2012 Lexus IS220d display

333
3-4. Using the hands-free phone system (for mobile phones)
3
Interior features
IS250/220d/200d_EE
Using the hands-free phone system for the first time
Before using the hands-free phone system, it is necessary to regis-
ter a mobile phone in the system. The system will enter phone reg-
istration mode automatically when starting the system with no
mobile phone registered. Follow the procedure below to register
(pair) a mobile phone:
Press the off-hook switch or the talk switch, and select “Pair
Phone” using , and .
Select “Record Name” using , and , and
say the name to be registered after the beep.
The name to be registered will be repeated aloud.
Select “Confirm” using , and .
A passkey will be displayed.
Input the passkey into the mobile phone.
Refer to the manual that comes with the mobile phone for the
operation of the phone.
If the mobile phone has a Bluetooth® audio player, the audio
player can be registered at the same time.
When “Pair Audio?” is displayed, select “Yes” or “No”
using , and . (Bluetooth
® audio player
P. 309)
STEP1
STEP2
STEP3
STEP4
STEP5

335
3-4. Using the hands-free phone system (for mobile phones)
3
Interior features
IS250/220d/200d_EE
“Setup”
“Security”
“Set PIN”Setting a PIN code
“Phbk Lock”Locking the phone book
“Phbk Unlock”Unlocking the phone book
“Phone
Setup”
“Pair Phone”Registering a mobile phone
“Select Phone”Selecting a mobile phone to
be used
“Change Name”Changing the registered
name of a mobile phone
“List Phones”Listing the registered mobile
phones
“Set Passkey”Changing the passkey
“Delete Phone”Deleting a registered mobile
phone
“System
Setup”
“Guidance Vol”Setting voice guidance vol-
ume
“Device Name”Displaying the Bluetooth®
device address and name
“Initialize”Initializing the system
First menuSecond
menuThird menuOperation detail

338
3-4. Using the hands-free phone system (for mobile phones)
IS250/220d/200d_EE
Dialing by inputting a name
Press the talk switch and say a registered name.
The desired name or number is displayed.
Dial by one of the following methods:
a. Press the off-hook switch.
b. Select “Dial” using , and .
In , if the pronounced name cannot be recognized, select
the desired name using
, and .
Speed dialing
Press the off-hook switch.
Press the preset button in which the desired number is regis-
tered.
Press the off-hook switch.
When receiving a phone call
Answering a phone call
Press the off-hook switch.
Refusing a phone call
Press the on-hook switch.
STEP1
STEP2
STEP1
STEP1
STEP2
STEP3

343
3-4. Using the hands-free phone system (for mobile phones)
3
Interior features
IS250/220d/200d_EE
Changing the passkey
Select “Set Passkey” using , and .
Select a 4 to 8-digit number using , and .
The number should be input 1 digit at a time.
When the entire number to be registered as a passkey has
been input, press again.
If the number to be registered has 8 digits, pressing is not
necessary.
Deleting a registered mobile phone
Select “Delete Phone” using , and .
Select the desired mobile phone to be deleted using ,
and .
If the mobile phone to be deleted is paired as a Bluetooth
® audio
player, the registration of the audio player can be deleted at the
same time.
When “Del Audio?” is displayed, select “Yes” or “No”
using , and . (Bluetooth
® audio player
P. 309)
The number of mobile phones that can be registered
Up to 6 mobile phones can be registered in the system.
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3

344
3-4. Using the hands-free phone system (for mobile phones)
IS250/220d/200d_EE
Security and system setup
To enter the menu of each setting, follow the steps below.
Security setting items and operation procedures
Press the off-hook switch and select “Setup” using ,
and .
Select “Security” using , and .
Select one of the following items using , and
:
Setting or changing the PIN (Personal Identification Num-
ber)
“Set PIN”
Locking the phone book
“Phbk Lock”
Unlocking the phone book
“Phbk Unlock”
System setup items and operation procedures
Press the off-hook switch and select “Setup” using ,
and .
Select “System Setup” using , and .
Select one of the following items using , and
:
Setting voice guidance volume
“Guidance Vol”
Displaying the Bluetooth
® device address and name
“Device Name”
Initializing the system
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3

346
3-4. Using the hands-free phone system (for mobile phones)
IS250/220d/200d_EE
Displaying the Bluetooth® device address and name
Select “Device Name” using , and .
Press or to display the Bluetooth
® device
address and name.
Select “Go Back” using , and to return to
“System Setup”.
Initializing the system
Select “Initialize” and then “Confirm” using ,
and .
Select “Confirm” again using , and .
STEP1
STEP2
STEP3
STEP1
STEP2

349
3-4. Using the hands-free phone system (for mobile phones)
3
Interior features
IS250/220d/200d_EEAdding procedure
Select “Add Entry” using , and .
Use one of the following methods to input a telephone num-
ber:
Transferring data from the mobile phone:
STEP2-1Select “By Phone” and then “Confirm” using
, and .
STEP2-2When “Transfer” appears in the display, transfer
the data from the mobile phone.
Refer to the manual that comes with the mobile phone
for details on transferring data.
STEP2-3Select the desired data using , and
.
Inputting a phone number using , and :
STEP2-1Select “Manual Input” using , and
.
STEP2-2Input a phone number using , and
, and press again.
Input the phone number 1 digit at a time.
Selecting a phone number from the outgoing or incoming call his-
tory:
STEP2-1Select “Call History” using , and
.
STEP2-2Select “Outgoing” or “Incoming” using ,
and .
STEP2-3Select the desired data using , and
.
Select “Record Name” using , and , and
say the desired name after the beep.
STEP1
STEP2
STEP3

364
3-7. Other interior features
IS250/220d/200d_EE
Clock
The clock is displayed when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
Adjusts the hour.
Adjusts the minutes.
Rounds to the nearest
hour.
*
*: e.g. 1:00 to 1:29 1:00
1:30 to 1:592:00
