2012 MINI Countryman Owner's Manual

MOBILITYIndicator and warning lamps
176
Display in Canadian models
The driving stability control systems,
including ABS and the Flat Tire Moni-
tor or the Tire Pressure Monitor, have
failed, refer also to page65Reduced braking and driving stability.
Drive cautiously and think well ahead.
Avoid braking with full force, driving
on rough tracks, and depressing the
accelerator pedal to full throttle or
kickdown position. Have the system
checked immediately.
Display in Canadian models
The driving stability control systems,
including ABS, ALL4 all-wheel drive,
and the Flat Tire Monitor or the Tire
Pressure Monitor, have failed, refer
also to page 65 Drive cautiously and think well ahead.
Avoid braking with full force, driving
on rough tracks, and depressing the
accelerator pedal to full throttle or
kickdown position. Have the system
checked immediately.
ALL4 all-wheel drive has failed. Con tinued driving is possible. Drive
cautiously and thin k well ahead. Avoid
rough track driving, full-throttle oper-
ation, and use of the transmission's
kickdown mode. Have the system
checked immediately.
ALL4 all-wheel drive and DSC have
failed. Continued driving is possible. Drive
cautiously and thin
k well ahead. Avoid
rough track driving, full-throttle oper-
ation, and use of the transmission's
kickdown mode. Have the system
checked immediately.
12Cause What to do
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG

Indicator and warning lampsMOBILITY
177
Vehicles with Flat Tire Monitor
Light up in yellow and red:
>Tire damage Carefully bring the car to a stop.
Observe the information starting on
page
68.
> Flat Tire Monitor not initialized Initialize Flat Tire Monitor, page
68.
Light up in yellow:
Flat Tire Monitor failed. Punctures are
not indicated Have the system checked.
Vehicles with Tire Pressure Monitor
Light up in yellow and red:
There is a flat tire or significant tire
pressure loss, e.g. in the front right
tire Carefully bring the car to a stop.
Observe the information starting on
page
70.
Vehicles with Tire Pressure Monitor
Light up in yellow:
Tire Pressure Monitor not initialized Check the inflation pressure and reset
the system, page
71.
The small lamp flashes yellow and
then stays on, the large lamp lights
up in yellow:
> Wheel mounted without TPM
electronics Have the system checked.
> The TPM is temporarily malfunc-
tioning due to other systems or
devices using the same radio fre-
quency.
12Cause What to do
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG

MOBILITYIndicator and warning lamps
178
Vehicles with Tire Pressure Monitor
The small lamp flashes yellow and
then stays on, the large lamp lights
up in yellow:
>Tire Pressure Monitor failed.
Punctures are not indicated Have the system checked.
> Wheel mounted without TPM
electronics Have the system checked.
Lights up in red:
> Transmission limp-home pro-
gram active with restricted range
of gears, possibly with reduced
acceleration You can continue your journey, but
moderate your speed and exercise
due caution. Have the system
checked without delay.
> Gears can be engaged without
depressing the brake Always depress the brake to engage a
gear.
> Automatic selector lever locked Manually releasing the selector lever
lock, page49.
Lights up in yellow: Have the system checked as soon as
possible.
> Automatic selector lever locked:
Selector lever locked in position P
with engine running and brake
depressed or Manually releasing the selector lever
lock, page
49.
> Brake signal malfunctioning: gear
can be engaged without depress-
ing the brake To engage a gear while the vehicle is
at a standstill, always depress the
brake. Before leaving the vehicle,
move the selector lever to position P
and switch off the engine.
12Cause What to do
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG

Indicator and warning lampsMOBILITY
179
Lights up in red:
Transmission overheating Bring the car to a stop and move the
selector lever to position P. Allow the
transmission to cool down. You can
continue your journey, but moderate
your speed and exercise due caution.
Have the system checked if the situa-
tion reoccurs.
Lights up in yellow:
Transmission too hot Avoid high engine loads. You can con- tinue your journey, but moderate
your speed and exercise due caution.
Selector lever position P not engaged.
Vehicle not prevented from rolling
Selector lever position P not engaged.
Ignition cannot be switched off Engage selector lever position P when
you wish to switch off the ignition,
page
45.
Cruise control system fail edHave the system checked.
Park Distance Control fail edHave the system checked.
Bulb of exterior lighting system failed Have the exterior lighting checked as
soon as possible.
Low-beam headlamp or fog lamp
failed Have the lamps checked as soon as
possible.
High-beam headlamp failed Have the high-beam headlamps
checked.
Rear fog lamp failed Have the rear fog lamp checked.
12Cause What to do
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG

MOBILITYIndicator and warning lamps
180
Adaptive Light Control has failed
Coolant level too lowAdd coolant immediately, page148.
Engine oil pressure too low Stop immediately and switch off the
engine. You cannot continue your
journey. Contact your MINI dealer.
Lights up in red:
Service appointment overdue Arrange a service appointment.
Check service requirements, page 61.
Lights up in yellow:
Service due Arrange a service appointment.
Check service requirements, page 61.
No service due
Set speed limit
exceeded
Time and date no longer correct Set the time and date, page 62.
12Cause What to do
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG

Indicator and warning lampsMOBILITY
181
Online Edition for Part no. 01 40 2 914 828 - \251 07/12 BMW AG
