4 4-1. Before driving
Driving
GS350/250_EE (OM30C36E)
NOTICE
When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may
cause the following serious damage to the vehicle:
Engine stalling
Short in electrical components
Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be
sure to have any authorized Lexus dealer or repairer, or another duly quali-
fied and equipped professional check the following:
Brake function
Changes in quantity and quality of oil and fluid used for the engine, trans-
mission, transfer (AWD models), differential, etc.
Lubricant condition for the propeller shaft, bearings and suspension joints
(where possible), and the function of all joints, bearings, etc.

849
8 8-1. Specifications
Vehicle specifications
GS350/250_EE (OM30C36E)
Your Lexus vehicle is filled with “Toyota Genuine Differential Oil” at the
factory.
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equiva-
lent of matching quality to satisfy the above specification. Please contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional for further details.
*: Minimum pedal clearance when depressed with a force of 500 N (51.0
kgf, 112.4 lbf) while the engine is operating.
Front differential (AWD models)
Oil capacity 0.70 L (0.74 qt., 0.62 Imp.qt.)
Oil type and viscosity
Hypoid gear oil API GL-5
Above -18C (0F): SAE90
Below -18C (0F): SAE80W or SAE80W-90
Rear differential
Oil capacityGS2501.15 L (1.22 qt., 1.01 Imp.qt.)
GS3501.35 L (1.43 qt., 1.19 Imp.qt.)
Oil type and viscosity
Toyota Genuine Differential gear oil
LT
75W-85 GL-5 or equivalent
Brakes
Pedal
clearance
*
2WD115 mm (4.5 in.) Min.
AW D126 mm (5.0 in.) Min.
Pedal free play1.0 — 2.0 mm (0.04 — 0.08 in.)
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Steering
Free playLess than 30 mm (1.2 in.)
