2012 HONDA ODYSSEY Brake light

404Handling the Unexpected
OverheatingHow to Handle OverheatingOverheating symptoms are as follows:
•The temperature gauge needle is at the mark or the engine suddenly loses
power.
•Steam is coming out of the engine compartment.■
First thing to do
1.Immediately park the vehicle in a safe place.
uMove the shift lever to
(P
and set the parking brake. Turn off all accessories
and turn on the hazard warning lights.
2. No steam coming out: Keep the engine running and open the hood.
Steam coming out: Turn off the engine and wait until steam goes away. Then,
open the hood.
1How to Handle Overheating
NOTICEContinuing to drive with the temperature gauge
needle at the mark may damage the engine.
3
WARNING
Steam and spray from an overheated
engine can seriously scald you.
Do not open the hood if steam is coming
out.
H
H

408
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator Comes On
Handling the Unexpected
If the Brake System Indicator Comes On
■
Reasons for the indicator to come on
•The brake fluid is low.
•There is a malfunction in the brake system.
■
What to do when the indicator comes on while driving
Press the brake pedal lightly to check pedal pressure.
•If normal, check the brake fluid level the next time you stop.
•If abnormal, take immediate action. If necessary, downshift the
transmission to slow the vehicle using engine braking.
1If the Brake System Indicator Comes On
Have your vehicle repaired immediately.
It is dangerous to drive with low brake fluid. If there
is no resistance from the brake pedal, stop
immediately in a safe place. If necessary downshift
the gears.
If the brake system indicator and ABS indicator come
on simultaneously, the electronic brake distribution
system is not working. This can result in vehicle
instability under sudden braking.
Have your vehicle inspected by a dealer immediately.
U.S.
Canada

420Information
Specifications■Vehicle Specifications*1: LX modelModel
Honda Odyssey
No. of Passengers:
Front 2
Rear 2nd Row 3 (2
*1)
3rd Row 3
Total 8 (7*1)
Weights:Gross Vehicle
Weight Rating
U.S.: 6,019 lbs (2,730 kg)
Canada: 2,730 kg
Gross Axle Weight
Rating (Front)
U.S.: 2,910 lbs (1,320 kg)
Canada: 1,320 kg
Gross Axle Weight
Rating (Rear)
U.S.: 3,197 lbs (1,450 kg)
Canada: 1,450 kg
Gross Combined
Weight Rating
U.S.: 8,477 lbs (3,845 kg)
Canada: 3,845 kg
Air Conditioning:Refrigerant Type
HFC-134a (R-134a)
Charge Quantity
24.7 – 26.5 oz (700 – 750 g)
Lubricant Type
ND-OIL8
■Engine Specifications
■Fuel
■Battery
■Washer FluidDisplacement
212 cu-in (3,471 cm
3)
Spark Plugs NGK DILZKR7A11G
Fuel:
Type
Unleaded gasoline, Pump octane number
of 87 or higher
Fuel Tank Capacity 21 US gal (79.5 ℓ)
Capacity/Type
60AH(5)/72AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 4.5 US qt (4.3 ℓ)
■Light Bulbs*1: Not available on all modelsHeadlights (Low Beam)
35W (D2S)
*1
55W (H11)
Headlights (High Beam) 60W (HB3)
Fog Lights
*1
55W (H11)
Front Turn Signal/Parking/Side
Marker Lights28/8W
Side Turn Signal Lights
(on Door Mirrors)
*1
LED
Brake/Rear Side Marker/Taillights 21/5W
Rear Turn Signal Lights
21W (Amber)
Back-Up Lights 21W
Tail-lights
3CP
High-Mount Brake Light 16W
Rear License Plate Lights
5W
Map Lights (Front) 8W
Map Lights (Rear)
5W
Cargo Area Light 8W
Vanity Mirror Lights
1.4W
Door Courtesy Lights 3.8W (2CP)
Glove Box Light
1.4W
Foot Light
*1
LED

426
uuEmissions TestinguTesting of Readiness Codes
Information
7.Select a nearby, lightly traveled major highway where you can maintain a speed
of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway in
(D
. Do not use cruise control. When traffic allows, drive for 90 seconds without
moving the accelerator pedal. (Vehicle speed may vary slightly; this is okay.) If you
cannot do this for a continuous 90 seconds because of traffic conditions, drive for
at least 30 seconds, then repeat it two more times (for a total of 90 seconds).
8.Drive in city/suburban traffic for at least 10 minutes. When traffic conditions
allow, let the vehicle coast for several seconds without using the accelerator pedal
or the brake pedal.
9.Park the vehicle and leave the engine off for 30 minutes.

