2012 JEEP GRAND CHEROKEE rear view mirror

MIRRORS
Inside Day/Night Mirror
A single ball joint mirror is provided in the
vehicle. It is a twist on mirror that has a fixed
position. The mirror head can be adjusted up,
down, left, and right for various drivers. The
mirror should be adjusted to center on the view
through the rear window.
Headlight glare from vehicles behind you can
be reduced by moving the small control under
the mirror to the night position (toward the rear
of the vehicle). The mirror should be adjusted
while set in the day position (toward the wind-
shield).
Automatic Dimming Mirror — If
Equipped
This mirror automatically adjusts for headlight
glare from vehicles behind you. You can turn
the feature on or off by pressing the button at
the base of the mirror. A light in the button will
illuminate to indicate when the dimming feature
is activated. The mirror is twisted on the wind-
shield button counterclockwise and requires no
tools for mounting.
CAUTION!
To avoid damage to the mirror during clean-
ing, never spray any cleaning solution directly
onto the mirror. Apply the solution onto a clean
cloth and wipe the mirror clean.
Outside MirrorsTo receive maximum benefit, adjust the outside
mirrors to center on the adjacent lane of traffic
with a slight overlap of the view obtained on the
inside mirror.
WARNING!
Vehicles and other objects seen in the pas-
senger side convex mirror will look smaller
and farther away than they really are. Relying
too much on your passenger side convex
mirror could cause you to collide with another
vehicle or other object. Use your inside mirror
when judging the size or distance of a vehicle
seen in the passenger side convex mirror.
Some vehicles will not have a convex passen-
ger side mirror.
Adjusting Rearview Mirror
Automatic Dimming Mirror
67

Illuminated Vanity MirrorsTo access an illuminated vanity mirror, flip down
one of the visors.
Lift the cover to reveal the mirror. The light will
turn on automatically.
Sun Visor Extension — If EquippedThis feature has a pull out extension on the sun
visor for increased coverage.
BLIND SPOT MONITORING — IF
EQUIPPED
The Blind Spot Monitoring (BSM) system uses
two radar-based sensors, located inside the
rear bumper fascia, to detect highway licens-
able vehicles (automobiles, trucks, motor-
cycles, etc.) that enter the blind spot zones
from the rear/front/side of the vehicle.
When the vehicle is started, the BSM warning
light will momentarily illuminate in both outside
rear view mirrors to let the driver know that the
system is operational. The BSM system sen-
sors operate when the vehicle is in any forwardgear or REVERSE and enters stand by mode
when the vehicle is in PARK.
The BSM detection zone covers approximately
one lane on both sides of the vehicle (11 ft or
3.35 m). The zone starts at the outside rear view
mirror and extends approximately 20 ft (6 m) to
the rear of the vehicle. The BSM system moni-
tors the detection zones on both sides of the
vehicle when the vehicle speed has reached
approximately 6 mph (10 km/h) or higher and
will alert the driver of vehicles in these areas.
NOTE:
•
The BSM system does NOT alert the
driver about rapidly approaching vehicles
that are outside the detection zones.
• The BSM system detection zone DOES
NOT change if your vehicle is towing a
trailer. Therefore, visually verify the adja-
cent lane is clear for both your vehicle
and trailer before making a lane change. If
the trailer or other object (i.e., bicycle,
sports equipment) extends beyond the
side of your vehicle, this may result in the
Illuminated Vanity Mirror
Rear Detection Zones
69

