2012 Peugeot 207 CC Owner's Manual

i
!
!
7
FAMILIARISATION
OPENING

Retractable roof operation


Opening the roof


)
Pull this control until the roof
is fully open.

Closing the roof


)
Press this control until the
roof is fully closed.
Do not release the roof control
during operation of the roof.
However, in the event of danger,
release the control, the roof stops;
then, when the danger is no lon-
ger present, complete the required
operation.
If the operation has not completely
fi nished, you will be warned by an
audible signal and a message on
the multifunction screen. These will
be repeated as the vehicle passes
a number of speed thresholds.
Changing to "cabriolet"
confi guration:


- the four windows lower,

- the boot opens,

- the roof folds into the boot,

- the boot closes.

If you continue to pull or press this
control after the end of the opera-
tion, the four windows rise.
The electric window controls and
the control for the four windows
are deactivated during operation
of the roof.
The roof electronic control unit may
interrupt the operation in progress
as a precaution (for example: door
movement and roof operation in
quick succession). In this case,
release the control then operate
it again to complete the required
operation.

Operating fault
If a malfunction of the roof occurs,
apply the parking brake, switch
off the ignition, restart the engine,
then start the required operation
again.
If the problem persists, contact a
PEUGEOT dealer.
Changing to "coupé" confi guration:


- the four windows lower,

- the boot opens,

- the roof opens out and locks auto-
matically,

- the boot closes. The end of the operation is confi rmed
by an audible signal and a message on
the multifunction screen.
The end of the operation is confi rmed
by an audible signal and a message on
the multifunction screen.

8
FAMILIARISATION
INTERIOR

Dual-zone digital air
conditioning
This system allows different levels of
comfort to be set for the driver and the
front passenger. It then automatically
controls these levels according to the
ambient conditions.



50



Automatic gearbox

This system provides perfect driving
pleasure by combining a fully automatic
mode, associated with two special pro-
grammes, and a manual mode.



107



Audio and communication
systems
These systems benefi t from the latest
technology: MP3 compatible Peugeot
Connect Sound (RD5), Peugeot Con-
nect USB, Bluetooth hands-free system,
Peugeot Connect Navigation (RNEG)
with 16/9 colour screen, JBL audio sys-
tem, auxiliary sockets.

Peugeot Connect Navigation (RNEG)




157

Peugeot Connect Sound (RD5)




189

Peugeot Connect USB




196


Electric windows

On the driver's side, control of
the electric window is automatic
when opening and when closing.



71

9
FAMILIARISATION
INSTRUMENTS AND CONTROLS



1.
Cruise control/speed limiter
switches.

2.
Steering wheel adjustment control.

3.
Lighting and direction indicator
control stalk.

4.
Instrument panel.

5.
Driver's airbag.
Horn.

6.
Gear lever.

7.
Parking brake.

8.
Retractable roof control.
Control for the four windows.

9.
Bonnet release lever.

10.
Door mirror controls.
Electric window controls.

11 .
Fusebox.

12.
Headlamp height adjustment.

13.
Side adjustable air vent.

14.
Door window demisting vent.

15.
Speaker (medium tweeter).

16.
Windscreen demisting vent.

10
FAMILIARISATION
INSTRUMENTS AND CONTROLS



1.
Steering lock and ignition.

2.
Audio equipment steering mounted
controls.

3.
Wiper/wash-wipe/trip computer
control stalk.

4.
Hazard warning lamps switch.

5.
Multifunction screen.
Seat belt fastening status warning
lamps.

6.
Sunshine sensor.

7.
Passenger's airbag.

8.
Glove box/Passenger's airbag
deactivation/Audio/video sockets.

9.
Heated seat control.

10.
12 V accessories socket.

11 .
USB port.

12.
Dynamic stability control
(ESP/ASR) button.
Central locking button.
Alarm button.

13.
Heating/air conditioning controls.

14.
Storage compartment.

15.
Audio and telematics system.

16.
Central adjustable air vents.

i
!
11
FAMILIARISATION
SITTING COMFORTABLY

Also...

5.
Access to the rear seats.

6.
Heated seat.



Front seat adjustment
Steering wheel adjustment



1.
Forwards-backwards adjustment.

2.
Height adjustment.

3.
Seat back angle adjustment.

4.
Head restraint height adjustment.



52

1.
Unlocking the control.

2.
Adjustment for height and reach.

3.
Locking the control.
As a safety precaution, these opera-
tions must only be carried out while
stationary.



54

i
12
FAMILIARISATION
SITTING COMFORTABLY

Door mirror adjustment


A.
Selecting the mirror.

B.
Adjusting the position of the mirror.

C.
De-selecting the mirror.



55

Also...

D.
Folding/Unfolding.



Rear view mirror adjustment



1.
Selecting the "day" position of the
mirror.

2.
Adjusting the mirror.



56



Front seat belts



A.
Installing the strap.

B.
Fastening the buckle.

C.
Checking the fastening by pulling
the strap.



98

i
13
FAMILIARISATION
SEEING CLEARLY

Lighting
Wipers


Ring B



81

Front and rear foglamps.
Ring A

Stalk A: windscreen wipers

2.
Fast wipe.

1.
Normal wipe.

I.
Intermittent wipe.

0.
Park.

È
Single wipe.
Screenwash: pull the stalk towards
you.



84 Lighting off.
Automatic illumination of head-
lamps.
Sidelamps.
Dipped/main beam headlamps.



80

Automatic wiping is not currently
available on the 207CC.

–
14
FAMILIARISATION
VENTILATION

Advice on interior settings


Digital air conditioning
: use of the fully automatic mode by pressing the "AUTO"
button is recommended.

I require...



Heating or Manual air conditioning




Air distribution



Air fl ow



Air recirculation/


Exterior air intake



Temperature



Manual A/C




HEAT





COOL





DEMISTING

DEFROSTING