Index
433
Index
Index
AABS (Anti-lock Brake System).................. 316
AC Power Outlet...................................... 177
Accessories and Modifications................ 329
Accessory Power Sockets......................... 176
Additives
Coolant .................................................. 350
Engine Oil ............................................... 345
Washer ................................................... 354
Additives, Engine Oil............................... 345
Adjusting
Armrest .................................................. 168
Front Seats.............................................. 154
Head Restraints ....................................... 157
Mirrors.................................................... 152
Rear Seats ............................................... 162
Steering Wheel ....................................... 151
Temperature ........................................... 100
Air Conditioning System
(Climate Control System)....................... 187
Changing the Mode................................ 187
Defrosting the Windshield
and Windows........................................ 188
Dust and Pollen Filter .............................. 384
Recirculation/Fresh Air Mode................... 187
Sensors ................................................... 192
Using Automatic Climate Control............ 187
Air Conditioning System (Heating and
Cooling System)...................................... 183
Cooling................................................... 185Defrosting the Windshield
and Windows ........................................ 185
Dust and Pollen Filter ............................... 384
Heating ................................................... 184
Air Pressure....................................... 371, 421
Airbags........................................................ 39
Advanced Airbags ..................................... 45
After a Collision ......................................... 43
Airbag Care ............................................... 53
Event Data Recorder .................................. 23
Front Airbags (SRS) .................................... 42
Indicator ........................................ 50, 76, 80
Passenger Airbag Off Indicator .................. 51
Sensors ...................................................... 39
Side Airbag Cutoff System ......................... 48
Side Airbag Off Indicator ........................... 52
Side Airbags .............................................. 46
Side Curtain Airbags .................................. 49
AM/FM Radio.................................... 198, 205
Anti-lock Brake System (ABS).................. 316
Indicator .................................................... 75
Armrest..................................................... 168
Audio Remote Controls............................ 203
Audio System............................................ 194
Adjusting the Sound ........................ 197, 204
Auxiliary Input Jack .................................. 195
Error Messages ........................................ 235
General Information ................................ 237
MP3/WMA/AAC ...................................... 226
Reactivating ............................................. 196
Recommended CDs ................................. 238Recommended Devices............................ 240
Remote Controls ..................................... 203
Security Code .......................................... 196
Theft Protection ...................................... 196
USB Adapter Cable.................................. 195
USB Flash Drives ...................................... 240
Audio/Information Display........................ 91
Authorized Manuals................................ 429
Auto Door Locking/Unlocking................. 116
Customize ............................................... 117
Automatic Lighting.................................. 143
Automatic Transmission........................... 300
Creeping ................................................. 300
Fluid ........................................................ 352
Kickdown ................................................ 300
Operating the Shift Lever................... 17, 302
Shift Lever Does Not Move ...................... 403
Shifting ................................................... 301
Auxiliary Input Jack.................................. 195
Average Fuel Economy.................. 88, 92, 99
Average Speed................................... 92, 100
BBattery...................................................... 379
Charging System Indicator................. 73, 406
Jump Starting .......................................... 401
Maintenance (Checking the Battery) ........ 379
Maintenance (Replacing) ................. 380, 382
Belts (Seat).................................................. 30
Beverage Holders..................................... 174

