2012 INFINITI G37 sensor

Black plate (77,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SSS1016
SUPPLEMENTAL AIR BAG WARNING
LABELS GUID-0B65E0E3-218A-4A06-925F-DDB783835748
Warning labels about the supplemental
front-impact air bag systems are placed in
the vehicle as shown in the illustration.
SRS air bag GUID-E4E32938-35BA-448F-83FA-D791212BFB56
The warning labels
* 1
are located on the
surface of the sun visors. SPA1097
SUPPLEMENTAL AIR BAG WARNING
LIGHT GUID-FC2CCCAD-ABA5-4075-9F93-F2472626804E
The supplemental air bag warning light,
displaying
in the instrument panel,
monitors the circuits of the supplemental
front-impact air bag, front seat-mounted
side-impact supplemental air bag, roof-
mounted curtain side-impact supplemental
air bag, and seat belt pretensioner sys-
tems. The monitored circuits include the Air
bag Control Unit (ACU), satellite sensors,
crash zone sensor, occupant classification
system, front air bag modules, side air bag
modules, curtain air bag modules, preten-
sioner, front passenger air bag status light and all related wiring.
When the ignition switch is in the ON
position, the supplemental air bag warning
light illuminates for about 7 seconds and
then turns off. This means the system is
operational.
If any of the following conditions occur, the
front air bag, side air bag, curtain air bag
and pretensioner systems need servicing:
. The supplemental air bag warning light
remains on approximately 7 seconds
after the ignition switch is pushed to
the ON position.
. The supplemental air bag warning light
flashes intermittently.
. The supplemental air bag warning light
does not come on at all.
Under these conditions, the front air bag,
side air bag, curtain air bag or pretensioner
systems may not operate properly. They
must be checked and repaired. Take your
vehicle to the nearest INFINITI retailer.
WARNING If the supplemental air bag warning light is
on, it could mean that the front air bag, side
air bag, curtain air bag and/or pretensioner
Safety — Seats, seat belts and supplemental restraint system
1-55

Black plate (105,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]amount of fuel in the fuel tank and the
actual fuel consumption.
The display is updated every 30 seconds.
The dte mode includes a low range warning
feature. If the fuel level is low, the warning
is displayed on the screen.
When the fuel level drops even lower, the
dte display will change to “——” .
. If the amount of fuel added is small, the
display just before the ignition switch
is pushed to the OFF position may
continue to be displayed.
. When driving uphill or rounding curves,
the fuel in the tank shifts, which may
momentarily change the display.
5. Outside air temperature (ICY — 8 F
or 8 C) GUID-35621BA5-D61E-4ECD-9628-F300D193449A
The outside air temperature is displayed in
8 F or 8 C in the range of − 22 to 131 8 F ( − 30
to 55 8 C).
The outside air temperature mode includes
a low temperature warning feature. If the
outside air temperature is below 37 8 F
(3 8 C), the warning is displayed on the
screen.
The outside temperature sensor is located
in front of the radiator. The sensor may be affected by road or engine heat, wind
directions and other driving conditions.
The display may differ from the actual
outside temperature or the temperature
displayed on various signs or billboards.
6. Setting GUID-9F18B5C6-F437-4D24-B240-415AA28B0E09
Setting cannot be made while driving. A
message “ Setting can only be operated
when stopped ” is also displayed on the
dot matrix crystal display.
The
switch
* A
and switch
* B
are
used in the setting mode to select and
decide a menu.
SKIP: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the switch
* A
to move to the
warning check mode.
Push the
switch
* B
to select other
menus.
ALERT: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 3 submenus under the alert
menu.
. BACK
Select this submenu to return to the top
page of the setting mode.
. TIME TO REST
Select this submenu to specify when the “ time to rest ” indicator activates.
. ICY
Select this submenu to display the low
outside temperature warning.
MAINTENANCE: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 5 submenus under the main-
tenance menu.
. BACK
Select this submenu to return to the top
page of the setting mode.
. ENGINE OIL
Select this submenu to set or reset the
distance for changing the engine oil.
. OIL FILTER
Select this submenu to set or reset the
distance for replacing the oil filter.
. TIRE
Select this submenu to set or reset the
distance for replacing tires.
. OTHER
Select this submenu and set or reset
the distance for replacing items other
than the engine oil, oil filter and tires.
DISPLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 3 submenus under the display
menu.
Instruments and controls
2-27

