2012 Lexus CT200h CHILD RESTRAINT SYSTEM

1
2
3
4
5
6
3
CT200h_OM_OM76067E_(EE)
1-6. Refueling
Opening the fuel tank cap .. 131
1-7. Theft deterrent system
Immobilizer system ............ 135
Double locking system ....... 140
Alarm ................................. 142
1-8. Safety information
Correct driving posture ...... 149
SRS airbags ........................ 151
Airbag manual on-off
system .............................. 163
Child restraint systems ....... 166
Installing child restraints .... 176
2-1. Driving procedures
Driving the vehicle ............. 186
Power (ignition) switch ...... 198
EV drive mode ................... 204
Hybrid transmission ........... 207
Turn signal lever ................ 216
Parking brake ..................... 217
Horn ................................... 2182-2. Instrument cluster
Gauges and meters ............. 219
Indicators and warning
lights................................. 225
Multi-information display .. 229
2-3. Operating the lights and
windshield wipers
Headlight switch ................ 235
Fog light switch.................. 239
Windshield wipers and
washer .............................. 241
Rear window wiper and
washer .............................. 247
Headlight cleaner switch .... 249
2-4. Using other driving systems
Cruise control ..................... 250
Dynamic radar cruise
control .............................. 255
Lexus parking assist-sensor 273
Rear view monitor system.. 282
Driving assist systems ........ 291
Hill-start assist control ....... 296
PCS (Pre-Crash Safety
system) ............................. 299
2-5. Driving information
Cargo and luggage ............. 308
Winter driving tips ............. 311
Trailer towing..................... 315
2When driving

1Before driving
37
CT200h_OM_OM76067E_(EE)
1-1. Hybrid system
Hybrid system features ...... 38
Hybrid system
precautions ....................... 43
Energy monitor/consumption
screen ............................... 49
Hybrid vehicle driving tips 54
1-2. Key information
Keys ................................... 56
1-3. Opening, closing and
locking the doors
Smart entry & start system. 62
Push-button start system .... 79
Wireless remote control ..... 84
Side doors .......................... 89
Back door ........................... 93
1-4. Adjustable components
(seats, mirrors, steering
wheel)
Front seats .......................... 98
Rear seats ......................... 100
Driving position memory . 102
Head restraints ................. 105
Seat belts .......................... 108
Steering wheel.................. 115
Inside rear view mirror..... 116
Outside rear view mirrors 1181-5. Opening and closing the
windows and moon roof
Power windows................ 123
Moon roof ........................ 127
1-6. Refueling
Opening the fuel tank cap 131
1-7. Theft deterrent system
Immobilizer system ......... 135
Double locking system .... 140
Alarm ............................... 142
1-8. Safety information
Correct driving posture .... 149
SRS airbags...................... 151
Airbag manual on-off
system ............................ 163
Child restraint systems..... 166
Installing child restraints . 176

111
1-4. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CT200h_OM_OM76067E_(EE)
Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may
also lock if you lean forward too quickly. A slow, easy motion will allow the
belt to extend so that you can move around fully.
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. (P. 166)
When the child becomes large enough to properly wear the vehicle’s seat
belt, follow the instructions on P. 108 regarding seat belt usage.
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will acti-
vate for the first collision, but will not activate for the second or subsequent
collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact
any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional for seat belt replacement or installation.

112
1-4. Adjustable components (seats, mirrors, steering wheel)
CT200h_OM_OM76067E_(EE)
CAUTION
Observe the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failing to do so may cause death or serious injury.
Wearing a seat belt
Ensure that all passengers wear a seat belt.
Always wear a seat belt properly.
Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at once, including children.
Lexus recommends that children be seated in the rear seat and always use
a seat belt and/or an appropriate child restraint system.
To achieve a proper seating position, do not recline the seat more than
necessary. The seat belt is most effective when the occupants are sitting up
straight and well back in the seats.
Do not wear the shoulder belt under your arm.
Always wear your seat belt low and snug across your hips.

159
1-8. Safety information
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
SRS airbag precautions
The SRS front passenger airbag also deploys with considerable force, and
can cause death or serious injury especially if the front passenger is very
close to the airbag. The front passenger seat should be as far from the air-
bag as possible with the seatback adjusted, so the front passenger sits
upright.
Improperly seated and/or restrained infants and children can be killed or
seriously injured by a deploying airbag. An infant or child who is too
small to use a seat belt should be properly secured using a child restraint
system. Lexus strongly recommends that all infants and children be
placed in the rear seats of the vehicle and properly restrained. The rear
seats are safer for infants and children than the front passenger seat. (P.
166)
Do not sit on the edge of the seat or
lean against the dashboard.

163
1
1-8. Safety information
Before driving
CT200h_OM_OM76067E_(EE)
Airbag manual on-off system
This system deactivates the front passenger airbag, front passenger
knee
airbag and front passenger side airbag.
Only deactivate the airbags when using a child restraint system on the
front passenger seat.
“PASSENGER AIRBAG”
indicator
This indicator turns on when
the airbag system is on (only
when the “POWER” switch
is in ON mode).
Airbag manual on-off
switch

165
1-8. Safety information
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
When installing a child restraint system
For safety reasons, always install the child restraint system in a rear seat. In
the event that the rear seat cannot be used, the front seat can be used as long
as the airbag manual on-off system is set to off.
If the airbag manual on-off system is left on, the strong impact of the airbag
deployment (inflation) may cause serious injury or even death.
When a child restraint system is not installed on the front passenger seat
Ensure that the airbag manual on-off system is set to on.
If it is left off, the airbag may not deploy in the event of an accident, which
may result in serious injury or even death.

166
1-8. Safety information
CT200h_OM_OM76067E_(EE)
Child restraint systems
Points to remember
Studies have shown that installing a child restraint system on a rear
seat is much safer than installing one to the front passenger seat.
Choose a child restraint system that suits your vehicle and is
appropriate to the age and size of the child.
For installation details, follow the instructions provided with the
child restraint system.
General installation instructions are provided in this manual.
(P. 176)
If child restraint system regulations exist in the country where
you reside, please contact any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional for
the child restraint system installation.
Lexus recommends that you use a child restraint system which
conforms to the regulation ECE No.44.
Lexus strongly urges the use of child restraint systems.
