Page 466 of 532
466
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
*1: Unladen vehicles
*2: P215/55R17 and P225/45R18 tires
*3: P205/65R16 tires
Vehicle identification■ Vehicle identification number
The vehicle identificati on number (VIN) is the legal identifier for your
vehicle. This is the primary identification number for your Toyota. It is
used in registering the ownership of your vehicle.
This number is located on the
top left of the instrument panel.
Overall length 189.2 in. (4805 mm)
Overall width71.7 in. (1820 mm)
Overall height*157.9 in. (1470 mm)
Wheelbase109.3 in. (2775 mm)
Tread
Front62.0 in. (1575 mm)*2
62.4 in. (1585 mm)*3
Rear61.6 in. (1565 mm)*2
62.0 in. (1575 mm)*3
Vehicle capacity weight
(Occupants + luggage) 905 lb. (410 kg)
Page 484 of 532
484 6-1. Specifications
Tire size■ Typical tire size information
The illustration indicates typical tire size.
Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■ Tire dimensions
Section width
Tire height
Wheel diameter
Page 520 of 532

520 Alphabetical index
Child safetyAirbag precautions ................108
Battery precautions ....... 364, 457
Child restraint system............ 118
Child-protectors .......................54
How your child should wear
the seat belt ..........................71
Installing child restraints ........ 122
Moon roof precautions ............87
Power window lock switch.......81
Power window precautions .....83
Removed key battery
precautions ......................... 387
Seat belt extender
precautions ...........................75
Seat belt precautions ..............73
Seat heater precautions ........ 308
Trunk precautions ...................60
Cleaning Exterior .................................. 334
Interior ................................... 337
Seat belts .............................. 338
Clock ......................................... 300
Coin holder ............................... 292
Compass ................................... 322
Condenser ................................ 361
Console box ............................. 291
Cooling system Engine overheating ............... 459
Cruise control........................... 199
Cup holder ................................ 294
Curtain shield airbags ............. 100
Customizable features............. 493 Daytime running light
system .................................... 189
Defogger Outside rear view mirror........ 240
Rear window ......................... 240
Dimensions .............................. 466
Dinghy towing .......................... 223
Do-it-yourself maintenance .......................... 347
Door courtesy light Door courtesy light ................ 285
Wattage................................. 477
Doors Door lock ..................... 32, 46, 52
Door windows ......................... 81
Outside rear view mirrors ........ 79
Driver's seat belt reminder
light ......................................... 423
Driving Break-in tips .......................... 135
Correct posture ....................... 98
Procedures............................ 134
Winter driving tips ................. 218D
