2012 Seat Exeo ST Owner's manual

3R9012003CE
Inglés 3R9012003CE (07.12) (GT9)
EXEO ST
Owner ’s manual
EXEO ST Inglés (07.12)

SEAT S.A. se preocupa constantemente por mantener todos sus tipos y mode\�los en un desarrollo continuo. Por ello le rogamos que com-
prenda que, en cualquier momento, puedan producirse modificaciones del v\�ehículo entregado en cuanto a la forma, el equipamiento y
la técnica. Por esta razón, no se puede derivar derecho alguno bas\�ándose en los datos, las ilustraciones y descripciones del presente
Manual.
Los textos, las ilustraciones y las normas de este manual se basan en el\� estado de la información en el momento de la realización de la
impresión. Salvo error u omisión, la información recogida en el\� presente manual es válida en la fecha de cierre de su edición.
No está permitida la reimpresión, la reproducción o la traducci\�ón, total o parcial, sin la autorización escrita de SEAT.
SEAT se reserva expresamente todos los derechos según la ley sobre el\� “Copyright”. Reservados todos los derechos sobre modificación.
❀Este papel está fabricado con celulosa blanqueada sin cloro.
© SEAT S.A. - Reimpresión: 15.07.12

Foreword
This Instruction Manual and its corresponding supplements should be read carefully to familiarise yourself
with your vehicle.
Besides the regular care and maintenance of the vehicle, its correct handling will help preserve its value.
For safety reasons, note the information concerning accessories, modifications and part replacements.
If selling the vehicle, give all of the onboard documentation to the new owner, as it should be kept with the
vehicle.

Table of Contents
Manual structure . . . . . . . . . . . . . . . . . . . . 5
Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Brief introduction . . . . . . . . . . . . . . . . . . . . . . . . . 7
Proper sitting position for occupants . . . . . . . . . 10
Pedal area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Storing objects . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Brief introduction . . . . . . . . . . . . . . . . . . . . . . . . . 19
Why wear seat belts? . . . . . . . . . . . . . . . . . . . . . . 20
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . 28
Airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Brief introduction . . . . . . . . . . . . . . . . . . . . . . . . . 29
Front airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Knee airbag* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Side airbags* . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Curtain airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Deactivating airbags . . . . . . . . . . . . . . . . . . . . . . . 45
Child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Brief introduction . . . . . . . . . . . . . . . . . . . . . . . . . 47
Child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Securing child seats . . . . . . . . . . . . . . . . . . . . . . . 52 Operating Instructions
. . . . . . . . . . . . . 59
Cockpit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Warning and indicator lamps . . . . . . . . . . . . . . . . 67
Driver information system . . . . . . . . . . . . . . . . . . 74
Auto-check system . . . . . . . . . . . . . . . . . . . . . . . . 78
Speed warning*  . . . . . . . . . . . . . . . . . . . . . . . . 85
Onboard computer . . . . . . . . . . . . . . . . . . . . . . . . 88
Menu display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Tyre pressure monitoring* . . . . . . . . . . . . . . . . . . 92
Steering wheel controls . . . . . . . . . . . . . . . . . . . . 94
Multifunction steering wheel* . . . . . . . . . . . . . . . 94
Unlocking and locking . . . . . . . . . . . . . . . . . . . . . 99
Remote control keys . . . . . . . . . . . . . . . . . . . . . . . 99
Central locking . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Childproof lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Remote control key . . . . . . . . . . . . . . . . . . . . . . . . 108
Anti-theft alarm system* . . . . . . . . . . . . . . . . . . . 110
Electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Sliding/tilting sunroof* . . . . . . . . . . . . . . . . . . . . 114
Lights and visibility . . . . . . . . . . . . . . . . . . . . . . . . 117
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Visibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Windscreen wipers . . . . . . . . . . . . . . . . . . . . . . . . 129
Rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Seats and storage compartments . . . . . . . . . . 135
Manual adjustment of the front seats . . . . . . . . . 135
Electric adjustment of front seats* . . . . . . . . . . . 137
Lumbar support* . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Driver seat memory* . . . . . . . . . . . . . . . . . . . . . . . 139 Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Armrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Luggage compartment . . . . . . . . . . . . . . . . . . . . . 144
Roof rack / roof rails* . . . . . . . . . . . . . . . . . . . . . . 152
Drink holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Ashtray*, cigarette lighter* and electric sockets* . .154
Compartments . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
2C-Climatronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Ignition lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Starting and stopping the engine . . . . . . . . . . . . 174
Start-Stop function* . . . . . . . . . . . . . . . . . . . . . . . 176
Handbrake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Parking aid acoustic system . . . . . . . . . . . . . . . . . 181
Cruise speed* (Cruise control system) . . . . . . . . 183
Manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Automatic gearbox* . . . . . . . . . . . . . . . . . . . . . . . 187
Practical Tips . . . . . . . . . . . . . . . . . . . . . . . . . 195
Intelligent technology . . . . . . . . . . . . . . . . . . . . . 195
Electronic Stability Control (ESC) . . . . . . . . . . . . . 195
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Power steering . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Servotronic* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Driving and the environment . . . . . . . . . . . . . . . 201
Running-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Exhaust gas purification system . . . . . . . . . . . . . 202
Economical and environmentally friendly driving 203
Driving abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
3
Table of Contents

