2012 Lexus IS F Specifications / 2012 ISF OWNERS MANUAL QUICK GUIDE (OM53A51U)

65
Door Locks
■Locking the vehicle from inside
Inside lock button
Locks
Unlocks
Door lock switch
Operates all door locks.
Locks
Unlocks
■ Locking the vehicle from outside
Use the entry function or wireless remote control (  P. 7 , 8 )
■Rear door child-protector lock
Pushing down the switch prevents the rear doors
from being opened from the inside.
Always set the child protector locks when chil-
dren are seated in the rear seat.
1
2
1
2

66
Powe r Wi n d ows
Powe r w i n d ow s w i t c h e sTo o p e n : press the switch.
To c l o s e : pull the switch up.
Fully pulling up and releasing the switches
causes the windows to close fully. Fully
pressing down and releasing the switches
causes the windows to open fully.
Window lock switch The window lock switch disables the opera-
tion of passenger window switches.
Moon Roof (If Equipped)
■Opening and closing
Open
The moon roof stops slightly before the fully
opened position.
To fully open, press the switch again.
Close
■Tilting up and down
Tilt up
Tilt down
1
2
1
2
1
2

67
Fuel Tank Cap
Press the fuel filler door opener.
Slowly remove the cap by turning it counter-
clockwise.
After the cap is removed, it can be hung on the
inside of the fuel filler door.

68
Tr u n k
Trunk opener
To open the trunk from inside the cabin, simply
press the trunk opener.
To disable the trunk opener, turn off the main
switch in the glove box.
On
Off
When the trunk opener is disabled, the trunk can-
not be opened using the wireless remote control
or the entry function.
Entry function and wireless remote control ( P. 7 , 8 )
1
2

What to do if ...
69
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
(Canada)Brake system warning light
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
(Canada)Malfunction
indicator lamp
Electric power steering
system warning light
Pre-collision system
warning light*1
SRS warning light
(Blinking and
then continu-
ously on)Tire pressure warning light
(U.S.A.)
(Canada)ABS warning light
(Comes on)
Slip indicator
Follow the correction procedures.
Open door warning light
(On the cen-ter panel)
Front passenger’s seat belt
reminder light
Low fuel level warning light
(Illuminates without
blinking)Tire pressure warning light*2
(On the
instrument
cluster)Driver’s seat belt
reminder light
Master warning light
For further information, re fer to the Owner's Manual.

70
*1
: If equipped
*2: Turns on due to natural causes such as natura
l air leaks or tire inflation pressure changes
caused by temperature excluding the spare tire . Adjust the tire inflation pressure to the
specified level. The light will turn off after a fe w minutes. In case the light does not turn off
even if the tire inflation pressure is adju sted, have the system checked by your Lexus
dealer.
See the Owner's Manual
Tu r n s i g n a l i n d i c a t o rIntuitive parking assist
indicator
*1
Headlight high beam indicator
(Flashes)
Slip indicator
Headlight indicator (U.S.A.)VSC off indicator
Tail light indicator (Canada)“TRAC OFF” indicator
Front fog light indicatorSRS airbag on-off indicator
“SNOW” indicatorShift range display
“SPORT” indicatorGear position display
Cruise control indicator
For further information, re fer to the Owner's Manual.

What to do if ...
71
If the electronic key does not operate
properly
■Unlocking and locking the doors
To unlock or lock the vehicle, use the mechanical
key to remove the lock cover on the driver's door
handle. The mechanical ke y is stored inside the
electronic key.
Unlocks
Locks
■Starting the engine
Depress the brake pedal.
Touch the Lexus emblem side of the electronic
key to the “ENGINE START STOP” switch.
Press the “ENGINE START STOP” switch
within 10 seconds of the buzzer, keeping the
brake pedal depressed.
To change “ENGINE START STOP” switch
modes, release the brake pedal and press the
“ENGINE START STOP” switch within 10 sec-
onds of the buzzer.
1
2
If the electronic key battery becomes depleted , replace it with a new battery. For instruc-
tions on replacing the ba ttery, refer to the Owner's Manual. If you need further assistance,
contact your Lexus dealer.

72
If the engine doesn't start
Make sure that the correct operating procedures have been followed.Make sure that the brake pedal is firmly
depressed when attempting to start the engine.
( P.1 2 )
Make sure that the steering wheel lock is
released.
To release it, press the “ENGINE START STOP”
switch while gently turn ing the wheel left and
right. ( P.9 )
Brake pedal
Steering wheel lock
If the engine still does not st art, see the Owner's Manual fo r more information or contact
your Lexus dealer.
