2012 JEEP GRAND CHEROKEE light

Telltale Lightwill flash on and off for 75 sec-
onds and then turn off, and the Electronic
Vehicle Information Center (EVIC) will display
the “SERVICE TPM SYSTEM” message. The
EVIC will also display pressure values in place
of the dashes. On the next ignition switch cycle
the SERVICE TPM SYSTEM message will no
longer be displayed as long as no system fault
exists.
General InformationTransmitter and receivers operate on a carrier
frequency of 433.92 MHz as required by EEC
regulations. These devices must be certified to
conform to specific regulations in each indi-
vidual country. Two sets of regulations are
involved: ETS (European Telecommunication
Standard) 300–220, which most countries use,
and German BZT federal regulation 225Z125,
which is based on ETC 300–220 but has addi-
tional unique requirements. Other defined re-
quirements are noted in ANNEX VI of COMMIS-
SION DIRECTIVE 95/56/EC. Operation is
subject to the following conditions:
• This device may not cause harmful interfer-
ence. •
This device must accept any interference
received, including interference that may
cause undesired operation.
FUEL REQUIREMENTS —
GASOLINE ENGINE
3.6L Engine
These engines are designed to meet all emis-
sions regulations and provide excellent fuel
economy and performance when using high-
quality unleaded gasoline with a minimum re-
search octane rating of 91. The use of premium
gasoline is not recommended, as it will not
provide any benefit over regular gasoline in
these engines.
5.7L EngineTheses engines are designed to meet all emis-
sions regulations and provide satisfactory fuel
economy and performance when using high-
quality unleaded gasoline having an octane
range of 91 to 95. The manufacturer recom-
mends the use of 95 octane for optimum per-
formance. The use of premium gasoline is not
recommended, as it will not provide any benefit
over regular gasoline in these engines. Light spark knock at low engine speeds is not
harmful to your engine. However, continued
heavy spark knock at high speeds can cause
damage, and immediate service is required.
Poor quality gasoline can cause problems such
as hard starting, stalling, and hesitations. If you
experience these symptoms, try another brand
of gasoline before considering service for the
vehicle.
Over 40 auto manufacturers worldwide have
issued and endorsed consistent gasoline
specifications (the Worldwide Fuel Charter,
WWFC) which define fuel properties necessary
to deliver enhanced emissions, performance,
and durability for your vehicle. The manufac-
turer recommends the use of gasoline that
meets the WWFC specifications if they are
available.
Besides using unleaded gasoline with the
proper octane rating, gasolines that contain
detergents, corrosion and stability additives
are recommended. Using gasolines that have
these additives may help improve fuel
economy, reduce emissions, and maintain ve-
hicle performance.
262

WARNING!
Do not use alcohol or gasoline as a fuel-
blending agent. They can be unstable under
certain conditions and hazardous or explosive
when mixed with diesel fuel.
Diesel fuel is seldom completely free of water.
To prevent fuel system trouble, drain the accu-
mulated water from the fuel/water separator
using the provided fuel/water separator drain. If
you buy good quality fuel and follow the cold
weather advice above, fuel conditioners should
not be required in your vehicle. If available in
your area, a high cetane “premium” diesel fuel
may offer improved cold-starting and warm-up
performance.
ADDING FUEL
Fuel Filler Cap (Gas Cap)
The gas cap is located behind the locking fuel
filler door, on the driver’s side of the vehicle. If
the gas cap is lost or damaged, be sure the
replacement cap is for use with this vehicle.
1. Press the fuel filler door release switch (lo-
cated under the headlamp switch). 2. Open the fuel filler door, and remove the fuel
filler cap.
CAUTION!
•
Damage to the fuel system or emission
control system could result from using an
improper fuel cap (gas cap). A poorly fitting
cap could let impurities into the fuel system.
Also, a poorly fitting aftermarket cap can
cause the “Malfunction Indicator Light
(MIL)” to illuminate, due to fuel vapors
escaping from the system.
• A poorly fitting gas cap may cause the MIL
to turn on.
• To avoid fuel spillage and overfilling, do not
“top off” the fuel tank after filling.
WARNING!
•Never have any smoking materials lit in or
near the vehicle when the gas cap is re-
moved or the tank is being filled.
• Never add fuel when the engine is running.
This is in violation of most state and federal
fire regulations and may cause the mal-
function indicator light to turn on.
(Continued)
Fuel Filler Door Release Switch
Fuel Filler Cap
265