Black plate (111,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SIC4190
RAIN-SENSING AUTO WIPER SYS-
TEM (if so equipped) GUID-48081641-8F6B-4F78-BAA1-DC74FECCE041
The rain-sensing auto wiper system can
automatically turn on the wipers and
adjust the wiper speed depending on the
rainfall and the vehicle speed by using the
rain sensor located on the upper part of
the windshield.
To set the rain-sensing auto wiper system,
push the lever down to the AUTO position
* 1
. The wiper will sweep once while the
ignition switch is in the ON position.
The rain sensor sensitivity level can be
adjusted by turning the knob toward the front
* 2
(High) or toward the rear
* 3
(Low).
. High — High sensitive operation
. Low — Low sensitive operation
To turn the rain-sensing auto wiper system
off, push up the lever to the OFF position,
or pull down the lever to the LO or HI
position.
CAUTION Do not touch the rain sensor and around it
when the wiper switch is in the AUTO
position and the ignition switch is in the
ON position. The wipers may operate un-
expectedly and cause to an injury or a wiper
damage.
. The rain-sensing auto wipers are in-
tended for use during rain. If the switch
is left in the AUTO position, the wipers
may operate unexpectedly when dirt,
fingerprints, oil film or insects are
stuck on or around the sensor. The
wipers may also operate when exhaust
gas or moisture affect the rain sensor.
. The rain-sensing auto wipers may not
operate if rain does not hit the rain sensor even if it is raining.
. When the windshield glass is coated
with water repellent, the speed of the
rain-sensing auto wipers may be high-
er even though the amount of the
rainfall is small.
. Be sure to turn off the rain-sensing
auto wiper system when you use a car
wash.
. Using genuine wiper blades is recom-
mended for proper operation of the
rain-sensing auto wiper system. (See
“ Windshield wiper blades ” (P.8-22) for
wiper blade replacement.)
Instruments and controls
2-33

Black plate (114,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-36 Instruments and controlsThe autolight system can turn on the
headlights automatically when it is dark
and turn off the headlights when it is light.
If the ignition switch is pushed to the OFF
position and one of the doors is opened
and this condition is continued, the head-
lights remain on for 5 minutes.
Automatic headlights off delay: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
You can keep the headlights on for up to
180 seconds after you push the ignition
switch to OFF and open any door then close
all the doors.
You can adjust the period of the automatic
headlights off delay from 0 seconds (OFF)
to 180 seconds. The factory default setting
is 45 seconds.
For automatic headlights off delay setting,
see “ Light Off Delay ” (P.4-19). SAA0642A
Be sure not to put anything on top of the
photo sensor
* A
located on the top of the
instrument panel. The photo sensor con-
trols the autolight; if it is covered, the
photo sensor reacts as if it is dark and the
headlights will illuminate. SIC3269
Headlight beam select GUID-1105ED2E-9741-4EAA-A5D8-36C19A0F048D
* 1
To select the low beam, put the lever
in the neutral position as shown.
* 2
To select the high beam, push the
lever forward while the switch is in the
position. Pull it back to select the
low beam.
* 3
Pulling the lever toward you will flash
the headlight high beam even when
the headlight switch is in the OFF
position.

Black plate (171,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Automatic anti-glare type GUID-42BCED9D-122C-447D-8C17-A6AFE2097EE0
The inside mirror is designed so that it
automatically changes reflection according
to the intensity of the headlights of the
following vehicle.
The anti-glare system will be automatically
turned on when the ignition switch is
pushed to the ON position.
When the anti-glare system is turned on,
the indicator light
* A
will illuminate and
excessive glare from the headlights of the
vehicle behind you will be reduced.
Type A: Push the
switch
* B
to make the
inside rearview mirror operate normally
and the indicator light will turn off. Push
the
switch again to turn the system on.
Type B: Push the “ * ” switch
* C
to make
the inside rearview mirror operate nor-
mally. The indicator light will turn off. Push
the “ I ” switch
* D
to turn the system on.
Do not allow any object to cover the
sensors
* E
or apply glass cleaner on
them. Doing so will reduce the sensitivity
of the sensor, resulting in improper
operation.
For the compass (if so equipped) opera- tion, see “ Compass ” (P.2-9).
For the HomeLink ®
Universal Transceiver
operation, see “ HomeLink ®
Universal
Transceiver ” (P.2-59).
SPA2319
OUTSIDE MIRRORS GUID-44D37997-DE2C-47B8-BB91-5AA2BF04971B
WARNING Objects viewed in the outside mirror on the
passenger side are closer than they appear.
Be careful when moving to the right. Using
only this mirror could cause an accident.
Use the inside mirror or glance over your
shoulder to properly judge distances to
other objects.
Pre-driving checks and adjustments
3-29

