2012 HONDA PILOT navigation system

Thechartontherightexplainsthe
error messages you may see in the
display while playing a disc.
If you see an error message in the
display while playing a disc, press
the eject button. After ejecting the
disc, check it for damage or
deformation. If there is no damage,
insert the disc again.
For additional information on
damaged discs, see page .
Theaudiosystemwilltrytoplaythe
disc. If there is still a problem, the
error message will reappear. Press
the eject button, and pull out the disc.
Insert a dif f erent disc. If the new
disc plays, there is a problem with
the f irst disc. If the error message
cycle repeats and you cannot clear it,
take your vehicle to a dealer.Cause
Error Message Solution
333
Track/File format not
supported
Mechanical Error
Servo Error
Disc Error Current track will be skipped. The next
supported track or file plays automatically.
Press the EJECT button and pull out the disc.
Check the disc f or serious damage, signs of
def ormation, excessive scratches, and/or dirt
(see page 333). Insert the disc again. If the code
does not disappear, or the disc cannot be
removed, consult your dealer. Do not try to
f orce the disc out of the player.
Check the disc f or serious damage, signs of
def ormation, excessive scratches, and/or dirt
(see page 333).
Disc Player Error Messages (EX, EX-L , and Canadian L X models without navigation sys
tem)
Features
253
UNSUPPORTED
PUSH EJECT
CHECK DISC
Main MenuTable of Contents

Playing CD L ibrary Audio (EX, EX-L , and Canadian L X models without navigation system)
254
SELECTOR KNOB
RETURN BUTTON
SCAN BUTTON
SETUP BUTTONPOWER/VOLUME KNOB
CDL BUTTON DISC SLOT
SKIP BAR ALBUM/FOLDER BAR
U.S. EX and Canadian LX models
EJECT BUTTON
Main MenuTable of Contents

CONT INUED
Playing CD L ibrary Audio (EX, EX-L , and Canadian L X models without navigation system)
Features
255
SCAN
BUTTON
SETUP BUTTON
EX-L models
Canadian EX models EX-L models with Rear
Entertainment System
SKIP BAR CDL BUTTON
DISC SLOT
SELECTOR KNOB
POWER/
VOLUME KNOB
CDL BUTTON
SELECTOR KNOB RETURN BUTTON
RETURN BUTTON CATEGORY
BAR
EJECT BUTTON
SCAN
BUTTON
SKIP BAR
POWER/
VOLUMEKNOB
RETURN BUTTON SETUP BUTTON SELECTOR KNOB
CDL BUTTON CATEGORY BAR
EJECT
BUTTON
DISC SLOT
SCAN
BUTTON
SKIP BAR
SETUP BUTTONFOLDER BAR
POWER/
VOLUME KNOB
Main MenuTable of Contents

µ µ µµ µ µµµ µ
If equipped
The CD Library Audio f unction can
record tracks from music CDs to the
f lash memory. Each music CD is
stored on an albumlist. This audio
system can store up to 18 albums.Digital music f iles, such as MP3,
WMA, AAC etc., from CD-R,
DVD-R and USB f lash memory
devices cannot be copied to the
CD Library. Likewise, digital
musicfilesrecordedintheCD
Library cannot be copied to CD-R,
DVD-R and USB devices. Music data recorded in the CD
Library can only be used f or
personal use.
Title inf ormation will be displayed
when the inf ormation is f ound in
the Gracenote
Album Inf o
(Gracenote
Media Database) in
the built-in f lash memory. See
page . If the CD Library is ever replaced,
all data will be lost and stored
music will not be recovered.
Only recordings f rom a standard
CD-DA (44.1 kHz, 16 bit stereo
PCM digital sound data) to CD
Library are supported.
Although data is recorded using
ultra-ef f icient compression
technology, sound quality may
vary slightly f rom the original.Recording f unction f rom f ollowing
media is not supported.
CD-DA which prohibits the
copying by SCMS
CD-DA with copy control
SACD (Super Audio CD)
DTS-CD
DVD-A
CD-R/RW
DVD-R/RW
Copy controlled CDs (Playback
cannot be guaranteed)
DTS-CDs (Only enabled f or
playback)
360
Playing CD L ibrary Audio (EX, EX-L , and Canadian L X models without navigation syst em)
256
NOTE:
Main MenuTable of Contents

