2012 TOYOTA HIGHLANDER HYBRID fog light bulb

510
4-3. Do-it-yourself maintenance
Light bulbs
You may replace the following bulbs yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perfor m, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■ Prepare a replacement light bulb.
Check the wattage of the light bulb being replaced. ( P. 583)
■ Turn the power back door main switch OFF. (vehicles with
power back door)
P. 7 2
■ Front bulb locations
Headlight high
beams and
daytime running
lights (if equipped)
Headlight low beams
Fog lights
Parking, front side
marker and front turn
signal lights

512 4-3. Do-it-yourself maintenance
Turn the bulb base counterclock-
wise.Low beam
High beam
■ Fog lights
Unplug the connector while
depressing the lock release.
Turn the bulb base counterclock-
wise.STEP2
STEP1
STEP2

583
6-1. Specifications
6
Vehicle specifications
Light bulbs
A: H11 halogen bulbs
B: Wedge base bulbs (amber)
C: HB3 halogen bulbs D: Wedge base bulbs (clear)
E: PSX26W F: Double end bulbs
*: If equipped
Light BulbsBulb No.WTy p e
ExteriorHeadlights
High beam
Low beam 9005
 60
55 C
A
Parking, front side marker and
front turn signal lights 3457NA 28/8 B
Fog lights 24 E
Rear turn signal lights 21 B
Back-up lights 921 16 D
Stop/tail and rear side marker
lights 7443 21/5 D
License plate lights 5D
Outer foot lights* 5D
Interior Vanity lights
8D
Personal/interior lights (front) 5D
Personal lights (center) 5D
Interior lights (rear) 8F
Door courtesy lights 168 5 D