The BSM system will not alert you of objects
that are traveling in the opposite direction of the
vehicle in adjacent lanes.WARNING!
The Blind Spot Monitoring system is only an
aid to help detect objects in the blind spot
zones. The BSM system is not designed to
detect pedestrians, bicyclists, or animals.
Even if your vehicle is equipped with the BSM
system, always check your vehicles mirrors,
glance over your shoulder, and use your turn
signal before changing lanes. Failure to do so
can result in serious injury or death.
Rear Cross PathThe Rear Cross Path (RCP) feature is intended
to aid the driver when backing out of parking
spaces where their vision of oncoming vehicles
may be blocked. Proceed slowly and cau-
tiously out of the parking space until the rear
end of the vehicle is exposed. The RCP system
will then have a clear view of the cross traffic
and if an oncoming vehicle is detected, alert
the driver.RCP monitors the rear detection zones on both
sides of the vehicle, for objects that are moving
toward the side of the vehicle with a minimum
speed of approximately 1 to 2 mph (1 km/h to
3 km/h), to objects moving a maximum of
approximately 10 mph (16 km/h), such as in
parking lot situations.
NOTE:
In a parking lot situation, oncoming vehicles
can be obscured by vehicles parked on
either side. If the sensors are blocked by
other structures or vehicles, the system will
not be able to alert the driver.Opposing Traffic
RCP Detection Zones
72

•The selected phone will be used for the next
phone call. If the selected phone is not
available, the Uconnect™ Phone will return
to using the highest priority phone present in
or near (approximately within 30 ft [9 m]) the
vehicle.
Delete Uconnect™ Phone Paired Mobile
Phones
• Press the
button to begin.
• After the “Ready” prompt and the following
beep, say “Setup Phone Pairing”.
• At the next prompt, say “Delete” and follow
the prompts.
• You can also press the
button at any
time while the list is being played, and then
choose the phone you wish to delete.
Things You Should Know About
Your Uconnect™ Phone
Uconnect™ Phone Tutorial
To hear a brief tutorial of the Uconnect™ Phone
features, press the
button and say
“Uconnect™ Tutorial”. Voice Training
For users experiencing difficulty with the
Uconnect™ Phone recognizing their voice
commands or numbers, the Uconnect™ Phone
Voice Training feature may be used. To enter
this training mode, follow one of the two follow-
ing procedures:
From outside the Uconnect™ Phone mode
(e.g., from radio mode)
•
Press and hold the
button for five
seconds until the session begins, or,
• Press the
button and say the “Voice
Training, System Training, or Start Voice
Training” command.
You can either press the Uconnect™ Phone but-
ton to restore the factory setting or repeat the
words and phrases when prompted by the
Uconnect™ Phone. For best results, the Voice
Training session should be completed when the
vehicle is parked with the engine running, all
windows closed, and the blower fan switched off.
This procedure may be repeated with a new
user. The system will adapt to the last trained
voice only. Reset
•
press the
button.
• After the “Ready” prompt, and the following
beep, say “Setup”, then “Reset”.
This will delete all phone pairing, phone book
entries, and other settings in all language
modes. The System will prompt you before
resetting to factory settings.
Voice Command
• For best performance, adjust the rearview
mirror to provide at least
12in (1 cm) gap
between the overhead console (if equipped)
and the mirror.
• Always wait for the beep before speaking.
• Speak normally, without pausing, just as you
would speak to a person sitting a few feet/
meters away from you.
• Make sure that no one other than you is
speaking during a voice period.
• Performance is maximized under:
• low-to-medium blower setting,
• low-to-medium vehicle speed,
84