Trailer towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Trailer towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Removable towing bracket . . . . . . . . . . . . . . . . . . 209
Vehicle maintenance and cleaning . . . . . . . . . 216
General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Care of the vehicle exterior . . . . . . . . . . . . . . . . . . 217
Vehicle interior maintenance . . . . . . . . . . . . . . . . 222
Accessories, replacement of parts and
modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Accessories and spare parts . . . . . . . . . . . . . . . . 228
Technical modifications . . . . . . . . . . . . . . . . . . . . 228
Mobile phones and two-way radios . . . . . . . . . . . 229
Athermic windscreen* . . . . . . . . . . . . . . . . . . . . . 229
Checking and refilling levels . . . . . . . . . . . . . . . 230
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
Diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Cooling system . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Washer fluid and windscreen wiper blades . . . . 241
Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
Vehicle battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Wheels and tyres . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
If and when . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Tools, tyre repair kit and spare wheel . . . . . . . . . 259
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . 262
Tyre repair* (Tyre-Mobility-System) . . . . . . . . . . . 266
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Changing bulbs. Halogen headlights . . . . . . . . . 273
Changing bulbs. Bi-Xenon AFS headlights . . . . . 279
Changing tail light bulbs (on side panel) . . . . . . 283
Changing tail light bulbs (on rear lid) . . . . . . . . . 288
Side turn signals . . . . . . . . . . . . . . . . . . . . . . . . . . 291 Luggage compartment lights . . . . . . . . . . . . . . . . 292
Registration light . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Sun visor light . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Jump-starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Towing and tow-starting . . . . . . . . . . . . . . . . . . . . 297
Technical Specifications . . . . . . . . . . . 300
Description of specifications . . . . . . . . . . . . . . . 300
Important information . . . . . . . . . . . . . . . . . . . . . 300
Information on fuel consumption . . . . . . . . . . . . 302
Towing a trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Technical specifications . . . . . . . . . . . . . . . . . . . . 304
Engine specifications . . . . . . . . . . . . . . . . . . . . . . 304
Dimensions and capacities . . . . . . . . . . . . . . . . . 312
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
4Table of Contents

5
Manual structure
Manual structure
What you should know before reading this manual This manual contains a description of the equipment supplied with the ve-
hicle at the time of press. Some of the equipment hereunder described will
not be available until a later date, or is only available in certain markets.
As this is a general manual for the EXEO ST, some of the equipment and
functions described in this manual are not included in all types or versions
of the model. These may vary or be modified depending on technical and
market requirements, which can in no way be interpreted as deceptive ad-
vertising.
The illustrations are intended as a general guide and may vary from the
equipment fitted in your vehicle in some details.
The direction indications (left, right, front, rear) appearing in this manual re-
fer to the normal forward working direction of the vehicle except when oth-
erwise indicated.
The equipment marked with an asterisk ** is fitted as standard only in cer-
tain versions, and is only supplied as optional extras for some versions, or
are only offered in certain countries.
All registered marks are indicated with ®. Although the copyright sym-
bol does not appear, it is a copyrighted mark.
The section is continued on the following page.
Marks the end of a section .
WARNING
Texts preceded by this symbol contain information on safety. They warn
you about possible dangers of accident or injury.
®


CAUTION
Texts with this symbol draw your attention to potential sources of damage
to your vehicle.
For the sake of the environment
Texts preceded by this symbol contain relevant information concerning envi-
ronmental protection.
Note
Texts preceded by this symbol contain additional information. 

6Content
Content
This manual is structured to provide the information you need in an organ-
ised way. The content of this Manual is divided into sections which belong
to chapters (e.g. “Air conditioning”). The entire manual is divided into five
large parts which are:
1. Safety First Information on the vehicle equipment relating to passive safety such as
seat belts, airbags, seats, etc.
2. Operating instructions
Information about the distribution of controls in the driver position of your
vehicle, about the seat adjustment possibilities, about how to create a suit-
able climate in the passenger compartment, etc.
3. Practical Tips
Advice relating to the driving, caring and maintenance of your vehicle and
certain problems you can solve yourself.
4. Technical specifications
Figures, values and the dimensions of your vehicle.
5. Alphabetic index
At the end of this manual there is a detailed alphabetical index, this will
help you to rapidly find the information you require. 