434Index
Blind Spot Information (BSI) System........ 312
Bluetooth
® Audio..................................... 230
Bluetooth® HandsFreeLink
®..................... 259
Booster Seats (For Children)....................... 67
Brake System............................................. 314
Anti-lock Brake System (ABS) ................... 316
Brake Assist System ................................. 317
Fluid ........................................................ 353
Foot Brake ............................................... 315
Indicator ............................................ 72, 408
Parking Brake .......................................... 314
Brightness Control (Instrument Panel).... 147
BSI (Blind Spot Information) System........ 312
Bulb Replacement..................................... 355
Back-Up/Taillight...................................... 363
Brake/Rear Side Marker/Taillight
and Rear Turn Signal Lights .................... 361
Fog Lights ................................................ 359
Front Turn Signal/Parking/
Side Marker Lights ................................. 360
Headlights ............................................... 355
High-Mount Brake Light .......................... 365
Rear License Plate Light............................ 364
Bulb Specifications.................................... 420
CCarbon Monoxide Gas................................ 68
Cargo Hooks.............................................. 178
Carrying Cargo.................................. 287, 289
CD Library.................................................. 216CD Player........................................... 200, 212
Center Pocket........................................... 173
Certification Label.................................... 422
Changing Bulbs........................................ 355
Charging System Indicator................. 73, 406
Child Safety................................................. 54
Childproof Door Locks............................. 115
Child Seat.................................................... 54
Booster Seats ............................................ 67
Child Seat for Infants................................. 56
Child Seat for Small Children ..................... 57
Installing a Child Seat
with a Lap/Shoulder Seat Belt .................. 62
Larger Children ......................................... 66
Rear-facing Child Seat ............................... 56
Selecting a Child Seat ................................ 58
Using a Tether ........................................... 64
Childproof Door Locks............................. 115
Cleaning the Exterior............................... 387
Cleaning the Interior................................ 385
Climate Control System............................ 187
Changing the Mode ................................ 187
Defrosting the Windshield
and Windows ........................................ 188
Dust and Pollen Filter............................... 384
Recirculation/Fresh Air Mode ................... 187
Sensors ................................................... 192
Using Automatic Climate Control ............ 187
Clock.......................................................... 108
Coat Hooks............................................... 178
Compact Spare Tire.......................... 391, 421Controls.................................................... 107
Coolant (Engine)...................................... 350
Adding to the Radiator ........................... 351
Adding to the Reserve Tank .................... 350
Overheating ............................................ 404
Temperature Gauge .................................. 86
Creeping (Automatic Transmission)........ 300
Cruise Control.......................................... 303
Indicator ................................................... 81
Cup Holders.............................................. 174
Customer Service Information................ 430
Customized Features............................... 101
DDaytime Running Lights.......................... 144
Dead Battery............................................ 401
Defrosting the Windshield
and Windows................................. 185, 188
Devices that Emit Radio Waves............... 423
Dimming
Headlights .............................................. 142
Rearview Mirror ...................................... 152
Dipstick (Engine Oil)................................ 346
Directional Signals (Turn Signal)............. 142
Display/Information Button...................... 98
Door Mirrors............................................. 153
Doors........................................................ 110
Auto Door Locking.................................. 116
Auto Door Unlocking .............................. 116
Door and Tailgate Open Indicator ....... 29, 77

435
Index
Keys........................................................ 110
Locking/Unlocking the Doors
from the Inside...................................... 114
Locking/Unlocking the Doors
from the Outside................................... 112
Lockout Prevention System ..................... 113
DOT Tire Quality Grading........................ 373
Driving...................................................... 285
Automatic Transmission .......................... 300
Braking ................................................... 314
Cruise Control ........................................ 303
Shifting Gear .......................................... 301
Starting the Engine ................................. 297
Driving Position Memory System............ 149
Dust and Pollen Filter.............................. 384
EElapsed Time........................................ 92, 99
Electronic Stability Control (ESC)............ 306
Emergency................................................ 417
Emissions Testing (Readiness Codes)...... 425
Engine....................................................... 422
Coolant .................................................. 350
Jump Starting ......................................... 401
Oil .......................................................... 345
Starting................................................... 297
Switch Buzzer ......................................... 141
Engine Coolant........................................ 350
Adding to the Radiator ........................... 351
Adding to the Reserve Tank .................... 350Overheating ............................................ 404
Temperature Gauge .................................. 86
Engine Oil................................................. 345
Adding .................................................... 347
Checking ................................................. 346
Displaying Oil Life ............................ 335, 339
Low Oil Pressure Indicator .................. 72, 406
Recommended Engine Oil ........................ 345
Exhaust Gas Hazard
(Carbon Monoxide).................................. 68
Exterior Care (Cleaning)........................... 387
Exterior Mirrors........................................ 153
FFeatures..................................................... 193
Filters
Dust and Pollen ....................................... 384
Oil ........................................................... 348
Flat Tire..................................................... 391
Flip-up Trash Bag Ring............................. 172
Floor Mats................................................. 386
Fluids
Automatic Transmission ........................... 352
Brake ....................................................... 353
Engine Coolant ........................................ 350
Power Steering ........................................ 354
Windshield Washer .................................. 354
Fog Light Indicator..................................... 80
Folding Down the Rear Seats.......... 162, 166
Foot Brake................................................. 315Front Airbags (SRS)..................................... 42
Front Seats................................................ 154
Adjusting ................................................ 154
Fuel...................................................... 18, 325
Economy ................................................. 328
Gauge ....................................................... 86
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Range ........................................... 88, 92, 99
Recommendation .................................... 325
Refueling................................................. 325
Fuel Economy........................................... 328
Fuel Fill Cap........................................ 18, 327
Message.................................................. 407
Fuel Fill Door...................................... 18, 326
Fuses.......................................................... 411
Inspecting and Changing......................... 416
Locations................. 411, 412, 413, 414, 415
GGasoline (Fuel)
Economy ................................................. 328
Gauge ....................................................... 86
Information ............................................. 325
Instant Fuel Economy .......................... 92, 99
Low Fuel Indicator ..................................... 75
Refueling................................................. 325
Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 301