NOTE:
The engine must be running before the
headlights will turn on in the Automatic
Mode.
Headlights On Automatically With
Wipers
If your vehicle is equipped with Automatic
Headlights, it also has this customer-
programmable feature. When your headlights
are in the automatic mode and the engine is
running, they will automatically turn on when
the wiper system is on. Refer to “Electronic
Vehicle Information Center (EVIC)/Customer-
Programmable Features” in “Understanding
Your Instrument Panel” for further information.
If your vehicle is equipped with a “Rain Sensi-
tive Wiper System” and it is activated, the
headlights will automatically turn on after the
wipers complete five wipe cycles within ap-
proximately one minute, and they will turn off
approximately four minutes after the wipers
completely stop. Refer to “Windshield Wipers
and Washers” in this section for further informa-
tion.NOTE:
When your headlights come on during the
daytime, the instrument panel lights will
automatically dim to the lower nighttime
intensity. Refer to “Lights” in this section for
further information.SmartBeam™ — If EquippedThe SmartBeam™ system provides increased
forward lighting at night by automating high
beam control through the use of a digital cam-
era mounted on the inside rearview mirror. This
camera detects vehicle specific light and auto-
matically switches from high beams to low
beams until the approaching vehicle is out of
view.
NOTE:
If the windshield or SmartBeam™ mirror is
replaced, the SmartBeam™ mirror must be
re-aimed to ensure proper performance. See
your local authorized dealer.
To Activate
1. Enable the Automatic High Beams. Refer to
“Electronic Vehicle Information Center (EVIC)/Customer-Programmable Features” in “Under-
standing Your Instrument Panel” for further in-
formation.
2. Turn the headlight switch to the AUTO head-
light position.
3. Push the multifunction lever away from you
(toward front of vehicle) to engage the high
beam mode.
NOTE:
This system will not activate until the ve-
hicle is at or above 20 mph (32 km/h).
To Deactivate
1. Pull the multifunction lever toward you (or
rearward in car) to manually deactivate the
system (normal operation of low beams).
2. Push back on the multifunction lever once
again to reactivate the system.
NOTE:
Broken, muddy, or obstructed headlights
and taillights of vehicles in the field of view
will cause headlights to remain on longer
(closer to the vehicle). Also, dirt, film, and
other obstructions (sticker, toll box, etc.) on
106

selection, press and release the SELECT but-
ton until a check-mark appears next to the
feature showing the system has been activated
or the check-mark is removed showing the
system has been deactivated.
NOTE:
Turning the headlights on during the day-
time causes the instrument panel lights to
dim. To increase the brightness, refer to
“Lights” in “Understanding The Features Of
Your Vehicle.”
Tilt Mirror in Reverse — If Equipped
When this feature is selected, the outside rear-
view mirrors will tilt downward when the ignition
switch is in the RUN position and the transmis-
sion shift lever is in the REVERSE position. The
mirrors will move back to their previous position
when the transmission is shifted out of RE-
VERSE. To make your selection, press and
release the SELECT button until a check-mark
appears next to the feature showing the system
has been activated or the check-mark is re-
moved showing the system has been deacti-
vated.Auto High Beams
(Available with SmartBeam™ Only)
When this feature is selected, the high beam
headlights will deactivate automatically under
certain conditions. To make your selection,
press and release the SELECT button until a
check-mark appears next to the feature show-
ing the system has been activated or the
check-mark is removed showing the system
has been deactivated. Refer to “Lights/
SmartBeam™ — If Equipped” in “Understand-
ing The Features Of Your Vehicle” for further
information.
Wiper Mode — If Equipped
When this feature is selected, the system will
automatically activate the windshield wipers if it
senses moisture on the windshield. To make
your selection, press and release the SELECT
button until a check-mark appears next to the
feature showing the system has been activated
or the check-mark is removed showing the
system has been deactivated. When this fea-
ture is deactivated, the system reverts to the
standard intermittent wiper operation.
Easy Entry/Exit Seat
(Available with Memory Seat Only)
This feature provides automatic driver seat
positioning to enhance driver mobility when
entering and exiting the vehicle. To make your
selection, press and release the SELECT but-
ton until a check-mark appears next to the
feature showing the system has been activated
or the check-mark is removed showing the
system has been deactivated.
NOTE:
The seat will return to the memorized seat
location (if Recall Memory with Remote Key
Unlock is set to ON) when the RKE transmit-
ter is used to unlock the door. Refer to
“Driver Memory Seat” in “Understanding
The Features Of Your Vehicle” for further
information.
Key-Off Power Delay
When this feature is selected, the power win-
dow switches, radio, hands-free system (if
equipped), DVD video system (if equipped),
power sunroof (if equipped), and power outlets
will remain active for up to 10 minutes after the
ignition switch is turned OFF. Opening either
182

