200DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
If any of the above parts are extremely
dirty or you are not sure of their condi-
tion, take your vehicle to any authorized
Toyota dealer or repairer, or another duly
qualified and equipped professional.
CAUTION
To prevent burning yourself, be care-
ful not to touch the radiator, con-
denser and intercooler when the en-
gine is hot.
NOTICE
To prevent damage to the radiator,
condenser and intercooler, do not per-
formtheworkbyyourself.
When the fuel filter warning light
comes on, the water in the fuel filter
must be drained immediately.
Place a small tray under the drain plug to
catch the water.
1. Turn the drain plug about 2—2−1/2
turns, as shown above. (Loosening
more than this will cause water oozing
from around the drain plug.)
2. Operate the priming pump until fuel be-
gins to run out.
After draining, retighten the drain plug. Do
not use a tool.
Dyna100/150_EE
Checking the radiator,
condenser and intercoolerDraining fuel filter water

208DO−IT−YOURSELF MAINTENANCE: Electrical components
CAUTION
BATTERY PRECAUTIONS
The battery produces flammable and
explosive hydrogen gas.
DDo not cause a spark from the bat-
tery with tools.
DDo not smoke or light a match near
the battery.
The electrolyte contains poisonous
and corrosive sulfuric acid.
DAvoid contact with eyes, skin or
clothes.
DNever ingest electrolyte.
DWear protective safety glasses when
working near the battery.
DKeep children away from the bat-
tery.
EMERGENCY MEASURES
DIf electrolyte gets in your eyes,
flush your eyes with clean water
immediately and get immediate
medical attention. If possible, con-
tinue to apply water with a sponge
or cloth while en route to the medi-
cal office.
DIf electrolyte gets on your skin,
thoroughly wash the contact area. If
you feel pain or burning, get medi-
cal attention immediately.
DIf electrolyte gets on your clothes,
there is a possibility of its soaking
through to your skin, so immediate-
ly take off the exposed clothing and
follow the procedure above, if nec-
essary.
DIf you accidentally swallow electro-
lyte, drink a large quantity of water
or milk. Get emergency medical
attention immediately.
The electricity stored in the battery will
discharge gradually even when the vehicle
is not in use, due to natural discharge
and the draining effects of certain electri-
cal appliances. If the vehicle is left for a
long time, the battery may discharge, and
the engine may be unable to start. (The
battery recharges automatically during
driving.)
Some models—
The meanings of each caution symbol
on the top of the battery are as fol-
lows:
No smoking, no naked
flames, no sparks
Shield eyes
Keep away from
children
Battery acid
Note operating
instructions
Explosive gas
Dyna100/150_EE
Checking battery condition—
—Precautions

DO−IT−YOURSELF MAINTENANCE: Electrical components211
Ty p e A
Good Blown
Ty p e B
Good Blown
Ty p e C
Good Blown
Instrument panel
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” on page 190 in Sec-
tion 7−1 for locations of the fuses.
Turn the engine switch and inoperative
component off. Pull the suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
page 227 in Section 8 for the functions
controlled by each circuit.
Type A fuses can be pulled out by the
pull−out tool. The location of the pull−out
tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the “CIG”,
“DOME” or “A/C” fuse, which may be dis-
pensable for normal driving, and use it if
its amperage rating is the same.
Dyna100/150_EE
Checking and replacing fuses

