537
6-1. Specifications
6
Vehicle specifications
■
Temperature A, B, C
The temperature grades are A (the highest), B, and C, represent-
ing the tire’s resistance to the generation of heat and its ability to
dissipate heat when tested under controlled conditions on a speci-
fied indoor laboratory test wheel.
Sustained high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can lead
to sudden tire failure.
The grade C corresponds to a level of performance which all passen-
ger car tires must meet under the Federal Motor Vehicle Safety Stan-
dard No. 109.
Grades B and A represent higher levels of performance on the labo-
ratory test wheel than the minimum required by law.
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
548 6-2. Customization
ItemFunctionDefault settingCustomizedsetting
Windshield
wipers and
washer
( P. 189) Switching operation
when the vehicle is sta-
tionary
ON
OFF
Time elapsed before
the drip prevention
function operates Variable
depending on
the vehicle
speed
3 seconds
Illumination
( P. 346) Time elapsed before
lights turn off
15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked ON
OFF
Operation after the
“ENGINE START
STOP” switch or the
engine switch turned
OFF ON
OFF
Front/rear personal
lights turned on when a
door is opened Corresponding
light only All lights
OFF
Outer foot lights ONOFF
Rear
sunshade
( P. 366) Time elapsed before
the reverse operation
feature activates
0.7 seconds0 seconds
0.9 seconds
1.2 seconds
576
What to do if...
What to do if...
A tire puncturesP. 491If you have a flat tire
The engine does not start
P. 9 6Engine immobilizer system
P. 501If the engine will not start
P. 508If the battery is discharged
The shift lever cannot be
moved outP. 503If the shift lever cannot be shifted
from “P”
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 512If your vehicle overheats
The key is lostP. 504If you lose your keys
The battery runs outP. 508If the battery is discharged
The doors cannot be lockedP. 4 7Doors
The horn begins to soundP. 9 9Alarm
The vehicle is stuck in mud
or sandP. 515If the vehicle becomes stuck