436Index
Glass (care)................................................ 388
Glove Box.................................................. 171
Grocery Bag Hooks................................... 179HHalogen Bulbs................................... 355, 359
Handling the Unexpected........................ 389
HandsFreeLink
® (HFL)............................... 259
HandsFreeLink® (HFL)
Automatic Answering .............................. 270
Automatic Import of Cellular Phonebook and
Call History ............................................ 272
Automatic Transferring ............................ 270
HFL Buttons ............................................. 259
HFL Menus .............................................. 261
HFL Status Display.................................... 260
Making a Call .......................................... 276
Options During a Call .............................. 281
Phone Setup ............................................ 264
Receiving a Call ....................................... 280
Speed Dial ............................................... 273
HandsFreeLink® (HFL)
To Clear the System ................................. 271
HandsFreeLink® (HFL)
To Create a Security PIN........................... 269
Hazard Warning Button............................... 2
Head Restraints......................................... 157
Headlights................................................. 142
Aiming .................................................... 355
Automatic Operation ............................... 143Dimming ......................................... 142, 144
Operating................................................ 142
Heaters (Seat)........................................... 181
Heating and Cooling System................... 183
Cooling ................................................... 185
Defrosting the Windshield
and Windows ........................................ 185
Dust and Pollen Filter............................... 384
Heating ................................................... 184
HFL (HandsFreeLink
®)............................... 259
High Beam Indicator.................................. 79
IIdentification Numbers............................ 422
Engine and Transmission ......................... 422
Vehicle Identification ............................... 422
Ignition Switch......................................... 141
Illumination Control................................. 147
Knob ....................................................... 147
Immobilizer System.................................. 134
Indicator.................................................... 80
Indicators.................................................... 72
ABS (Anti-lock Brake System)..................... 75
BSI (Blind Spot Information) System ........... 83
Charging System ............................... 73, 406
CRUISE CONTROL ............................. 81, 304
CRUISE MAIN .................................... 81, 303
Daytime Running Lights............................. 77
Door and Tailgate Open ...................... 29, 77
Fog Light ................................................... 80Fuel Economy ........................................... 81
High Beam ................................................ 79
Immobilizer System ................................... 80
Lights On .................................................. 79
Low Fuel ................................................... 75
Low Oil Pressure ............................... 72, 406
Low Tire Pressure .............................. 78, 308
Low Tire Pressure/TPMS ............ 78, 308, 309
Maintenance Minder......................... 82, 335
Malfunction Indicator Lamp .............. 73, 407
Parking Brake and Brake System ....... 72, 408
Parking Sensor .......................................... 77
Power Sliding Door ................................... 83
Power Tailgate .......................................... 82
Seat Belt Reminder.............................. 31, 75
Security System Alarm............................... 81
Shift Lever Position.................................... 74
Side Airbag Off ................................... 52, 80
Starter System........................................... 81
Supplemental Restraint System ........... 50, 76
System Message ....................................... 79
TPMS ................................................ 78, 310
Transmission ............................................. 74
Turn Signal ............................................... 79
VSA
® (Vehicle Stability Assist)
System ............................................ 76, 306
VSA® OFF .......................................... 76, 307
Washer Level ............................................ 82
Information.............................................. 419
Information Display................................... 87
Instant Fuel Economy.................... 88, 92, 99