230INDEX
A
Adding washer fluid 212..................
Adjustment
Driver ’s seat 25.......................
Seat belt 28...........................
Air bleeding 150.........................
Air conditioning filter 101.................
Air conditioningsystem 92...............
Airbag 38...............................
Anti−lock brake system
warning light 73.......................
Anti−theft steering column lock 80........
Appearance care
Cleaning the interior 181...............
Protecting your Toyota from
corrosion 178.......................
Washing and waxing 179...............
Audio system 84........................
Audio systemoperating tips 89...........
Auxiliary box 110........................
B
Battery
Access 190...........................
Checking battery condition 208.........
Gas caution 208.......................
Handling safety 208...................
Recharging precautions 210............
Winter driving tips 137.................
Before starting the engine 132............
Brake pad wear indicators 127............
Brake system 124.......................
Brake system warning light 73............
Brakes
Pad wear indicators 127................
Parking 82............................
Break−in tips 116........................
C
Carbon monoxide caution 122............
Card holder 112.........................
Center console box 111..................
Charging system warning light 73.........
Checking and replacing fuses 211........
Checking the engine oil level 196.........
Checking the radiator, condenser and
intercooler 200........................Child restraint
Child restraint system 45...............
Installation 48,51......................
Precautions 44........................
Types of child restraint system 46.......
Cigarette lighter and ashtrays 108........
Cleaning the interior 181.................
Cold weather
Operation 137.........................
Condenser
Checking the condenser 200...........
Controls, Instrument panel 2,6...........
Cooling system
Coolant level 198......................
Engine overheating 156................
Radiator and reservoir 198.............
Radiator cap 156......................
Winter driving tips 137.................
Corrosion prevention 178................
Cup holder 110..........................
D
Diesel particulate filter system 118........
Differential, Limited slip 128..............
Dimmer switch, Headlight 62.............
Directional signals 62....................
Do−it−yourself maintenance
Service precautions 193...............
Does your vehicle need repairing? 185....
Doors
Side doors 13.........................
DPF system 118.........................
Driver ’s seat 25.........................
Driving
Driving tips 132........................
Manual transmission 81................
Driving in the rain 136....................
Driving tips
Driving in the rain 136..................
Driving tips in various conditions 135....
Driving with a manual
transmission 81.....................
Economical driving 146................
Good driving practice 81...............
Pre−trip safety check 134..............
Winter driving tips 137.................
During
Break−in 116..........................
Dyna100/150_EE

INDEX231
E
Economical driving
Saving money on both fuel and
repairs 146..........................
Electrical system
Access to the battery 190..............
Battery 208,210.......................
Fuse locations 190....................
Fuses 211............................
Emergency flasher switch 64.............
Emergency, In case of
Bleeding the fuelsystem 150...........
Blown fuse 211........................
Emergency flasher switch 64...........
Flat tire 157...........................
If you cannot increase engine
speed 155..........................
If you lose your keys 174...............
If your engine stalls while
driving 155..........................
If your vehicle becomes stuck 170......
If your vehicle has to be stopped in
an emergency 175...................
If your vehicle needs to be
towed 171...........................
If your vehicle will not start 150.........
Jump starting 151.....................
Overheating 156.......................
Towing 171............................
Engine
Access hole cover 17..................
Before starting the engine 132..........
Checking the coolant level 198.........
Engine compartment 188...............
Exhaust gas caution 122...............
Identification number 130..............
Oil consumption 123...................
Oil level 196...........................
Overheating 156.......................
Starting procedure 132.................
Turning off an engine with
turbocharger 134....................
Engine coolant
Temperature gauge 68.................
Winter driving tips 137.................
Engine coolant temperature gauge 68.....Engine oil
Oil maintenance management
system 70..........................
Winter driving tips 137.................
Engine oil change reminder light 73.......
Engine switch 80........................
Exhaust gas caution 122.................
F
Facts about engine oil
consumption 123......................
Flasher, Headlight 62....................
Flat tire
After changing wheels 170.............
If you have a flat tire 157...............
Installing wheel 167....................
Jack point 165.........................
Jacking precautions 157...............
Jacking up 165........................
Loosening wheel nuts 163..............
Lowering vehicle 168..................
Reinstalling wheel ornament 169........
Removing wheel ornament 163.........
Replacing inner rear wheel 166.........
Wheel block 162.......................
Floor mat 112...........................
Fluid level
Washer fluid 212......................
Fog light switch, Rear 64.................
Foreign countries, Operation in 118.......
Fuel
Bleeding the fuelsystem 150...........
Draining fuel filter water 200............
Fuel economy 146.....................
Gauge 68.............................
Operation in foreign countries 118......
Tank cap 21...........................
Fuel filter
Draining fuel filter water 200............
Fuel filter warning light 73................
Fuel information 116.....................
Fuse
Fuse box 211..........................
Fuse locations 190......................
Dyna100/150_EE