Towing Requirements – Tires
Proper tire inflation pressures are essential tothe safe and satisfactory operation of your
vehicle. Refer to “Tires – General Informa-
tion” in “Starting and Operating” for proper
tire inflation procedures.
Check the trailer tires for proper tire inflation pressures before trailer usage.
Check for signs of tire wear or visible tire damage before towing a trailer. Refer to
“Tires – General Information” in “Starting and
Operating” for proper inspection procedure.
When replacing tires, refer to “Tires – Gen- eral Information” in “Starting and Operating”
for proper tire replacement procedures. Re-
placing tires with a higher load carrying
capacity will not increase the vehicle’s
GVWR and GAWR limits.
Towing Requirements – Trailer Brakes
Do notinterconnect the hydraulic brake sys-
tem or vacuum system of your vehicle with
that of the trailer. This could cause inad-
equate braking and possible personal injury. An electronically-actuated trailer brake con-
troller is required when towing a trailer with
electronically-actuated brakes. When towing
a trailer equipped with a hydraulic surge-
actuated brake system, an electronic brake
controller is not required.
Trailer brakes are recommended for trailers over 1,000 lbs (454 kg), and required for
trailers in excess of 1,654 lbs (750 kg).
WARNING!
• Do not connect trailer brakes to your vehi-
cle’s hydraulic brake lines. It can overload
your brake system and cause it to fail. You
might not have brakes when you need
them and could have an accident.
• Towing any trailer will increase your stop-
ping distance. When towing, you should
allow for additional space between your
vehicle and the vehicle in front of you.
Failure to do so could result in an accident. Towing Requirements – Trailer Lights And
Wiring
Whenever you pull a trailer, regardless of the
trailer size, stop lights and turn signals on the
trailer are required for motoring safety.
The Trailer Tow Package includes a 13 pin
wiring harness. Use a factory approved trailer
harness and connector.
NOTE:
Do not cut or splice wiring into the vehicles
wiring harness.
The electrical connections are all complete to
the vehicle but you must mate the harness to a
trailer connector.
272

Pin
Number Function Wire
Color
1 Left Turn Signal Black/ White
2 Rear Fog Light White
3
aGround/Common
Return for Contacts
(Pins) 1 and 2 and 4 to 8 Brown
4 Right Turn Signal Black/ Green
Pin
Number Function Wire
Color
5 Right Rear Position, Side Marker Lights,and Rear Registra- tion Plate Illumina- tion Device.
b
Green/Red
6 Stop Lights Black/Red
7 Left Rear Position, Side Marker Lights,and Rear Registra- tion Plate Illumina- tion Device.
b
Green/Black
8 Reverse lights Blue/Red
9 Permanent Power Supply (+12V) Red
10 Power Supply Con- trolled by IgnitionSwitch (+12V) Yellow
11
aReturn for Contact (Pin) 10 Yellow/
Brown
Pin
Number Function Wire
Color
12 Reserve for Future Allocation –
13
aReturn for Contact (Pin) 9 Red/
Brown
Note: The allocation pin 12 has been
changed from “Coding for coupled Trailer” to
“Reserve for Future Allocation.”
aThe three return circuits shall not be con-
nected electrically in the trailer.
bThe rear position registration plate illumina-
tion device shall be connected such that no
light of the device has a common connection
with both pins 5 and 7.
13 - Pin Connector
273

Electronic Speed Control – If Equipped
Do not use in hilly terrain or with heavy loads.
When using the speed control, if you expe-rience speed drops greater than 10 mph
(16 km/h), disengage until you can get back
to cruising speed.
Use speed control in flat terrain and with light loads to maximize fuel efficiency.
Cooling System
To reduce potential for engine and transmission
overheating, take the following actions:
City Driving
When stopped for short periods of time, shift
the transmission into NEUTRAL and increase
engine idle speed.
Highway Driving
Reduce speed.
Air Conditioning
Turn off temporarily. Trailer Hitch Attaching Points
Your vehicle will require extra equipment to tow
a trailer safely and efficiently. The trailer tow
hitch must be attached to your vehicle using
the provided attaching points on the vehicle’s
frame. Refer to the following chart to determine
the accurate attaching points. Other equip-
ment, such as trailer sway controls and braking
equipment, trailer equalizing (leveling) equip-
ment and low profile mirrors, may also be
required or strongly recommended.Trailer Tow Hitch Attaching Points And
Overhang Dimensions
Fixed, Detach andRetractable Hitch
A 1.85 ft. (565 mm)
B 2.09 ft. (636 mm)
C 2.32 ft. (707 mm)
D 2.4 ft. (733 mm)
E 1.62 ft. (494 mm)
F 1.47 ft. (447 mm)
275

