847
8 8-1. Specifications
Vehicle specifications
GS350/250_EE (OM30C36E)
Cooling system
GS250
GS350Left-hand
drive vehiclesRight-hand
drive vehicles
Capacity
10.9 L (11.5
qt., 9.6
Imp.qt.)11.0 L (11.6
qt., 9.7
Imp.qt.)9.7 L (10.3 qt.,
8.5 Imp.qt.)
Coolant type
Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based
non-silicate, non-amine, non-nitrite, and
non-borate coolant with long-life hybrid
organic acid technology
Do not use plain water alone.
Ignition system
Spark plug
MakeDENSO FK20HBR11
Gap1.1 mm (0.043 in.)
NOTICE
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

868What to do if... (Troubleshooting)
GS350/250_EE (OM30C36E)
What to do if... (Troubleshooting)
If you lose your mechanical keys, new genuine mechani-
cal keys can be made by any authorized Lexus dealer or
repairer, or another duly qualified and equipped profes-
sional. (P. 120)
If you lose your electronic keys, the risk of vehicle theft
increases significantly. Contact any authorized Lexus
dealer or repairer, or another duly qualified and equipped
professional immediately. (P. 122)
Is the electronic key battery weak or depleted? (P. 697)
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. (P.
208)
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the
electronic key on your person.
The function may not operate properly due to the condi-
tion of the radio wave. (P. 130)
If you have a problem, check the following before contacting any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked

870What to do if... (Troubleshooting)
GS350/250_EE (OM30C36E)
Did you press the engine switch while firmly depressing
the brake pedal? (P. 207)
Is the shift lever in P? (P. 211)
Is the electronic key anywhere detectable inside the vehi-
cle?
(P. 126)
Is the steering wheel unlocked? (P. 212)
Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way.
(P. 823)
Is the battery discharged? (P. 825)
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the
brake pedal with the engine switch in IGNITION ON
mode
(P. 818)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal

871What to do if... (Troubleshooting)
GS350/250_EE (OM30C36E)
It is locked automatically to prevent theft of the vehicle.
(P. 211)
Is the window lock switch pressed?
The power window except for the one at the driver’s seat
cannot be operated if the window lock switch is pressed.
(P. 178)
The auto power off function will be operated if the vehi-
cle is left in ACCESSORY or IGNITION ON mode (the
engine is not running) for a period of time. (P. 211) The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is turned off automatically

872What to do if... (Troubleshooting)
GS350/250_EE (OM30C36E)
The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat
belts?
(P. 752)
The parking brake indicator is on
Is the parking brake released? (P. 225)
Depending on the situation, other types of warning buzzer
may also sound. (P. 749, 757)

Did anyone inside the vehicle open a door or anything
move inside the vehicle during setting the alarm?
The sensor detects them and the alarm sounds. (P. 86)
To stop the alarm, turn the engine switch to IGNITION ON
mode or start the engine. A warning buzzer sounds during driving
An alarm is activated and the horn sounds (if equipped)

880Alphabetical index
GS350/250_EE (OM30C36E)
Eco drive mode .........................328
Eco Driving Indicator ........109, 114
Electric Power Steering (EPS) ..334
Function ................................334
Warning light........................751
Warning message..................762
Electronic key............................118
Battery-saving function ........129
If the electronic key does not
operate properly .................822
Replacing the battery ............697
Emergency, in case of
If the battery is discharged ...825
If the electronic key does not
operate properly .................822
If the engine will not start.....816
If the parking brake cannot
be released ..........................819
If the shift lever cannot be
shifted from P .....................818
If the warning buzzer sounds749
If the warning light turns on .749
If the warning message is
displayed ............................757
If you have a flat tire ....783, 798
If you think something
is wrong ..............................747
If your vehicle becomes stuck ....
833
If your vehicle has to be
stopped in an emergency ....739
If your vehicle needs to
be towed .............................740
If your vehicle overheats ......830Emergency brake signal ........... 334
Emergency flashers .................. 738
Emergency tire puncture
repair kit ................................. 798
Engine....................................... 838
Accessory mode................... 208
Compartment ....................... 660
Engine switch ...................... 207
Hood .................................... 657
How to start the engine ........ 207
Identification number .......... 837
If the engine will not start .... 816
Ignition switch
(engine switch) .................. 207
Overheating ......................... 830
Engine compartment cover....... 661
Engine coolant .......................... 665
Capacity ............................... 847
Checking .............................. 665
Preparing and checking
before winter ..................... 359
Engine coolant temperature
gauge ........................................ 99
Engine immobilizer system ........ 80
Engine oil ................................. 662
Capacity ............................... 839
Checking .............................. 662
Oil level warning message... 766
Oil pressure warning
message ............................. 758
Preparing and checking
before winter ..................... 359
E