Plastic is not as scratch-resistant as glass and
therefore different lens cleaning procedures
must be followed.
To minimize the possibility of scratching the
lenses and reducing light output, avoid wiping
with a dry cloth. To remove road dirt, wash with
a mild soap solution followed by rinsing.
Do not use abrasive cleaning components,
solvents, steel wool or other aggressive mate-
rial to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a
regular basis with MOPARGlass Cleaner or
any commercial household-type glass cleaner.
Never use an abrasive type cleaner. Use cau-
tion when cleaning inside rear windows
equipped with electric defrosters. Do not use
scrapers or other sharp instruments which may
scratch the elements.
When cleaning the rearview mirror, spray
cleaner on the towel or rag that you are using.
Do not spray cleaner directly on the mirror. Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this
vehicle are molded in clear plastic. When
cleaning the lenses, care must be taken to
avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap
solution may be used, but do not use high
alcohol content or abrasive cleaners. If soap is
used, wipe clean with a clean damp rag.
2. Dry with a soft cloth.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with
chemical solvents or abrasive cleaners. This
will weaken the fabric. Sun damage will also
weaken the fabric.
If the belts need cleaning, use MOPAR
Total
Clean, a mild soap solution, or lukewarm water.
Do not remove the belts from the vehicle to
wash them. Dry with a soft cloth.
Replace the belts if they appear frayed or worn
or if the buckles do not work properly.FUSES
Totally Integrated Power Module
The Totally Integrated Power Module is located
in the engine compartment. This center con-
tains cartridge fuses and mini fuses. A descrip-
tion of each fuse and component may be
stamped on the inside cover, otherwise the
cavity number of each fuse is stamped on the
inside cover that corresponds to the following
chart.
Totally Integrated Power Module
318

Gas Cap (Fuel Filler Cap)....265,266,301
Gasoline (Fuel) ...............262
Conserving ................173
Gasoline, Clean Air ............263
Gauges Coolant Temperature ..........164
Fuel ....................163
Speedometer ..............163
Tachometer ...............159
Gear Ranges ............. 222,226
Gear Select Lever Override ........290
General Information ........15,20,262
Glass Cleaning ...............318
Gross Axle Weight Rating .........267
Gross Vehicle Weight Rating .......267
Hands-Free Phone (Uconnect™) .....74
Hazard Warning Flasher .........282
Headlights .................322
Bulb Replacement ...........323
Cleaning .................317
On With Wipers .............106
Replacing ................323
Heated Mirrors ...............68
High Beam Indicator ...........160
Hill Descent Control ............250 Hill Descent Control Indicator
......160
Hill Start Assist ...............249
Holder, Cup ................144
Hood Release ...............104
Ignition ....................13
Key ................... 12,13
Ignition Key Removal ............13
Illuminated Entry ..............17
Immobilizer (Sentry Key) ..........14
Infant Restraint .............. 47,49
Inflation Pressure Tires ..........253
Information Center, Vehicle ........164
Inside Rearview Mirror ...........67
Instrument Cluster .............159
Instrument Panel and Controls ......157
Instrument Panel Lens Cleaning .....318
Integrated Power Module (Fuses) ....318
Interior Appearance Care .........317
Intermittent Wipers (Delay Wipers) ....111
Introduction ..................4
Jack Location ...............283
Jack Operation ............ 283,284
Jacking Instructions ............284
Jump Starting ...............287 Key-In
Reminder
..............14
Key, Programming .............15
Key, Replacement ..............15
Key, Sentry (Immobilizer) ..........14
Keyless Enter-N-Go ........22,176,216
Keyless Entry System ............17
Keyless Go ............... 12,176
Keys .....................12
Lap/Shoulder Belts .............30
LATCH (Lower Anchors and Tether for
CHildren) ...................51
Latches ...................58
Lead Free Gasoline ............262
Leaks, Fluid .................58
Liftgate ....................26
Liftgate Flipper Glass ............27
Liftgate Window Wiper/Washer ......149
Light Bulbs ..................58
Lights .................. 58,105
Airbag ............. 42,45,56,159
Anti-Lock .................163
Automatic Headlights ..........105
Back-Up .................324
Brake Assist Warning ..........251
Brake Warning ..............162
369