1. Bring the vehicle to a complete stop and
shift the transmission to PARK.
2. Turn the engine OFF.
3. For vehicles with Keyless Enter-N-Go, re-
move the Keyless Enter-N-Go button and use
the key fob to complete this procedure. Refer to
“Starting Procedures/Keyless Enter-N-Go” in
“Starting and Operating” for further information.
4. Turn the ignition switch to the ON/RUN po-
sition, but do not start the engine.
5. Press and hold the brake pedal.
6. Shift the transmission into NEUTRAL.
7. Using the point of a ballpoint pen or similar
object, press and hold the recessed transfer
case NEUTRAL (N) button (located by the
selector switch) for four seconds, until the light
behind the N symbol starts to blink, indicating
shift in progress. The light will stop blinking
(stay on solid) when the shift to NEUTRAL (N) is
complete.8. After the shift is completed and the NEU-
TRAL (N) light stays on, release the NEUTRAL
(N) button.
9. Start the engine.
10. Shift the transmission into REVERSE.
11. Release the brake pedal for five seconds
and ensure that there is no vehicle movement.
12. Turn the engine OFF, then turn the ignition
switch back to the ON/RUN position without
starting the engine.
13. Firmly apply the parking brake.14. Shift the transmission into PARK.
CAUTION!
Damage to the transmission may occur if the
transmission is shifted into PARK with the
transfer case in NEUTRAL (N) and the engine
running. With the transfer case in NEUTRAL
(N) ensure that the engine is off prior to
shifting the transmission into PARK.
15. Attach the vehicle to the tow vehicle using
a suitable tow bar.
16. Release the parking brake.
17. Disconnect the negative battery cable, and
secure it away from the negative battery post.
NOTE:
• Steps 1 through 6 are requirements that
must be met prior to pressing the NEU-
TRAL (N) button, and must continue to be
met until the four seconds elapse and the
shift has been completed. If any of these
requirements are not met prior to press-
ing the NEUTRAL (N) button or are no
longer met during the four second timer,
NEUTRAL (N) Switch
278

then the NEUTRAL (N) indicator light will
flash continuously until all requirements
are met or until the NEUTRAL (N) button is
released.
• The ignition switch must be in the ON/
RUN position for a shift to take place and
for the position indicator lights to be op-
erable. If the ignition switch is not in the
ON/RUN position, the shift will not take
place and no position indicator lights will
be on or flashing.
• A flashing NEUTRAL (N) position indica-
tor light indicates that shift requirements
have not been met.
Shifting Out Of NEUTRAL (N)
Use the following procedure to prepare your
vehicle for normal usage.
1. Bring the vehicle to a complete stop, leaving
it connected to the tow vehicle.
2. Firmly apply the parking brake.
3. Reconnect the negative battery cable. 4. Turn the ignition switch to the LOCK/OFF
position.
5. Turn the ignition switch to the ON/RUN po-
sition, but do not start the engine.
6. Press and hold the brake pedal.
7. Shift the transmission into NEUTRAL.
8. Using the point of a ballpoint pen or similar
object, press and hold the recessed transfer
case NEUTRAL (N) button (located by the
selector switch) for one second.
NOTE:
When shifting out of transfer case NEUTRAL
(N), turning the engine OFF may be required
to avoid gear clash.
9. After the NEUTRAL (N) indicator light turns
off, release the NEUTRAL (N) button.
10. After the NEUTRAL (N) button has been
released, the transfer case will shift to the
position indicated by the selector switch.
11. Shift the transmission into PARK.
12. Release the brake pedal.
13. Disconnect vehicle from the tow vehicle.
14. Start the engine.
NEUTRAL (N) Switch
279

15. Press and hold the brake pedal.
16. Release the parking brake.
17. Shift the transmission into DRIVE, release
the brake pedal, and check that the vehicle
operates normally.
18. The Keyless Enter-N-Go button (if
equipped) may now be reinstalled if desired.
Refer to “Starting Procedures/Keyless Enter-N-
Go” in “Starting and Operating” for further
information.NOTE:
•
Steps 1 through 7 are requirements that
must be met prior to pressing the NEU-
TRAL (N) button, and must continue to be
met until the shift has been completed. If
any of these requirements are not met
prior to pressing the NEUTRAL (N) button
or are no longer met during the shift, the
NEUTRAL (N) indicator light will flash
continuously until all requirements are
met or until the NEUTRAL (N) button is
released. •
The ignition switch must be in the ON/
RUN position for a shift to take place and
for the position indicator lights to be op-
erable. If the ignition switch is not in the
ON/RUN position, the shift will not take
place and no position indicator lights will
be on or flashing.
• A flashing NEUTRAL (N) position indica-
tor light indicates that shift requirements
have not been met.
280