882Alphabetical index
GS350/250_EE (OM30C36E)
Gauges .........................................99
Glove box ..................................616
Glove box light ..........................616
Hands-free system
(for cellular phone) .................542
Head restraints ...........................168
Headlights .................................228
Adaptive Front-lighting
System (AFS) .....................230
Automatic High Beam
system.................................233
Discharge headlights
precautions .........................737
Follow me home system .......229
Headlight leveling warning
message ..............................760
Light switch ..........................228
Replacing light bulbs ............735
Wattage .................................853
Headlight cleaner.......................248
Head-up display ........................112
Heaters.......................................409
Air conditioning system .......409
Heated steering wheel...........629
Outside rear view mirrors .....430
Seat heaters ...........................631
Hill-start assist control ..............341Hood ......................................... 657
Open..................................... 657
Warning message................. 763
Hooks
Cargo hooks ......................... 621
Coat hooks ........................... 640
Retaining hooks (floor mat)... 34
Luggage hook ...................... 621
Utility hook .......................... 642
Horn .......................................... 228
Identification ............................ 837
Engine .................................. 837
Vehicle ................................. 837
Ignition switch (engine switch) 207
Illuminated entry system .......... 613
Immobilizer system .................... 80
Indicators .................................... 96
Initialization
Moon roof ............................ 183
Power windows.................... 179
Tire pressure warning
system................................ 675
Initiators (tire pressure warning
system) ................................... 688
Inside door handle lights .......... 611
Inside rear view mirror ............. 171
Instrument panel light control .. 100
Interior lights ............................ 611
Intrusion sensor and tilt sensor ... 89
ISOFIX rigid anchors ................. 69
G
H
I

888Alphabetical index
GS350/250_EE (OM30C36E)
Steering lock..............................211
Column lock release .............212
Steering lock system warning
message ..............................781
Steering wheel ...........................170
Adjustment ...........................170
Audio switches .....................543
Heated steering wheel...........629
Power easy access system ....166
Steering wheel position
memory ..............................162
Stop lights
Emergency brake signal .......334
Replacing light bulbs ............735
Storage feature...........................614
Stuck
If the vehicle becomes stuck.833
Sun visors ..................................624
Sun shade
Rear ......................................636
Rear door ..............................637
Roof ......................................182
Switches
AFS OFF switch ...................230
Audio remote control
switches ..............................543
Automatic High Beam switch ....
233
BSM (Blind spot monitor)
switch .................................354
Cruise control switch ............254
“DISP” button.......................104
Door lock switches ...............146
Driving mode select switch ..328Driving position memory
switches ............................. 162
Dynamic radar cruise control
switch ................................ 258
Emergency flashers switch .. 738
Engine switch ...................... 207
Fog light switch ................... 239
Headlight cleaner switch ..... 248
Heated steering wheel switch ....
629
HUD (Head-up display)
switches ............................. 112
Ignition switch ..................... 207
Lexus parking assist-sensor
switch ................................ 285
Light switches ...................... 228
LKA (Lane-Keeping Assist)
switch ................................ 276
Moon roof switches ............. 181
Outside rear view mirror
switches ............................. 174
Paddle shift switches ........... 218
PCS OFF switch .................. 344
Power door lock switch ....... 146
Power window switches ...... 178
Rear sunshade switch........... 636
Rear window and outside rear
view mirror defoggers
switch ................................ 430
Seat heater switches ............. 631
Seat ventilator switches ....... 632
Snow mode switch ............... 217
Talk switch .................. 402, 567
Telephone switches.............. 543
Tilt and telescopic steering
control switch .................... 170
