2012 Lexus GS350 navigation

7
1
8 7
6
5
4
3
2
GS350/250_EE (OM30C36E)
8-1. Specifications
Maintenance data (fuel, oil
level, etc.)...........................836
Fuel information................ 853
8-2. Customization
Customizable features ....... 855
8-3. Items to initialize
Items to initialize............... 866
What to do if... (Troubleshoot-
ing)...................................868
Alphabetical index ............ 876
8Vehicle specifications
Index
For vehicles with a navigation system, refer to the “Navigation
System Owner’s Manual” for information regarding the naviga-
ti t

21Pictorial index
GS350/250_EE (OM30C36E)
Seat heater switches*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 631
Seat ventilator switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 632
Lexus parking assist-sensor switch
*2. . . . . . . . . . . . . . . . . . . . P. 284
Rear sunshade switch
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 636
Driving mode select switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 326
Snow mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
*1: Refer to “Navigation System Owner’s Manual”.
*2: If equipped
1
2
3
4
5
6

29Pictorial index
GS350/250_EE (OM30C36E)
Rear sunshade switch*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 636
Lexus parking assist-sensor switch
*2. . . . . . . . . . . . . . . . . . . . P. 284
Seat heater switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 631
Seat ventilator switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 632
Driving mode select switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 326
Snow mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
*1: Refer to “Navigation System Owner’s Manual”.
*2: If equipped
1
2
3
4
5
6

1132. Instrument cluster
2
Instrument cluster
GS350/250_EE (OM30C36E)
Vehicle speed
Tachometer
Shift position and shift range
Displays the selected shift position or selected shift range (P. 214)

Eco Driving Indicator (P. 109)
Audio display
Displays audio information for approximately 3 seconds when the audio
system is operated

Route guidance display (vehicles with navigation system)
(P. 116)
When approaching an intersection while the navigation system is giving
route guidance, an arrow will automatically be displayed to indicate the
direction of travel.

Lane departure warning display (LKA [Lane-Keeping Assist])
(if equipped) (P. 767)
Approach warning display (dynamic radar cruise control) (if
equipped)
(P. 767)
Pre-crash braking warning message (pre-crash safety system)
(if equipped) (P. 767)
Head-up display contents

1162. Instrument cluster
GS350/250_EE (OM30C36E)When the vehicle approaches an
intersection, the direction the
vehicle should go is guided by
the arrow.
When the vehicle approaches an
intersection, the route guidance
will start and the distance
* to the
intersection will also be dis-
played.
*: The distance decreases in incre-
ments of 50 m (164 ft.) and the dis-
tance indication will disappear
when the vehicle passes through
the intersection.
The following display can be shown or hidden.
Audio display
Route guidance display (vehi-
cles with navigation system)
Route guidance display (vehicles with navigation system)
Display customization
1
2

3685-1. Remote Touch screen
GS350/250_EE (OM30C36E)
Remote Touch
“•” button
Press this button to change map scale and scroll through lists.
“HOME” button
Press this button to display the home screen.
Remote Touch knob
Use this knob to move the cursor and select items on the screen.
Feedback force, pointer sound volume, on or off of selection sounds etc.
can be changed.
“MENU” button
Press this button to display the “Menu” screen.
The Remote Touch can be used to operate the Remote Touch
screens.
Owners of models equipped with a navigation system should refer
to the “Navigation System Owner’s Manual”.
The illustration below is for left-hand drive vehicles without navi-
gation system.
The button positions may differ slightly for right-hand drive vehi-
cles.
1
2
3
4

3705-1. Remote Touch screen
GS350/250_EE (OM30C36E)
Remote Touch screen
By using the Remote Touch, you can control the audio system and
air conditioning system, and adjust the screen display etc.
Owners of models equipped with a navigation system should refer
to the “Navigation System Owner’s Manual”.
Vehicles with a 12.3-inch display: Different information can be
displayed on the left and right of the screen. The 8-inch display
area on the left of the screen is called the “Main Display”, and the
area to the right is called the “Side Display”. For details, refer to
the “Navigation System Owner’s Manual”.
“Menu” screen
Vehicles without navigation
systemVehicles with a 8-inch dis-
play navigation system
Vehicles with a 12.3-inch dis-
play navigation system

3715-1. Remote Touch screen
5
Interior features
GS350/250_EE (OM30C36E)If the engine switch is turned to
ACCESSORY or IGNITION
ON mode, the initial screen will
be displayed for a few seconds as
the system starts up.
Images shown on the initial screen
can be changed to suit individual
preferences. (P. 389)
SwitchPage
“Car”P. 3 7 8
“Info”Navigation System Owner’s Manual
“Setup”P. 3 8 2
“Navi”Navigation System Owner’s Manual
“Audio”P. 432, 467
“Climate”P. 4 0 9
“Telephone”P. 5 4 2
“Display”P. 3 7 2
Initial screen
