464 4-3. Do-it-yourself maintenance
Remove the light bulb.
■ Auxiliary lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP3
STEP1
STEP2

527
6-1. Specifications
6
Vehicle specifications
Light bulbs
A: D4S discharge bulbs
B: H11 halogen bulbs
C: HB3 halogen bulbs
D: Wedge base bulbs (amber)
E: Wedge base bulbs (clear)
F: Double end bulbs
Light BulbsBulb No.WTy p e
Exterior
Headlights
Low beam (discharge bulbs)
Low beam (halogen bulbs)
High beam D4S
H11
HB3 35
55
60A
B
C
Fog lights H11 55 B
Auxiliary light W5W 5 E
Front turn signal/parking
lights 3457NA 28/8 D
Front side marker lights W5W 5 E
Rear turn signal lights 7440A 21 D
Stop lights 7440 21 E
Rear side marker lights W5W 5 E
Back-up lights 921 16 E
License plate lights W5W 5 E
Interior Interior light W5W 5 E
Personal lights W5W 5 E
Vanity lights 7065 1.4 F
Glove box light 74 1.2 E
Door courtesy lights 168 5 E
Trunk light 2825 4.8 E

569
Alphabetical index
Alphabetical index
A/C ............................................ 228
ABS........................................... 207
Air conditioning systemAir conditioning filter ............. 437
Automatic air conditioning
system................................ 228
Steering switches ................. 236
Airbags Airbag operating conditions .. 109
Airbag precautions for your child.................................... 113
Airbag warning light .............. 481
Curtain shield airbag precautions ........................ 116
Front passenger occupant classification system .......... 119
General airbag precautions .. 113
Locations of airbags ............. 106
Modification and disposal of airbags ............................... 118
Side airbag precautions........ 113
Side and curtain shield airbags operating conditions ........... 109
SRS airbags ......................... 106
Alarm .......................................... 99
Antenna .................................... 248
Anti-lock brake system ........... 207
Armrest .................................... 365
Ashtrays ................................... 360
Audio input .............................. 285
Audio system
Antenna ................................ 248
Audio input ........................... 285
AUX port ............................... 285
CD player/changer ............... 251
iPod ...................................... 267
MP3/WMA disc ..................... 259
Optimal use .......................... 282
Portable music player ........... 285
Radio .................................... 243
Steering wheel audio switches ............................. 286
USB memory ........................ 274 Automatic headlight leveling
system ....................................181
Automatic light control system ....................................178
Automatic transmission Automatic transmission .........161
If the shift lever cannot be shifted from P......................503
S mode ..................................163
AUX port ...................................285
Back-up lights
Wattage .................................527
Battery Checking ...............................417
If the vehicle battery is
discharged ..........................508
Preparing and checking
before winter .......................219
Bluetooth
® audio......................289
Bluetooth® phone ....................308
Brake Fluid ......................................414
Parking brake ........................167
Brake assist ..............................207
Break-in tips .............................144
Care Exterior ..................................386
Interior ...................................389
Seat belts ..............................390
Cargo capacity .........................212
CD player/changer ...................251
Chains .......................................221
Child-protectors .........................49
A
B
C

580
GAS STATION INFORMATION
Auxiliary catch leverP. 403Trunk openerP. 5 4Fuel filler door P. 9 2
Hood lock release lever
P. 403Fuel filler door opener
P. 9 2Tire inflation pressureP. 5 2 6
Fuel tank capacity
(Reference)18.5 gal. (70 L, 15.4 lmp.gal.)
Fuel typeUnleaded gasoline only P. 92, 522
Cold tire inflation
pressureP. 5 2 6
Engine oil capacity
(Drain and refill —
reference)qt. (L, Imp.qt.)
With filter 6.4 (6.1, 5.4)
Without filter 6.0 (5.7, 5.0)
Engine oil type“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil P. 522
