2012 TOYOTA DYNA 100/150 cab tilt

KEYS AND DOORS11
Section 1−2
OPERATION OF INSTRUMENTS AND
CONTROLS
Keys and Doors
DKeys 12..............................................
DSide doors 13.........................................
DPower windows 14.....................................
DTailgate and side gates 16..............................
DEngine access hole cover 17...........................
DTilt cab 18............................................
DFuel tank cap 21.......................................
Dyna100/150_EE

18KEYS AND DOORS
Before tilting the cab, observe the fol-
lowing.
1. Park the vehicle on a level ground.
2. Set the parking brake firmly.
3. Put the transmission in neutral.
4. Stop the engine.
5. Remove or secure all the loose items
in the vehicle.
6. Close the doors.
CAUTION
Make sure that no one is around and
in the cab.
NOTICE
Make sure that there is no interfering
object on and in front of the cab.

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Handle latch lever
Cab lock
handle
1. Pull the cab lock handle up while
holding the handle latch lever up,
and the cab will spring up slightly.
Dyna100/150_EE
Tilt cab—
(single cab models
)—Tilting the cab

KEYS AND DOORS19
Safety
catch lever
Cab stay
lock lever
2. Hold the cab down, pull the safety
catch lever out and raise the cab to
tilt forward. Make sure that the cab
stay lock lever locks securely.
The cab will automatically lock when it
tilts fully forward.
CAUTION
When the cab tilts fully forward, make
sure the cab stay lock lever securely
locks and that the cab does not low-
er.
Cab stay lock
lever stopper
3. Plug the opening with the cab stay
lock lever stopper for additional se-
curity.
CAUTION
When tilting the cab, make sure that
the cab stay lock lever stopper has
immobilized the cab stay lock lever.
If it is not immobilized, the cab could
lower and cause death or serious in-
juries.
Dyna100/150_EE

20KEYS AND DOORS
1. Pull the cab stay lock lever stopper
up and return it to the upper hole.
While holding the cab with the grip,
pull the cab stay lock lever up to
unlock, then lower the cab slowly.
Before lowering the cab, check to see that
you have not forgotten any tools, rags,
etc.
CAUTION
When lowering the cab, make sure
that no one is around the cab.
2. Press down the cab lock handle
firmly.
Make sure the cab is securely locked.
CAUTION
Do not drive the vehicle without lock-
ing the cab securely. Otherwise, the
cab may be tilted unexpectedly, possi-
bly causing an accident.
Dyna100/150_EE
—Lowering the cab

156IN CASE OF AN EMERGENCY
If your engine coolant temperature
gauge indicates overheating, if you ex-
perience a loss of power, or if you hear
a loud knocking or pinging noise, the
engine has probably overheated. You
should follow this procedure...
1. Pull safely off the road, stop the ve-
hicle, and turn on your emergency
flashers. Put the transmission in neu-
tral and apply the parking brake. Turn
off the air conditioning if it is being
used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine.
Wait until the steam subsides before
opening the engine access hole cover
or tilting the cab. If there is no coolant
or steam boiling over, leave the engine
running and make sure the electric
cooling fan is operating. If it is not,
turn the engine switch off.
CAUTION
To help avoid serious injury, keep the
engine access hole cover closed or
the cab lowered until there is no
steam. Escaping steam or coolant is
a sign of very high pressure.
3. Visually check to see if the engine
drive belt (fan belt) is broken or loose.
Look for obvious coolant leaks from the
radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has
been used.
CAUTION
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.
4. If the engine drive belt is broken or the
coolant is leaking, stop the engine im-
mediately. Call any authorized Toyota
dealer or repairer, or another duly qual-
ified and equipped professional, for as-
sistance.
5. If the engine drive belt is O.K. and
there are no obvious leaks, you may
help the engine cool down more quickly
by running it at about 1500 rpm for a
few minutes with the accelerator pedal
lightly depressed.
6. Check the coolant reservoir. If it is dry,
add coolant to the reservoir while the
engine is running. Fill it about half full.
For the coolant type, see “Coolant type
selection” on page 199 in Section 7−2.
CAUTION
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure.
7. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If neces-
sary, bring it up to half full again.
Serious coolant loss indicates a leak in
the system. You should have it
checked as soon as possible at any
authorized Toyota dealer or repairer, or
another duly qualified and equipped
professional.
Dyna100/150_EE
If your vehicle overheats

214DO−IT−YOURSELF MAINTENANCE: Electrical components
1. Single cab models: Tilt the cab. (See
“Tilt cab” on page 18 in Section 1−2
for details.)
Unplug the connector.
If the connector is tight, wiggle it.2. Remove the rubber cover.
Dyna100/150_EE
—Headlights

INDEX233
N
New vehicle break−in 116................
O
Odometer 70............................
Oil
Consumption 123......................
Oil maintenance management
system 70..........................
Viscosity and grade 196................
Oil consumption 123.....................
OMMS 70...............................
Operation in foreign countries 118........
Overheating, Engine 156.................
Overheating, Engine coolant 68..........
Overview
Engine compartment 188...............
P
Parking brake
Operation 82..........................
Reminder light 82.....................
Parking brake reminder light 73...........
Polishing 179...........................
Power window switches 14...............
Pre−trip safety check 134................
Precautions for turning off an engine
with turbocharger 134..................
Preloader (seat belt pretensioner) 35.....
Pretensioner
(seat belt pretensioner) 35.............
Protecting your Toyota from
corrosion 178.........................
R
Radiator
Checking the radiator 200..............
Coolant, Engine 198...................
Radio 84................................
Rear fog light switch 64..................
Rear heatersystem 100..................
Rear seat 26............................
Rear view mirrors
Folding 59............................
Outside 59............................
S
Safety check, Pre−trip 134...............
Seat belts
Cleaning 181..........................
Fastening 28..........................
Seat belt precautions 28...............
Seat belt pretensioner 35..............
Seats 24................................
Service and maintenance 184............
Service reminder indicator 73............
Side door locks 13.......................
Side doors 13...........................
Side gate 16............................
Side vents 99...........................
Spare fuse 211..........................
Spare tire 158...........................
Specifications 220.......................
SRS driver airbag 38....................
SRS warning light 73....................
Starting
Cold weather 132......................
Engine 132............................
Jump starting 151.....................
Steering
Adjusting steering wheel 58............
Storage precautions 109.................
Suspension and chassis 130.............
Switch
Emergency flasher 64.................
Engine 80.............................
Headlight, dimmer and
turn signal 62.......................
Heater idle up 101.....................
Ignition 80............................
Rear fog light 64.......................
Windshield wiper and washer 65........
T
Tachometer 69..........................
Tailgate 16..............................
Telescopic steering wheel 58.............
Tilt cab 18..............................
Tilt steering wheel 58....................
Timing belt replacement
warning light 73.......................
Dyna100/150_EE