Black plate (217,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]control button.
To return to the automatic control mode,
push the intake air control button until the
indicator light on the “
” side illumi-
nates. The advanced climate control sys-
tem turns on and the intake air will be
controlled automatically.
To turn system off GUID-767438D1-A2A8-4078-8AA8-A30753E720F2
Push the OFF button.
Advanced climate control system GUID-AD61F339-E220-4617-BF07-B3EC3255539C
The advanced climate control system keeps
the air inside of the vehicle clean, using
the ion control and the automatic air intake
control with outside odor and exhaust gas
detecting sensor. SAA2734
Ion control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
This unit generates highly concentrated
Plasmacluster ®
ions into the air blown
from the ventilators and reduces odor
absorbed into the interior trim.
The high-density Plasmacluster ®
ions gen-
erated in the air conditioner ’ s air stream
not only suppress airborne bacteria and
reduce the adherence of odors to the
interior trim, but also have a proven skin
moisture preserving effect.
When the air conditioner is turned on, the
system generates Plasmacluster ®
ions
automatically. The amount of Plasmacluster ®
ions in-
creases according to the amount of air
flow. When the air flow is high, “
” is
displayed on the screen and when the air
flow is low, the indication in the screen
changes to “
” .
Outside odor and exhaust gas detection
sensor: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
This vehicle is equipped with an outside
odor and exhaust gas detection sensor.
When the automatic intake air control is
ON, the sensor detects odors and exhaust
gas, and then the system automatically
changes from the outside air circulation
mode to the recirculation mode.
When the intake air control button is
pushed under the following conditions,
the indicator light on the “
” side will
illuminate and the outside odor and
exhaust gas detection sensor will turn on.
. The air flow control is not in the front
defroster mode (the indicator light on
the “
” front defroster button is
turned off).
. The outside temperature is about 32 8 F
(0 8 C) or more.
. The outside odor and exhaust gas
detection sensor detects industrial
Monitor, climate, audio, phone and voice recognition systems
4-39

Black plate (218,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-40 Monitor, climate, audio, phone and voice recognition systemsodors such as pulp or chemicals and
exhaust gas such as gasoline or diesel.
When the automatic intake air control is
ON, for the first 5 minutes, the recircula-
tion mode is selected to prevent dust, dirt
and pollen from entering the vehicle and
cleans the air inside of the vehicle with
Plasmacluster ®
ion that are emitted from
the ventilator.
After 5 minutes, the sensor detects outside
odors and exhaust gas and automatically
alternates between the recirculation mode
and outside air circulation mode.
OPERATING TIPS GUID-05B14404-70B8-489F-89C7-C5767F0AC7CE
When the engine coolant temperature and
outside air temperature are low, the air
flow from the foot outlets may not operate
for a maximum of 150 seconds. This is not
a malfunction. After the coolant tempera-
ture warms up, air will flow normally from
the foot outlets. SIC2768
The sunload sensor
* A
on the instrument
panel helps maintain a constant tempera-
ture. Do not put anything on or around this
sensor.
IN-CABIN MICROFILTER GUID-25EB7DE1-36F7-4B0F-9FD5-D23071134FE8
Type A and B:
The climate control system is equipped
with an in-cabin microfilter which collects
dirt, pollen, dust, etc. To make sure the air
conditioner heats, defogs, and ventilates
efficiently, replace the filter in accordance
with the maintenance schedule in the
INFINITI Service and Maintenance Guide.
To replace the filter, contact an INFINITI retailer.
The filter should be replaced if air flow is
extremely decreased or when windows fog
up easily when operating heater or air
conditioning system.
Type C:
The climate control system is equipped
with a natural grape seed polyphenol filter
which collects and neutralizes dirt, pollen,
dust, etc. To make sure that the air
conditioner heats, defogs and ventilates
efficiently, replace the filter in accordance
with the maintenance schedule in the
INFINITI Service and Maintenance Guide.
To replace the filter, contact an INFINITI
retailer.
The filter should be replaced if the air flow
decreases significantly or if windows fog
up easily when operating the heater or air
conditioner.

Black plate (326,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-6 Starting and driving. When a spare tire is mounted or a wheel
is replaced, the TPMS will not function
and the low tire pressure warning light
will flash for approximately 1 minute.
The light will remain on after 1 minute.
Contact your INFINITI retailer as soon as
possible for tire replacement and/or
system resetting.
. Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
. Do not inject any tire liquid or aerosol
tire sealant into the tires, as this may
cause a malfunction of the tire pressure
sensors.
CAUTION. The TPMS may not function properly
when the wheels are equipped with tire
chains or the wheels are buried in snow.
. Do not place metalized film or any metal
parts (antenna, etc.) on the windows.
This may cause poor reception of the
signals from the tire pressure sensors,
and the TPMS will not function properly. Some devices and transmitters may tem-
porarily interfere with the operation of the
TPMS and cause the low tire pressure
warning light to illuminate. Some exam-
ples are:
. Facilities or electric devices using simi-
lar radio frequencies are near the
vehicle.
. If a transmitter set to similar frequen-
cies is being used in or near the
vehicle.
. If a computer (or similar equipment) or
a DC/AC converter is being used in or
near the vehicle.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
Note: Changes or modifications not ex-
pressly approved by the party responsible
for compliance could void the user ’ s
authority to operate the equipment. For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
AVOIDING COLLISION AND ROLL-
OVER GUID-EE5BC752-B37C-479E-857D-032EF1A955FA
WARNING Failure to operate this vehicle in a safe and
prudent manner may result in loss of control
or an accident.
Be alert and drive defensively at all times.
Obey all traffic regulations. Avoid exces-
sive speed, high speed cornering, or
sudden steering maneuvers, because
these driving practices could cause you to
lose control of your vehicle. As with any
vehicle, a loss of control could result in a
collision with other vehicles or objects, or
cause the vehicle to rollover, particularly if
the loss of control causes the vehicle to
slide sideways. Be attentive at all times,