Playing an iPod(EX-L and Canadian EX models without navigation system)
Features
265
SELECTOR KNOB
EX-L models
Canadian EX models EX-L models with Rear
Entertainment System
SKIP BAR USB INDICATOR
ALBUM ART
SKIP BAR RETURN BUTTONRETURN BUTTON
SETUP BUTTON SETUP BUTTON
POWER/VOLUME KNOB
SELECTOR KNOB
RETURN BUTTON USB/AUX BUTTON
POWER/VOLUMEKNOB
SKIP BAR
SETUP BUTTON
SELECTOR KNOB
POWER/VOLUME KNOB
USB/AUX BUTTON
USB/AUX BUTTON
Main MenuTable of Contents

The audio system reads and plays
playable sound f iles on the iPod. The
system cannot operate an iPod as a
mass storage device. The system will
only play songs stored on the iPod
with iTunes.
iPod and iTunes are registered
trademarks owned by Apple Inc.
iPods compatible with your audio
system using the USB adapter cable
are:
This audio system can select and
play the audio f iles on the iPod
with
the same controls used f or the in-
dash disc player. To play an iPod,
connect it to the USB adapter cable
in the console compartment by using
your dock connector, then press the
USB/AUX button. The ignition
switch must be in the ACCESSORY
(I) or ON (II) position. The iPod will
also be charged with the ignition
switch in these settings.
Sof tware
Ver. 1.3 or more
Ver. 1.1.2 or more
Ver. 1.3.1 or more
Ver. 1.1.3 or more
Ver. 1.1.3 or more
Ver. 1.0.4 or more
Ver. 1.1.1 or more
Ver. 2.2.1 or more
Ver. 2.1.0 or more
Ver. 2.1.0 or more
Ver. 5.12.1 or more
Model
iPod 5th
generation
iPod classic
iPod nano
1st generation
iPod nano
2nd generation
iPod nano
3rd generation
iPod nano
4th generation
iPod nano
1st generation
iPod touch
2nd generation
iPhone
iPhone 3G
iPhone 3GS
Playing an iPod(EX-L and Canadian EX models without navigation system)
To Play an iPod
266
Main MenuTable of Contents

Connect your dock connector to
the iPod correctly and securely.
Install the dock connector to the
USB adapter cable securely.
Some devices cannot be powered
or charged via the USB adapter. If
this is the case, use the accessory
adapter to supply power to your
device.
We recommend backing up your
data bef ore playing it.
Do not use an extension cable
between the USB adapter cable
equipped with your vehicle and
your dock connector.
Do not keep the iPod and dock
connector cable in the vehicle.
Direct sunlight and high heat will
damage it.
Do not connect your iPod using ahub.
UseonlycompatibleiPodswiththe
latest sof tware. iPods that are not
compatible will not work in this audio
unit.
Unclip the USB connector by
pivoting it, and pull out the USB
adapter cable in the console
compartment.
1.
2.
3.
CONT INUED
Connect ing an iPod
Playing an iPod(EX-L and Canadian EX models without navigation system)
Features
267
NOTE:
DOCK CONNECTOR
USB ADAPTER CABLE
USB ADAPTER CABLE
USB CONNECTOR
Main MenuTable of Contents

µEach time you press and
releasethe sideof theSKIPbar,
the system skips forward to the
beginning of the next track. Press
and release the side of the bar
to skip backward to the beginning of
the current track. Press it again to
skip to the beginning of the previous
track.
Use the SKIP bar while an iPod is
playing to select passages and
change f iles.
To move rapidly within playing track,
press and hold either side ( or
) of the SKIP bar.
If the iPod indicator does not appear
in the audio display, check the
connections, and try to reconnect the
iPod a f ew times.
If the audio system still does not
recognize the iPod, the iPod may
need to be reset. Follow the
instructions that came with your
iPod, or you can f ind reset
instructions online at
Turning the selector knob to the
right or lef t also changes a f ile.You can also select a file from any
list on the iPod menu: playlists,
artists, albums, songs, genres,
composers and podcasts by using the
selector knob. Push the selector
knob to switch the display to an iPod
menu, then turn the selector knob to
select a desired list. Press the
selector knob to set your selection.
The current f ile number and total of
the selected playable f iles are on the
display. It also shows the artist,
album and track (file) names on the
display.
If a f ile on your iPod has an album
art, it will be shown in the display.
www.apple.com/ T o Change or Select Files
SK IP
Playing an iPod(EX-L and Canadian EX models without navigation system)
268