232INDEX
G
Gauge
Engine coolant temperature 68.........
Fuel 68...............................
Glove box 109...........................
Good driving practice 81.................
H
Hazard switch 64........................
Head restraints 27.......................
Headlight beam level control dial 63.......
Headlight switch 62......................
Heater idle up switch 101.................
High speed operation
During break−in 116...................
How to start the engine 132...............
I
Identification
Engine 130............................
Vehicle 128...........................
Ignition switch 80........................
Indicator symbols 8.....................
Instrument panel
Cigarette lighter and ashtrays 108......
Fuel gauge 68.........................
Indicator symbols 8....................
Odometer 70..........................
Tachometer 69........................
Trip meter 70..........................
Instrument panel overview 2,6...........
Intercooler
Checking the intercooler 200...........
J
Jack
Location 158..........................
Jump starting 151.......................
K
Keys 12,174............................
L
Light bulbs
Back−up lights 217....................
Front position lights 216................
Front turn signal lights 216.............
Headlights 214........................
License plate lights 218................
Rear fog light 218......................
Rear turn signal lights 217..............
Side turn signal lights 216..............
Stop/tail lights 217.....................
Light bulbs, Replacing 213...............
Light reminder buzzer 73.................
Light, Interior
Interior light 65........................
Limited slip differential 128...............
Lock
Side doors 13.........................
Side gate 16..........................
Steering column 80....................
Tailgate 16............................
Low brake fluid level warning light 73......
Low engine oil level warning light 73......
Low engine oil pressure
warning light 73.......................
Low fuel level warning light 73............
Low vacuum warning light 73.............
Luggage stowage precautions 127........
M
Maintenance
Do−it−yourself maintenance 193........
Does your vehicle need
repairing? 185.......................
Maintenance facts 184.................
Where to go for service 184............
Malfunction indicator lamp 73............
Manual regeneration switch,
Diesel particulate filter system 118......
Manual transmission
Driving with a manual
transmission 81.....................
Shift pattern 81........................
Maximum allowable speed
Manual transmission 81................
Mirrors
Folding rear view 59...................
Outside rear view 59...................
Dyna100/150_EE

INDEX233
N
New vehicle break−in 116................
O
Odometer 70............................
Oil
Consumption 123......................
Oil maintenance management
system 70..........................
Viscosity and grade 196................
Oil consumption 123.....................
OMMS 70...............................
Operation in foreign countries 118........
Overheating, Engine 156.................
Overheating, Engine coolant 68..........
Overview
Engine compartment 188...............
P
Parking brake
Operation 82..........................
Reminder light 82.....................
Parking brake reminder light 73...........
Polishing 179...........................
Power window switches 14...............
Pre−trip safety check 134................
Precautions for turning off an engine
with turbocharger 134..................
Preloader (seat belt pretensioner) 35.....
Pretensioner
(seat belt pretensioner) 35.............
Protecting your Toyota from
corrosion 178.........................
R
Radiator
Checking the radiator 200..............
Coolant, Engine 198...................
Radio 84................................
Rear fog light switch 64..................
Rear heatersystem 100..................
Rear seat 26............................
Rear view mirrors
Folding 59............................
Outside 59............................
S
Safety check, Pre−trip 134...............
Seat belts
Cleaning 181..........................
Fastening 28..........................
Seat belt precautions 28...............
Seat belt pretensioner 35..............
Seats 24................................
Service and maintenance 184............
Service reminder indicator 73............
Side door locks 13.......................
Side doors 13...........................
Side gate 16............................
Side vents 99...........................
Spare fuse 211..........................
Spare tire 158...........................
Specifications 220.......................
SRS driver airbag 38....................
SRS warning light 73....................
Starting
Cold weather 132......................
Engine 132............................
Jump starting 151.....................
Steering
Adjusting steering wheel 58............
Storage precautions 109.................
Suspension and chassis 130.............
Switch
Emergency flasher 64.................
Engine 80.............................
Headlight, dimmer and
turn signal 62.......................
Heater idle up 101.....................
Ignition 80............................
Rear fog light 64.......................
Windshield wiper and washer 65........
T
Tachometer 69..........................
Tailgate 16..............................
Telescopic steering wheel 58.............
Tilt cab 18..............................
Tilt steering wheel 58....................
Timing belt replacement
warning light 73.......................
Dyna100/150_EE
