ..................... 252
Warning messages ............... 744
Do-it-yourself maintenance .... 647
Door courtesy lights Door courtesy lights .............. 566
Wattage................................. 796
Door lock
Back door ................................ 82
Front door ............................... 60
Sliding door ............................. 67
Wireless remote control key ........................................ 53
Doors Back door ................................ 82
Door lock ..................... 53, 60, 68
Front doors.............................. 60
Side mirrors........................... 140
Sliding doors ........................... 67
Driver’s seat belt reminder light ......................................... 733
Driving Break-in tips .......................... 214
Correct posture ..................... 166
Procedures............................ 212
Winter driving tips ................. 352
Driving position memory ........ 120
DVD player........ 499, 509, 513, 514D

849
Alphabetical index
SIENNA_U (OM45477U)
I/M test ...................................... 646
Identification
Engine .................................. 785
Vehicle.................................. 785
Ignition switch ................. 226, 229
Illuminated entry system ........ 571
Indicator lights ........................ 247
Initialization Items to initialize ................... 823
Inside rear view mirror............ 138
Interior lights Interior lights ......................... 566
Switch ................................... 567
Wattage ................................ 796
Intuitive parking assist ........... 314
Jack
Positioning a floor jack ......... 653
Vehicle-equipped jack .......... 747
Jack handle.............................. 747
Keyless entry ............................. 53
Keys Electronic key ......................... 32
Engine switch ............... 226, 229
If you lose your keys............. 766
If the electronic key does not operate
properly .............................. 767
Ignition switch ............... 226, 229
Keyless entry .......................... 53
Key number ............................ 32
Keys ....................................... 32
Mechanical key....................... 32
Wireless remote control.......... 53 License plate lights
Replacing light bulbs .............709
Wattage .................................796
Light bulbs Replacing ..............................709
Wattage .................................796
Lights Door courtesy lights ..............566
Engine switch light ................566
Fog light switch .....................280
Headlight switch ....................266
Interior light switch ................567
Luggage compartment light .......................................85
Outer foot lights .....................566
Personal light switch .............567
Rear ceiling light....................570
Replacing light bulbs .............709
Turn signal lever....................241
Vanity lights ...........................591
Wattage .................................796
Load capacity ...........................351
Lock steering column ......227, 233
Luggage compartment light Switch......................................85
Wattage .................................796I
J
K
L

851
Alphabetical index
SIENNA_U (OM45477U)
Rear turn signal lights
Replacing light bulbs ............ 709
Switch ................................... 241
Wattage ................................ 796
Rear view mirror Compass .............................. 617
Rear window defogger............ 405
Rear window wiper.................. 290
Replacing Electronic key battery ........... 693
Fuses.................................... 696
Light bulbs ............................ 709
Rear seat entertainment system control battery ........ 496
Tires ..................................... 747
Wireless remote control
battery ................................ 693
Reporting safety defects for
U.S. owners ........................... 826
Roof luggage carrier ............... 346
Safety connect......................... 622
Seat belts Adjusting the seat belt .......... 129
Automatic Locking
Retractor ............................ 131
Child restraint system
installation .......................... 194
Cleaning and maintaining the seat belts...................... 636
Emergency Locking Retractor ............................ 131
How to wear
your seat belt ..................... 128
How your child should wear the seat belt ....................... 132
Pre-collision seat belt ........... 131
Pregnant women, proper seat belt use ........... 132
Reminder light ...................... 733
Seat belt extenders .............. 133
Seat belt pretensioners ........ 131 Seat heaters..............................598
Seating capacity.......................351
Seats
Adjustment ......................95, 100
Adjustment precaution .....................99, 116
Child seats/child restraint system installation ..............194
Cleaning ................................635
Driver’s seat position
memory ...............................120
Head restraint........................125
Properly sitting in the seat .....166
Seat heaters ..........................598
Service reminder
indicators ..............................247
Shift lever Automatic transaxle...............236
If the shift lever cannot
be shifted from P................. 764
Shift lock system .....................764
Side airbags..............................168
Side marker lights Replacing ..............................709
Switch....................................266
Wattage .................................796
Side mirrors Adjusting and folding .............140
Mirror position memory .........120
Sliding doors Sliding doors ...........................67
Wireless remote control ..........53
Smart key system Entry function ..........................36
Starting the engine ................229
S

854 Alphabetical index
SIENNA_U (OM45477U)
WeightCargo capacity ......................343
Load limits ............................. 351
Weight ...................................784
Wheels ......................................687
Window glasses ..............144, 148
Window lock switch .................144
Windows Power windows ............. 144, 148
Rear window defogger .......... 405
Washer .......................... 282, 290
Windshield wiper de-icer.........405
Windshield wipers ...................282
Wireless remote control key Replacing the battery ............693
Wireless remote control .......... 53
WMA disc .................................. 431
