331
3-7. Other interior features
3
Interior features
■
Circling calibration
Stop the vehicle in a place where it is safe to drive in a circle.
Press and hold “AUTO” for 9
seconds.
C appears on the compass dis-
play.
Drive the vehicle at 5 mph
(8 km/h) or less in a circle until a
direction is displayed.
If there is not enough space to
drive in a circle, drive around the
block until the direction is dis-
played.
STEP 1
STEP 2
STEP 3
■Conditions unfavorable for correct operation
The compass may not show the correct direction in the following situations:
●The vehicle is stopped immediately after turning.
● The vehicle is on an inclined surface.
● The vehicle is in a place where the earth's magnetic field is subject to
interference by artificial magnetic fields (underground car park/parking
lot, under a steel tower, between buildings, roof car park/parking lot, near
an intersection, near a large vehicle, etc.).
● The vehicle has become magnetized.
(There is a magnet or metal object near the anti-glare inside rear view
mirror.)
● The battery has been disconnected.
● A door is open.

332 3-7. Other interior features
CAUTION
■While driving the vehicle
Do not adjust the display. Be sure to adjust the display only when the vehicle
is stopped.
■ When doing the circling calibration
Be sure to secure a wide space, and watch out for people and vehicles in the
neighborhood. Do not violate any local traffic rules while performing circling
calibration.
NOTICE
■To avoid compass malfunctions
Do not place magnets or any metal objects near the anti-glare inside rear
view mirror.
Doing this may cause a malfunction of the compass sensor.
■ To ensure normal operation of the compass
●Do not perform circling calibration of the compass in a place where the
earth's magnetic field is subject to interference by artificial magnetic fields.
● During calibration, do not operate electric systems (moon roof, power win-
dows, etc.) as they may interfere with the calibration.

396 4-3. Do-it-yourself maintenance
■Under the driver’s side instrument panel
FuseAmpereCircuit
1 DEF 40 A Rear window defogger, MIR HTR
2 PWR SEAT 30 A Power seat
3 TAIL 10 A Parking lights, tail lights, license
plate lights, front side marker lights,
multiport fuel injection system/
sequential multiport fuel injection
system, instrument cluster lights
4 PANEL 7.5 A Switch illumination
5 FR DOOR 20 A Power windows, moon roof
6 RL DOOR 20 A Power windows
7 RR DOOR 20 A Power windows
8 SUNROOF 20 A Moon roof
9 CIG 15 A Cigarette lighter
10 ACC 7.5 A Outside rear view mirrors, audio
system, main body ECU
11 MIR HTR 10 A Outside rear view mirror defogger
12 IGN 7.5 A Steering lock system, SRS airbag
system, multiport fuel injection sys-
tem/sequential multiport fuel injec-
tion system, front passenger
occupant classification system
13 METER 7.5 A Gauge and meters

518 Alphabetical index
Floor mat................................... 328
FluidBrake ..................................... 361
Washer .................................. 366
Fog lights
Replacing light bulbs ............. 399
Switch.................................... 164
Wattage ................................. 475
Front passenger occupant classification system ..............98
Front passenger's seat belt
reminder light......................... 422
Front seats Adjustment ..............................51
Front side marker lights Replacing light bulbs ............. 399
Switch.................................... 160
Wattage ................................. 475
Front turn signal lights Replacing light bulbs ............. 399
Switch.................................... 146
Wattage ................................. 475
Fuel
Capacity ................................ 468
Fuel gauge ............................ 149
Fuel pump shut off system .... 419
Gas station information ......... 528
Information ............................ 476
Refueling .................................77
Type ...................................... 468
Fuel door.....................................77
Fuel filler door ............................77
Fuel pump shut off system ..... 419
Fuses......................................... 389 Gas station information .......... 528
Gauges...................................... 149
Glove box ................................. 312
Hands-free phone system
(for cellular phone) ................ 279
Hazard lights
Switch ................................... 412
Head restraints Adjusting ................................ 56
Headlights Replacing light bulbs ............. 399
Switch ................................... 160
Wattage................................. 475
Heaters Seat heater ........................... 326
Side mirror ............................ 219
Hood.......................................... 349
Horn .......................................... 148
I/M test ...................................... 344
Identification number Engine ................................... 464
Vehicle .................................. 464
Ignition switch.................. 131, 135
Illuminated entry system......... 308
Indicator lights ......................... 152
Initialization Items to initialize ................... 495
Inside rear view mirror .............. 67
Interior lights
Interior lights ......................... 307
Switch ................................... 309
Wattage................................. 475FG
H
I

519
Alphabetical index
Jack
Positioning a floor jack ......... 351
Vehicle-equipped jack .......... 432
Jack handle.............................. 432
Keyless entry ............................. 36
Keys Electronic key ......................... 22
Engine switch ............... 131, 135
If you lose your keys............. 447
If your electronic key battery is discharged .......... 448
Ignition switch ............... 131, 135
Key number ............................ 22
Keyless entry .......................... 36
Keys ....................................... 22
Mechanical key....................... 22
Wireless remote control key ... 36
License plate lights Replacing light bulbs ............ 399
Switch ................................... 160
Wattage ................................ 475
Light bulbs
Replacing ............................. 399
Wattage ................................ 475
Lights
Fog light switch..................... 164
Headlights switch ................. 160
Interior light switch................ 309
Personal light switch............. 309
Personal/interior light switch ................................. 310
Replacing light bulbs ............ 399
Turn signal lever ................... 146
Wattage ................................ 475
Load capacity .......................... 180
Lock steering column ..... 133, 137 Maintenance
Do-it-yourself
maintenance .......................345
General maintenance ............341
Maintenance data..................464
Maintenance requirements....339
Manual air conditioning system ....................................212
Manual transmission Manual transmission .............145
Meter
Instrument panel light control .................................151
Meters ...................................149
Mirrors Inside rear view mirror.............67
Side mirror heater .................219
Side mirrors .............................69
Vanity mirrors ........................321
Moon roof ...................................73
MP3 disc ...................................243
Multi-information display ....................................156J
K
L
M

520 Alphabetical index
Noise from under vehicle ..........15
Odometer .................................. 149
OilEngine oil .............................. 356
Opener Fuel filler door .........................77
Hood...................................... 349
Trunk .......................................47
Outside rear view mirrors
Adjusting and folding ...............69
Outside temperature display .................................... 156
Overheating, Engine ................456
Parking brake ........................... 147
Parking lights Replacing light bulbs ............. 399
Switch.................................... 160
Wattage ................................. 475
Personal lights
Switch.................................... 309
Wattage ................................. 475
Personal/interior lights
Switch.................................... 310
Wattage ................................. 475
Power outlet ............................. 325
Power windows ..........................71 Radiator .................................... 361
Radio ......................................... 232
Rear seats
Folding down........................... 54
Rear side marker lights
Replacing light bulb............... 399
Switch ................................... 160
Wattage................................. 475
Rear turn signal lights Replacing light bulbs ............. 399
Switch ................................... 146
Wattage................................. 475
Rear view mirror Compass ............................... 329
Rear window defogger ............ 219
Replacing Fuses .................................... 389
Key battery ............................ 385
Light bulbs............................. 399
Tires ...................................... 432
Reporting safety defects for U.S.A. owners ........................ 498
Reset the maintenance
data ......................................... 340N
O
P
R
